INFINITI M35 2006 Factory Service Manual FSU-14
[2WD]
TRANSVERSE LINK
Revision: 2006 January2006 M35/M45
TRANSVERSE LINKPFP:54500
Removal and InstallationNES000IG
REMOVAL
1. Remove tires from vehicle with a power tool.
2. Remove undercover w

FSU-14
[2WD]
TRANSVERSE LINK
Revision: 2006 January2006 M35/M45
TRANSVERSE LINKPFP:54500
Removal and InstallationNES000IG
REMOVAL
1. Remove tires from vehicle with a power tool.
2. Remove undercover with a power tool.
3. Remove the mounting nut on the upper side of stabilizer connecting rod with a power tool, and then
remove stabilizer connecting rod from transverse link.
4. Separate steering gear assembly and lower joint. Refer to PS-13, "
STEERING COLUMN" .
5. Remove rack stay. Refer to FSU-8, "
Components" .
6. Remove the mounting nut and bolt on the lower side of shock absorber with a power tool, and then
remove shock absorber from transverse link.
7. Remove transverse link from steering knuckle. Refer to FAX-5, "
Removal and Installation" .
8. Set jack under front suspension member.
9. Remove the mounting bolts of member bracket, and then remove member bracket from front suspension
member with a power tool. Refer to FSU-8, "
Components" .
10. Remove the mounting nut and bolts of member stay, and then remove member stay from front suspension
member and vehicle with a power tool.
11. Remove the mounting nut of front suspension member with a power tool. Refer to FSU-8, "
Components" .
12. Gradually lower the suspension member to the position where transverse link mounting bolts is remove.
CAUTION:
Be careful not to lower it too far. (Do not overload the links)
13. Remove mounting nut and bolts, and then remove transverse link from vehicle.
INSPECTION AFTER REMOVAL
Visual Inspection
Check the following:
Transverse link and bushing for deformation, cracks or damage. Replace it if a malfunction is detected.
Ball joint boot for cracks or other damage, and also for grease leakage. Replace it if a malfunction is
detected.
Ball Joint Inspection
Manually move ball stud to confirm it moves smoothly with no binding.
Swing Torque Inspection
NOTE:
Before measurement, move ball stud at least ten times by hand to check for smooth movement.
Hook a spring balance at cotter pin mounting hole. Confirm
spring balance measurement value is within specifications when
ball stud begins moving.
If it is outside the specified range, replace transverse link
assembly.Swing torque
: 0.5 - 3.6 Nꞏm (0.06 - 0.36 kg-m, 5 - 31 in-lb)
Spring balance measurement
: 7.8 - 56.3 N (0.8 - 5.7 kg, 1.8 - 12.5 lb)
SEIA0523E

Page 3442 of 5621

INFINITI M35 2006 Factory Service Manual TRANSVERSE LINK
FSU-15
[2WD]
C
D
F
G
H
I
J
K
L
MA
B
FSU
Revision: 2006 January2006 M35/M45
Rotating Torque Inspection
Attach mounting nut to ball stud. Make sure that rotating torque
is within specifi

Page 3443 of 5621

INFINITI M35 2006 Factory Service Manual FSU-16
[2WD]
UPPER LINK
Revision: 2006 January2006 M35/M45
UPPER LINKPFP:54524
Removal and InstallationNES000IH
REMOVAL
1. Remove tires from vehicle with a power tool.
2. Remove shock absorber. Refer

FSU-16
[2WD]
UPPER LINK
Revision: 2006 January2006 M35/M45
UPPER LINKPFP:54524
Removal and InstallationNES000IH
REMOVAL
1. Remove tires from vehicle with a power tool.
2. Remove shock absorber. Refer to FSU-11, "
COIL SPRING AND SHOCK ABSORBER" .
3. Remove mounting nut and bolt with a power tool, and then remove upper link from steering knuckle.
4. Remove mounting nuts and bolts, and then remove upper link and stopper rubber from vehicle.
INSPECTION AFTER REMOVAL
Visual Inspection
Check the following:
Upper link and bushing for deformation, cracks or damage. Replace it if a malfunction is detected.
Ball joint boot for cracks or other damage, and also for grease leakage. Replace it if a malfunction is
detected.
Ball Joint Inspection
Manually move ball stud to confirm it moves smoothly with no binding.
Swing Torque Inspection
NOTE:
Before measurement, move ball stud at least ten times by hand to check for smooth movement.
Hook a spring balance at cutout on ball stud. Confirm spring bal-
ance measurement value is within specifications when ball stud
begins moving.
If it is outside the specified range, replace upper link assembly.
Rotating Torque Inspection
Attach mounting nut to ball stud. Make sure that rotating torque
is within specifications with a preload gauge [SST].
If it is outside the specified range, replace upper link assembly.
Axial End Play Inspection
Move tip of ball stud in axial direction to check for looseness.
If it is outside the specified range, replace upper link assembly.
INSTALLATION
Installation is the reverse order of removal. For tightening torque, refer to FSU-8, "Components" .
Perform final tightening of bolts and nuts at the vehicle installation position (rubber bushing) under
unladen conditions with tires on level ground. Check wheel alignment. Refer to FSU-6, "
Wheel Alignment
Inspection" . Swing torque
: 0 - 2.0 Nꞏm (0 - 0.2 kg-m, 0 - 17 in-lb)
Spring balance measurement
: 0 - 61.5 N (0 - 6.2 kg, 0 - 13.6 lb)
SEIA0523E
Rotating torque
: 0 - 2.0 Nꞏm (0 - 0.2 kg-m, 0 - 17 in-lb)
SDIA1150E
Axial end play : 0 mm (0 in)

Page 3444 of 5621

INFINITI M35 2006 Factory Service Manual UPPER LINK
FSU-17
[2WD]
C
D
F
G
H
I
J
K
L
MA
B
FSU
Revision: 2006 January2006 M35/M45
Adjust neutral position of steering angle sensor after checking wheel alignment. Refer to BRC-6, "Adjust-
ment

Page 3445 of 5621

INFINITI M35 2006 Factory Service Manual FSU-18
[2WD]
STABILIZER BAR
Revision: 2006 January2006 M35/M45
STABILIZER BARPFP:54611
Removal and InstallationNES000II
REMOVAL
1. Remove tires from vehicle with a power tool.
2. Remove undercover wit

Page 3446 of 5621

INFINITI M35 2006 Factory Service Manual SERVICE DATA AND SPECIFICATIONS (SDS)
FSU-19
[2WD]
C
D
F
G
H
I
J
K
L
MA
B
FSU
Revision: 2006 January2006 M35/M45
SERVICE DATA AND SPECIFICATIONS (SDS)PFP:00030
Wheel Alignment (Unladen)NES000IJ
Ball J

Page 3447 of 5621

INFINITI M35 2006 Factory Service Manual FSU-20
[AWD]
PRECAUTIONS
Revision: 2006 January2006 M35/M45
[AWD]PRECAUTIONSPFP:00001
CautionNES000IM
When installing rubber bushings, the final tightening must be carried out under unlade

Page 3448 of 5621

INFINITI M35 2006 Factory Service Manual PREPARATION
FSU-21
[AWD]
C
D
F
G
H
I
J
K
L
MA
B
FSU
Revision: 2006 January2006 M35/M45
PREPARATIONPFP:00002
Special Service Tools [SST]NES000IN
The actual shapes of Kent-Moore tools may differ from th
