Page 3137 of 5621
EM-74
[VQ35DE]
TIMING CHAIN
Revision: 2006 January2006 M35/M45
Apply liquid gasket on installation position of water pump and cylinder head very completely.
d. Align rear timing chain case and water pump assembly with dowel pins (right and left bank) on cylinder
block and install rear timing chain case.
Make sure O-rings stay in place during installation to cylinder block and cylinder head.
e. Tighten mounting bolts in numerical order as shown in the fig-
ure.
There are two type mounting bolts. Refer to the following for
locating bolts.
f. After all bolts are tightened, retighten them to the specified
torque in numerical order shown in the figure.
If liquid gasket protrudes, wipe it off immediately.Bolt length: Bolt position
20 mm (0.79 in) : 1, 2, 3, 6, 7, 8, 9, 10
16 mm (0.63 in) : Except the above
: 12.7 Nꞏm (1.3 kg-m, 9 ft-lb)
PBIC2680E
SEM735G
Page 3138 of 5621
![INFINITI M35 2006 Factory Service Manual TIMING CHAIN
EM-75
[VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
Revision: 2006 January2006 M35/M45
g. After installing rear timing chain case, check the surface height
difference between the followi INFINITI M35 2006 Factory Service Manual TIMING CHAIN
EM-75
[VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
Revision: 2006 January2006 M35/M45
g. After installing rear timing chain case, check the surface height
difference between the followi](/manual-img/42/57023/w960_57023-3137.png)
TIMING CHAIN
EM-75
[VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
Revision: 2006 January2006 M35/M45
g. After installing rear timing chain case, check the surface height
difference between the following parts on the oil pan (upper)
mounting surface.
If not within the standard, repeat the installation procedure.
3. Install water pump with new O-rings. Refer to CO-24, "
WATER PUMP" .
4. Make sure that dowel pin hole, dowel pin and crankshaft key are
located as shown in the figure. (No. 1 cylinder at compression
TDC)
NOTE:
Though camshaft does not stop at the position as shown in the
figure, for the placement of cam nose, it is generally accepted
camshaft is placed for the same direction of the figure.
CAUTION:
Hole on small dia. side must be used for intake side dowel pin hole. Do not misidentify (ignore big
dia. side).
5. Install timing chains (secondary) and camshaft sprockets as follows:
CAUTION:
Mating marks between timing chain and sprockets slip easily. Confirm all mating mark positions
repeatedly during the installation process.
a. Push plunger of timing chain tensioner (secondary) and keep it
pressed in with a stopper pin.Standard
Rear timing chain case to cylinder block:
–0.24 to 0.14 mm (–0.0094 to 0.0055 in)
SEM943G
Camshaft dowel pin hole (intake side)
: At cylinder head upper face side in each bank.
Camshaft dowel pin (exhaust side)
: At cylinder head upper face side in each bank.
Crankshaft key
: At cylinder head side of right bank.
KBIA1073E
SEM430G
Page 3139 of 5621
![INFINITI M35 2006 Factory Service Manual EM-76
[VQ35DE]
TIMING CHAIN
Revision: 2006 January2006 M35/M45
b. Install timing chains (secondary) and camshaft sprockets.
Align the mating marks on timing chain (secondary) (gold link)
with the on INFINITI M35 2006 Factory Service Manual EM-76
[VQ35DE]
TIMING CHAIN
Revision: 2006 January2006 M35/M45
b. Install timing chains (secondary) and camshaft sprockets.
Align the mating marks on timing chain (secondary) (gold link)
with the on](/manual-img/42/57023/w960_57023-3138.png)
EM-76
[VQ35DE]
TIMING CHAIN
Revision: 2006 January2006 M35/M45
b. Install timing chains (secondary) and camshaft sprockets.
Align the mating marks on timing chain (secondary) (gold link)
with the ones on intake and exhaust camshaft sprockets
(punched), and install them.
NOTE:
Mating marks for intake camshaft sprocket are on the back
side of camshaft sprocket (secondary).
There are two types of mating marks, circle and oval types.
They should be used for the right and left banks, respec-
tively.
Align dowel pin and pin hole on camshafts with the groove
and dowel pin on sprockets, and install them.
On the intake side, align pin hole on the small diameter side of
the camshaft front end with dowel pin on the back side of
camshaft sprocket, and install them.
On the exhaust side, align dowel pin on camshaft front end
with pin groove on camshaft sprocket, and install them.
In case that positions of each mating mark and each dowel
pin are not fit on mating parts, make fine adjustment to the
position holding the hexagonal portion on camshaft with wrench or equivalent.
Mounting bolts for camshaft sprockets must be tightened in the next step. Tightening them by hand is
enough to prevent the dislocation of dowel pins.
It may be difficult to visually check the dislocation of mating
marks during and after installation. To make the matching
easier, make a mating mark on the top of sprocket teeth and
its extended line in advance with paint.
c. After confirming the mating marks are aligned, tighten camshaft
sprocket mounting bolts.
Secure camshaft using a wrench at the hexagonal portion to
tighten mounting bolts.Right bank : Use circle type.
Left bank : Use oval type.
PBIC2981E
PBIC0891E
KBIA1698J
Page 3140 of 5621
TIMING CHAIN
EM-77
[VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
Revision: 2006 January2006 M35/M45
d. Pull stopper pins out from timing chain tensioners (secondary).
6. Install tension guide.
7. Install timing chain (primary) as follows:
a. Install crankshaft sprocket.
Make sure the mating marks on crankshaft sprocket face the
front of the engine.
b. Install timing chain (primary).
Install timing chain (primary) so the mating mark (punched) on
camshaft sprocket is aligned with the pink link on timing
chain, while the mating mark (notched) on crankshaft
sprocket is aligned with the orange one on timing chain, as
shown in the figure.
When it is difficult to align mating marks of timing chain (pri-
mary) with each sprocket, gradually turn camshaft using
wrench on the hexagonal portion to align it with the mating
marks.
During alignment, be careful to prevent dislocation of mating
mark alignments of timing chains (secondary).
PBIC2110E
SEM929E
PBIC3494E
Page 3141 of 5621
![INFINITI M35 2006 Factory Service Manual EM-78
[VQ35DE]
TIMING CHAIN
Revision: 2006 January2006 M35/M45
8. Install internal chain guide, slack guide and timing chain ten-
sioner (primary).
CAUTION:
Do not overtighten slack guide mo INFINITI M35 2006 Factory Service Manual EM-78
[VQ35DE]
TIMING CHAIN
Revision: 2006 January2006 M35/M45
8. Install internal chain guide, slack guide and timing chain ten-
sioner (primary).
CAUTION:
Do not overtighten slack guide mo](/manual-img/42/57023/w960_57023-3140.png)
EM-78
[VQ35DE]
TIMING CHAIN
Revision: 2006 January2006 M35/M45
8. Install internal chain guide, slack guide and timing chain ten-
sioner (primary).
CAUTION:
Do not overtighten slack guide mounting bolts. It is normal
for a gap to exist under the bolt seats when mounting bolts
are tightened to the specification.
9. Install the timing chain tensioner (primary) with the following procedure:
a. Pull plunger stopper tab up (or turn lever downward) so as to
remove plunger stopper tab from the ratchet of plunger.
NOTE:
Plunger stopper tab and lever are synchronized.
b. Push plunger into the inside of tensioner body.
c. Hold plunger in the fully compressed position by engaging
plunger stopper tab with the tip of ratchet.
d. To secure lever, insert stopper pin through hole of lever into ten-
sioner body hole.
The lever parts and the tab are synchronized. Therefore, the
plunger will be secured under this condition.
NOTE:
Figure shows the example of 1.2 mm (0.047 in) diameter thin screwdriver being used as the stopper pin.
PBIC2109E
PBIC2633E
PBIC3568E
Page 3142 of 5621
![INFINITI M35 2006 Factory Service Manual TIMING CHAIN
EM-79
[VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
Revision: 2006 January2006 M35/M45
e. Install timing chain tensioner (primary).
Remove any dirt and foreign materials completely from the
INFINITI M35 2006 Factory Service Manual TIMING CHAIN
EM-79
[VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
Revision: 2006 January2006 M35/M45
e. Install timing chain tensioner (primary).
Remove any dirt and foreign materials completely from the](/manual-img/42/57023/w960_57023-3141.png)
TIMING CHAIN
EM-79
[VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
Revision: 2006 January2006 M35/M45
e. Install timing chain tensioner (primary).
Remove any dirt and foreign materials completely from the
back and the mounting surfaces of timing chain tensioner (pri-
mary).
f. Pull out stopper pin after installing, and then release plunger.
10. Make sure again that the mating marks on sprockets and timing chain have not slipped out of alignment.
11. Install new O-rings on rear timing chain case.
12. Install new front oil seal on front timing chain case.
Apply new engine oil to both oil seal lip and dust seal lip.
Install it so that each seal lip is oriented as shown in the fig-
ure.
Using a suitable drift [outer diameter: 60 mm (2.36 in)], press-
fit oil seal until it becomes flush with front timing chain case
end face.
Make sure the garter spring is in position and seal lip is not
inverted.
13. Install water pump cover and chain tensioner cover to front timing chain case.
PBIC3569E
PBIC2548E
SEM715A
PBIC0790E
Page 3143 of 5621
![INFINITI M35 2006 Factory Service Manual EM-80
[VQ35DE]
TIMING CHAIN
Revision: 2006 January2006 M35/M45
Apply a continuous bead of liquid gasket with the tube presser
[SST: WS39930000 ( — )] to front timing chain case as
shown in t INFINITI M35 2006 Factory Service Manual EM-80
[VQ35DE]
TIMING CHAIN
Revision: 2006 January2006 M35/M45
Apply a continuous bead of liquid gasket with the tube presser
[SST: WS39930000 ( — )] to front timing chain case as
shown in t](/manual-img/42/57023/w960_57023-3142.png)
EM-80
[VQ35DE]
TIMING CHAIN
Revision: 2006 January2006 M35/M45
Apply a continuous bead of liquid gasket with the tube presser
[SST: WS39930000 ( — )] to front timing chain case as
shown in the figure.
Use Genuine RTV Silicone Sealant or equivalent. Refer to
GI-48, "
RECOMMENDED CHEMICAL PRODUCTS AND
SEALANTS" .
14. Install front timing chain case as follows:
a. Apply a continuous bead of liquid gasket with the tube presser
[SST: WS39930000 ( — )] to front timing chain case back
side as shown in the figure.
Use Genuine RTV Silicone Sealant or equivalent. Refer to
GI-48, "
RECOMMENDED CHEMICAL PRODUCTS AND
SEALANTS" .
b. Install front timing chain case as to fit its dowel pin hole together dowel pin on rear timing chain case.
c. Tighten mounting bolts to the specified torque in numerical order
as shown in the figure.
There are two type of mounting bolts. Refer to the following
for locating bolts.
d. After all bolts are tightened, retighten them to the specified
torque in numerical order shown in the figure.
CAUTION:
Be sure to wipe off any excessive liquid gasket leaking on surface mating with oil pan (upper).
SEM744GA
PBIC2658E
M8 bolts : 1, 2
: 28.4 Nꞏm (2.9 kg-m, 21 ft-lb)
M6 bolts : Except the above
: 12.7 Nꞏm (1.3 kg-m, 9 ft-lb)
KBIA1303E
Page 3144 of 5621
![INFINITI M35 2006 Factory Service Manual TIMING CHAIN
EM-81
[VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
Revision: 2006 January2006 M35/M45
e. After installing front timing chain case, check the surface height
difference between the following part INFINITI M35 2006 Factory Service Manual TIMING CHAIN
EM-81
[VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
Revision: 2006 January2006 M35/M45
e. After installing front timing chain case, check the surface height
difference between the following part](/manual-img/42/57023/w960_57023-3143.png)
TIMING CHAIN
EM-81
[VQ35DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
Revision: 2006 January2006 M35/M45
e. After installing front timing chain case, check the surface height
difference between the following parts on the oil pan (upper)
mounting surface.
If not within the standard, repeat the installation procedure.
15. Install right and left intake valve timing control covers as follows:
a. Install new seal rings in shaft grooves.
b. Apply a continuous bead of liquid gasket with the tube presser
[SST: WS39930000 ( — )] to intake valve timing control cov-
ers as shown in the figure.
Use Genuine RTV Silicone Sealant or equivalent. Refer to
GI-48, "
RECOMMENDED CHEMICAL PRODUCTS AND
SEALANTS" .
c. Install new collared O-rings in front timing chain case oil hole
(left and right sides).
d. Being careful not to move seal ring from the installation groove, align dowel pins on front timing chain
case with holes to install intake valve timing control covers.
e. Tighten mounting bolts in numerical order as shown in the fig-
ure.
16. Install oil pans (upper and lower). Refer to EM-29, "
OIL PAN AND OIL STRAINER" .
17. Install rocker covers (right and left banks). Refer to EM-51, "
ROCKER COVER" .
18. Install crankshaft pulley as follows:
a. Fix crankshaft using the ring gear stopper [SST: KV10117700 (J44716)].
b. Install crankshaft pulley, taking care not to damage front oil seal.
When press-fitting crankshaft pulley with plastic hammer, tap on its center portion (not circumference). Standard
Front timing chain case to rear timing chain case:
–0.14 to 0.14 mm (–0.005 to 0.0055 in)
SEM943G
SBIA0492E
PBIC2631E
PBIC0918E
