Page 3969 of 5621

INFINITI M35 2006 Factory Service Manual LAN-300 [CAN] CAN SYSTEM (TYPE 6) Revision: 2006 January2006 M35/M45 Case 17 Check ABS actuator and electric unit (control unit) circuit. Refer to LAN-312, "ABS Actuator and Electric Unit (Contro

Page 3970 of 5621

INFINITI M35 2006 Factory Service Manual CAN SYSTEM (TYPE 6) LAN-301 [CAN] C D E F G H I J L MA B LAN Revision: 2006 January2006 M35/M45 Case 18 Check IPDM E/R circuit. Refer to LAN-312, "IPDM E/R Circuit Inspection" . PKIB8464E SKIB

Page 3971 of 5621

INFINITI M35 2006 Factory Service Manual LAN-302 [CAN] CAN SYSTEM (TYPE 6) Revision: 2006 January2006 M35/M45 Case 19 Check CAN communication circuit. Refer to LAN-313, "CAN Communication Circuit Inspection" . Case 20 Check IPDM E/R

Page 3972 of 5621

INFINITI M35 2006 Factory Service Manual CAN SYSTEM (TYPE 6) LAN-303 [CAN] C D E F G H I J L MA B LAN Revision: 2006 January2006 M35/M45 Case 21 Check IPDM E/R ignition relay circuit continuously sticks “ON”. Refer to LAN-320,

Page 3973 of 5621

INFINITI M35 2006 Factory Service Manual LAN-304 [CAN] CAN SYSTEM (TYPE 6) Revision: 2006 January2006 M35/M45 3. CHECK HARNESS FOR OPEN CIRCUIT Check continuity between harness connector (A) and data link con- nector (B). OK or NG O

Page 3974 of 5621

INFINITI M35 2006 Factory Service Manual CAN SYSTEM (TYPE 6) LAN-305 [CAN] C D E F G H I J L MA B LAN Revision: 2006 January2006 M35/M45 Inspection Between RAS Control Unit and Driver Seat Control Unit CircuitNKS0041C 1. CHECK CONNECTOR 1. T

Page 3975 of 5621

INFINITI M35 2006 Factory Service Manual LAN-306 [CAN] CAN SYSTEM (TYPE 6) Revision: 2006 January2006 M35/M45 3. CHECK HARNESS FOR OPEN CIRCUIT 1. Disconnect ABS actuator and electric unit (control unit) connector. 2. Check continuity betwee

Page 3976 of 5621

INFINITI M35 2006 Factory Service Manual CAN SYSTEM (TYPE 6) LAN-307 [CAN] C D E F G H I J L MA B LAN Revision: 2006 January2006 M35/M45 2. CHECK HARNESS FOR OPEN CIRCUIT 1. Disconnect A/T assembly connector. 2. Check resistance between A/T
