INFINITI M35 2006 Factory Service Manual BL-86
INTELLIGENT KEY SYSTEM
Revision: 2006 January2006 M35/M45
Trouble Diagnosis Symptom ChartNIS001XK
ALL FUNCTIONS OF INTELLIGENT KEY SYSTEM DOES NOT OPERATE
NOTE:
Before performing the diagnosis i

BL-86
INTELLIGENT KEY SYSTEM
Revision: 2006 January2006 M35/M45
Trouble Diagnosis Symptom ChartNIS001XK
ALL FUNCTIONS OF INTELLIGENT KEY SYSTEM DOES NOT OPERATE
NOTE:
Before performing the diagnosis in the following table, check “Trouble Diagnosis Procedure”. Refer to BL-
78, "Trouble Diagnosis Procedure" .
Make sure that vehicle is under the condition shown in “Conditions of vehicle” before starting diagnosis,
and check each symptom.
If the following “symptoms” are detected, check systems shown in the “Diagnosis/service procedure” col-
umn in this order.
Conditions of Vehicle (Operating Conditions)
“ENGINE START BY I-KEY” and “LOCK/UNLOCK BY I-KEY” are ON when setting on CONSULT-II.
All doors are closed.
DOOR LOCK/UNLOCK FUNCTION MALFUNCTION
NOTE:
Before performing the diagnosis in the following table, check “Trouble Diagnosis Procedure”. Refer to BL-
78, "Trouble Diagnosis Procedure" .
Make sure that vehicle is under the condition shown in “Conditions of vehicle” before starting diagnosis,
and check each symptom.
If the following “symptoms” are detected, check systems shown in the “Diagnosis/service procedure” col-
umn in this order.
Conditions of Vehicle (Operating Conditions)
“LOCK/UNLOCK BY I-KEY” is ON when setting on CONSULT-II.
Intelligent Key is out of key slot.
All doors are closed.
Symptom Diagnosis/service procedure Reference page
All function of Intelligent Key system dose not
operate.1.Check Intelligent Key unit power supply and ground
circuit.BL-93
2. Check Intelligent Key battery inspection.BL-126
3. Check remote keyless entry receiver.BL-117
4. Replace Intelligent Key unit.BL-125
Symptom Diagnosis/service procedure Reference page
Door lock/unlock do not operate by door
request switch.1.Check Intelligent Key unit power supply and ground
circuit.BL-93
2. Check door switch.BL-96
3. Check key slot.BL-94
4. Replace Intelligent Key unit.BL-125
Door lock/unlock does not operate by request
switch (driver side).1. Check door request switch (driver side).BL-1012. Check outside key antenna (driver side).BL-108
3. Replace Intelligent Key unit.BL-125
Door lock/unlock does not operate by request
switch (passenger side).1. Check door request switch (passenger side).BL-1012. Check outside key antenna (passenger side).BL-108
3. Replace Intelligent Key unit.BL-125
Selective unlock function does not operate by
door request switch (driver side) (other door
lock function operate).1.Check “SELECT UNLOCK FUNCTION” setting in
“WORK SUPPORT”.BL-83
2.Check selective unlock function with a remote control-
ler or door key cylinder.BL-26
3. Replace BCM.BCS-17
