Page 3337 of 5621

INFINITI M35 2006 Factory Service Manual EM-274 [VK45DE] CYLINDER BLOCK Revision: 2006 January2006 M35/M45 MAIN BEARING OIL CLEARANCE Method by Calculation Install main bearings to cylinder block and main bearing caps, and tighten

Page 3338 of 5621

INFINITI M35 2006 Factory Service Manual CYLINDER BLOCK EM-275 [VK45DE] C D E F G H I J K L MA EM Revision: 2006 January2006 M35/M45 CRUSH HEIGHT OF MAIN BEARING When main bearing cap is removed after being tightened to the specified torq

Page 3339 of 5621

INFINITI M35 2006 Factory Service Manual EM-276 [VK45DE] SERVICE DATA AND SPECIFICATIONS (SDS) Revision: 2006 January2006 M35/M45 SERVICE DATA AND SPECIFICATIONS (SDS)PFP:00030 Standard and LimitNBS004PQ GENERAL SPECIFICATIONS DRIVE BELTS IN

Page 3340 of 5621

INFINITI M35 2006 Factory Service Manual SERVICE DATA AND SPECIFICATIONS (SDS) EM-277 [VK45DE] C D E F G H I J K L MA EM Revision: 2006 January2006 M35/M45 SPARK PLUG Unit: mm (in) CAMSHAFT AND CAMSHAFT BEARING Unit: mm (in) *: Total indicat

Page 3341 of 5621

INFINITI M35 2006 Factory Service Manual EM-278 [VK45DE] SERVICE DATA AND SPECIFICATIONS (SDS) Revision: 2006 January2006 M35/M45 Available Adjusting Shims Thickness “T” mm (in) Identification (stamped) mark 2.32 (0.0913) 232 2.33 (0.091

Page 3342 of 5621

INFINITI M35 2006 Factory Service Manual SERVICE DATA AND SPECIFICATIONS (SDS) EM-279 [VK45DE] C D E F G H I J K L MA EM Revision: 2006 January2006 M35/M45 CYLINDER HEAD Unit: mm (in) 2.70 (0.1063) 270 2.71 (0.1067) 271 2.72 (0.1071) 272 2.7

Page 3343 of 5621

INFINITI M35 2006 Factory Service Manual EM-280 [VK45DE] SERVICE DATA AND SPECIFICATIONS (SDS) Revision: 2006 January2006 M35/M45 Valve Dimensions Unit: mm (in) Valve Guide Unit: mm (in) ItemsStandard Valve head diameter “D” Intake 36.0

Page 3344 of 5621

INFINITI M35 2006 Factory Service Manual SERVICE DATA AND SPECIFICATIONS (SDS) EM-281 [VK45DE] C D E F G H I J K L MA EM Revision: 2006 January2006 M35/M45 Valve Seat Unit: mm (in) Valve Spring Items Standard Service Cylinder head seat reces
