Page 3217 of 5621

INFINITI M35 2006 Factory Service Manual EM-154 [VQ35DE] SERVICE DATA AND SPECIFICATIONS (SDS) Revision: 2006 January2006 M35/M45 CYLINDER HEAD Unit: mm (in) Valve Dimensions Unit: mm (in) Items Standard Limit Head surface distortion Less th

Page 3218 of 5621

INFINITI M35 2006 Factory Service Manual SERVICE DATA AND SPECIFICATIONS (SDS) EM-155 [VQ35DE] C D E F G H I J K L MA EM Revision: 2006 January2006 M35/M45 Valve Guide Unit: mm (in) Items Standard Oversize (Service) [0.2 (0.008)] Va l v e

Page 3219 of 5621

INFINITI M35 2006 Factory Service Manual EM-156 [VQ35DE] SERVICE DATA AND SPECIFICATIONS (SDS) Revision: 2006 January2006 M35/M45 Valve Seat Unit: mm (in) * 1 : Diameter made by intersection point of conic angles “1” and “2” *2 : Di

Page 3220 of 5621

INFINITI M35 2006 Factory Service Manual SERVICE DATA AND SPECIFICATIONS (SDS) EM-157 [VQ35DE] C D E F G H I J K L MA EM Revision: 2006 January2006 M35/M45 CYLINDER BLOCK Unit: mm (in) Surface flatnessStandard Less than 0.03 (0.0012) Limit 0

Page 3221 of 5621

INFINITI M35 2006 Factory Service Manual EM-158 [VQ35DE] SERVICE DATA AND SPECIFICATIONS (SDS) Revision: 2006 January2006 M35/M45 PISTON, PISTON RING AND PISTON PIN Available Piston Unit: mm (in) Piston Ring Unit: mm (in) Piston Pin Unit: mm

Page 3222 of 5621

INFINITI M35 2006 Factory Service Manual SERVICE DATA AND SPECIFICATIONS (SDS) EM-159 [VQ35DE] C D E F G H I J K L MA EM Revision: 2006 January2006 M35/M45 CONNECTING ROD Unit: mm (in) *: After installing in connecting rodItems Standard Limi

Page 3223 of 5621

INFINITI M35 2006 Factory Service Manual EM-160 [VQ35DE] SERVICE DATA AND SPECIFICATIONS (SDS) Revision: 2006 January2006 M35/M45 CRANKSHAFT Unit: mm (in) *: Total indicator readingMain journal diameter. “Dm” grade StandardGrade No. A Gr

Page 3224 of 5621

INFINITI M35 2006 Factory Service Manual SERVICE DATA AND SPECIFICATIONS (SDS) EM-161 [VQ35DE] C D E F G H I J K L MA EM Revision: 2006 January2006 M35/M45 MAIN BEARING Undersize Unit: mm (in) Main Bearing Oil Clearance Unit: mm (in) *: Actu
