ACS-2Revision: 2006 January2006 M35/M45 PLY CIR 2 ............................................................... 41
DTC 3 VHCL SPEED SE CIRC .............................. 42
DTC 4 ABS/TCS/VDC CIRC .................................. 42
DTC 5 BRAKE SW/STOP L SW ............................. 43
DTC 6 OPERATION SW CIRC ............................... 47
DTC 12 LASER BEAM OFFCNTR ......................... 48
DTC 13 STOP LAMP RLY FIX ............................... 49
DTC 14 ECM CIRCUIT ........................................... 55
DTC 15 GEAR POSITION ...................................... 56
DTC 16 RADAR STAIN .......................................... 57
DTC 18 LASER AIMING INCMP ............................ 57
DTC 21 UNIT HIGH TEMP ..................................... 57
DTC 24 NP RANGE ............................................... 58
DTC 25 SHIFT RANGE IND ................................... 58
DTC 26 ECD MODE MALF .................................... 59
DTC 27 ECD PWR SUPLY CIR .............................. 59
DTC 100 CAN COMM CIRCUIT ............................. 60
DTC 110 CONTROL UNIT (CAN) ........................... 60
TROUBLE DIAGNOSIS FOR SYMPTOMS .............. 61
Symptom Chart ....................................................... 61
Symptom 1: MAIN Switch Does Not Turn ON*
1 ,
MAIN Switch Does Not Turn OFF*
2 ........................ 62Symptom 2: ICC System Cannot Be Set (MAIN
Switch Turns ON/OFF) ............................................ 63
Symptom 3: ICC System Cannot Be Operated by
CANCEL Switch, RESUME/ACCELERATE Switch
or DISTANCE Switch .............................................. 64
Symptom 4: ICC System Is Not Cancelled When
the A/T Selector Lever Is In Other Than “D” and “M” ... 64
Symptom 5: Chime Does Not Sound ...................... 65
Symptom 6: Driving Force Is Hunting ..................... 66
Symptom 7: ICC System Frequently Cannot Detect
the Vehicle Ahead/ Detection Zone Is Short ........... 66
Symptom 8: The System Does Not Detect the Vehi-
cle Ahead at All ....................................................... 67
ELECTRICAL COMPONENT INSPECTION ............. 68
ICC Steering Switch ................................................ 68
ICC Brake Hold Relay ............................................. 68
ICC Brake Switch and Stop Lamp Switch ............... 68
REMOVAL AND INSTALLATION .............................. 69
ICC Sensor Integrated Unit ..................................... 69
REMOVAL ............................................................ 69
INSTALLATION .................................................... 69
ICC Steering Switch ................................................ 69

TROUBLE DIAGNOSIS - GENERAL DESCRIPTION
ACS-31
[ICC]
C
D
E
F
G
H
I
J
L
MA
B
ACS
Revision: 2006 January2006 M35/M45
THRTL SENSOR
[deg]NOTE:
This item is displayed, but cannot monitor.
SET DISTANCE
[SHOR/MID/LONG]
Indicates set distance memorized in ICC sensor integrated unit.
MAIN SW
[ON/OFF]
Indicates [ON/OFF] status as judged from ICC steering switch signal (ECM
transmits ICC steering switch signal through CAN communication).
SET/COAST SW
[ON/OFF]
Indicates [ON/OFF] status as judged from ICC steering switch signal (ECM
transmits ICC steering switch signal through CAN communication).
CANCEL SW
[ON/OFF]
Indicates [ON/OFF] status as judged from ICC steering switch signal (ECM
transmits ICC steering switch signal through CAN communication).
RESUME/ACC SW
[ON/OFF]
Indicates [ON/OFF] status as judged from ICC steering switch signal (ECM
transmits ICC steering switch signal through CAN communication).
DISTANCE SW
[ON/OFF]
Indicates [ON/OFF] status as judged from ICC steering switch signal (ECM
transmits ICC steering switch signal through CAN communication).
CRUISE OPE
[ON/OFF]
Indicates whether controlling or not (ON means “controlling”).
BRAKE SW
[ON/OFF]
Indicates [ON/OFF] status as judged from ICC brake switch signal (ECM
transmits ICC brake switch signal through CAN communication).
STOP LAMP SW
[ON/OFF]
Indicates [ON/OFF] status as judged from stop lamp switch signal (ECM
transmits stop lamp switch signal through CAN communication).
CRUISE LAMP
[ON/OFF]
Indicates [ON/OFF] status of MAIN switch indicator lamp output.
CLUTCH SW SIG
[ON/OFF]
NOTE:
This item is displayed, but cannot monitor.
NP SW SIG
[ON/OFF]
NOTE:
This item is displayed, but cannot monitor.
STP LMP DRIVE
[ON/OFF]
Indicates [ON/OFF] status of ICC brake hold relay drive output.
PWR SUP MONI
[V]
Indicates IGN voltage input by ICC sensor integrated unit.
IDLE SW
[ON/OFF]
Indicates [ON/OFF] status of idle switch read from ICC sensor integrated
unit through CAN communication (ECM transmits ON/OFF status through
CAN communication).
OWN VHCL
[ON/OFF]
Indicates [ON/OFF] status of own vehicle indicator output.
VHCL AHEAD
[ON/OFF]
Indicates [ON/OFF] status of vehicle ahead detection indicator output.
ICC WARNING
[ON/OFF]
Indicates [ON/OFF] status of ICC system warning lamp output.
BUZZER O/P
[ON/OFF]
Indicates [ON/OFF] status of ICC warning chime output.
ENGINE RPM
[rpm]
Indicates engine speed read from ICC sensor integrated unit through CAN
communication (ECM transmits engine speed through CAN communica-
tion).
WIPER SW
[OFF/LOW/HIGH]
Indicates wiper [OFF/LOW/HIGH] status (BCM transmits front wiper request
signal through CAN communication).
YAW R AT E
[deg/s]
NOTE:
This item is displayed, but cannot monitor.
D RANGE SW
[ON/OFF]
Indicates [ON/OFF] status of “D” and “M” positions read from ICC sensor
integrated unit through CAN communication; ON when position “D” and “M”
(TCM transmits A/T position indicator lamp signal through CAN communi-
cation). Monitored Item [unit]MAIN
SIGNALSSELEC-
TION FROM
MENUDescription

TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
ACS-39
[ICC]
C
D
E
F
G
H
I
J
L
MA
B
ACS
Revision: 2006 January2006 M35/M45
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMSPFP:25962
Diagnostic Trouble Code (DTC) ChartNKS004CZ
: Applicable
DTC
No.CONSULT-II
screen termsICC
system
warning
lampFail-safe
Malfunctions detected where...Refer-
ence
page Vehicle-
to-
vehicle
distance
control
modeConven-
tional
(fixed
speed)
cruise
control
modeBrake
assist
(with
preview
function)
0CONTROL UNIT
[C1A00]
ICC sensor integrated unit internal
malfunction.ACS-41
1POWER SUPPLY CIR
[C1A01]
ICC sensor integrated unit power
supply voltage is excessively low
(less than 8V).ACS-41
2POWER SUPPLY CIR 2
[C1A02]
ICC sensor integrated unit power
supply voltage is excessively high
(more than 19V).ACS-41
3VHCL SPEED SE CIRC
[C1A03]
Wheel sensor malfunction.
ABS actuator and electric unit
(control unit) malfunction.
A/T vehicle speed sensor mal-
function.
TCM malfunction.
ICC sensor integrated unit mal-
function.ACS-42
4ABS/TCS/VDC CIRC
[C1A04]VDC/TCS/ABS system malfunc-
tion.ACS-42
5BRAKE SW/STOP L SW
[C1A05]
Stop lamp switch harness is open
or shorted.
Stop lamp switch is stuck to OFF.
ICC brake switch or stop lamp
switch is stuck to ON.
ECM malfunction.
ABS actuator and electric unit
(control unit) malfunction.ACS-43
6OPERATION SW CIRC
[C1A06]
ICC steering switch harness or
spiral cable is open or shorted.
ICC steering switch malfunction.ACS-47
12LASER BEAM OFFCNTR
[C1A12]Laser beam of ICC sensor inte-
grated unit is off the aiming point.ACS-48
13STOP LAMP RLY FIX
[C1A13]
Normally open terminal of ICC
brake hold relay is stuck.
Improper installation of ICC brake
switch or stop lamp switch.
ICC brake switch malfunction.
ECM malfunction.
ABS actuator and electric unit
(control unit) malfunction.ACS-49

ACS-50
[ICC]
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
Revision: 2006 January2006 M35/M45
6. CHECK STOP LAMP ILLUMINATION
1. Turn ignition switch OFF.
2. Disconnect ICC brake hold relay.
3. Connect stop lamp switch connector.
4. Check if stop lamp is turned ON when depressing brake pedal.
OK or NG
OK >> GO TO 7.
NG >> 1. Repair or replace stop lamp circuit.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system
again.
7. CHECK HARNESS BETWEEN STOP LAMP SWITCH AND ECM
1. Disconnect stop lamp switch connector and ECM connector.
2. Check continuity between stop lamp switch harness connector
(A) and ECM harness connector (B).
3. Check continuity between stop lamp switch harness connector
(A) and ground.
OK or NG
OK >> GO TO 8.
NG >> 1. Repair or replace harness between stop lamp switch and ECM.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system
again.
8. CHECK ICC BRAKE HOLD RELAY CIRCUIT
1. Connect ICC brake hold relay and ECM connector.
2. When brake pedal is not depressed, make sure that stop lamp does not illuminate.
OK or NG
OK >> GO TO 10.
NG >> GO TO 9.
9. CHECK ICC BRAKE HOLD RELAY
1. Disconnect ICC brake hold relay.
2. Check ICC brake hold relay. Refer to ACS-68, "
ICC Brake Hold Relay" .
OK or NG
OK >> GO TO 10.
NG >> 1. Replace ICC brake hold relay.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system
again.
AB
Continuity
Connector Terminal Connector Terminal
E124 2 M71 101 Yes
A
GroundContinuity
Connector Terminal
E124 2 No
PKIC0927E

TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
ACS-51
[ICC]
C
D
E
F
G
H
I
J
L
MA
B
ACS
Revision: 2006 January2006 M35/M45
10. PERFORM ECM SELF-DIAGNOSIS
With CONSULT-II
1. Perform “ENGINE” self-diagnosis. Refer to EC-133, "
CONSULT-II Function (ENGINE)" (for VQ35DE) or
EC-846, "
CONSULT-II Function (ENGINE)" (for VK45DE).
2. Check if malfunction is indicated.
Is malfunction indicated?
YES >> 1. Repair or replace applicable item.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system
again.
NO >> 1. Replace ICC sensor integrated unit, and adjust laser beam aiming.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system
again.
11 . CHECK HARNESS BETWEEN ICC SENSOR INTEGRATED UNIT AND ICC BRAKE HOLD RELAY
1. Turn ignition switch OFF.
2. Disconnect ICC sensor integrated unit connector and ICC brake hold relay.
3. Check continuity between ICC sensor integrated unit harness
connector (A) and ICC brake hold relay harness connector (B).
4. Check continuity between ICC sensor integrated unit harness
connector (A) and ground.
OK or NG
OK >> GO TO 12.
NG >> 1. Repair harness between ICC sensor integrated unit and ICC brake hold relay.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system
again.
12. CHECK ICC BRAKE HOLD RELAY GROUND CIRCUIT
Check continuity between ICC brake hold relay harness connector
and ground.
OK or NG
OK >> GO TO 13.
NG >> 1. Repair or replace harness between ICC brake hold
relay and ground.
2. Erase DTC and perform ICC system running test.
Then perform self-diagnosis of ICC system again.
AB
Continuity
Connector Terminal Connector Terminal
E61 2 E80 2 Yes
A
GroundContinuity
Connector Terminal
E61 2 No
PKIB9338E
ICC brake hold relay
connectorTerminal
GroundContinuity
E80 1 Yes
PKIB9341E

ACS-52
[ICC]
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
Revision: 2006 January2006 M35/M45
13. CHECK ICC SENSOR INTEGRATED UNIT STANDARD VOLTAGE
With CONSULT-II
1. Connect ICC sensor integrated unit connector.
2. Turn ignition switch ON.
3. Perform “ACTIVE TEST” (“STOP LAMP”: “STP LMP DRIVE
ON”) with CONSULT-II, check voltage between ICC brake hold
relay harness connector and ground.
OK or NG
OK >> GO TO 14.
NG >> 1. Replace ICC sensor integrated unit, and adjust laser beam aiming.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system
again.
14. CHECK ICC BRAKE HOLD RELAY POWER SUPPLY CIRCUIT
1. Turn ignition switch ON.
2. Check voltage between ICC brake hold relay harness connector
and ground.
OK or NG
OK >> GO TO 15.
NG >> 1. Repair or replace harness or fuse.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system
again.
Terminals
ConditionVoltage
(Approx.) (+)
(–)
ICC brake hold
relay connectorTerminal
E80 2 GroundDuring
“ACTIVE TEST”12 V
PKIB9342E
Terminals
Voltage
(Approx.) (+)
(–)
ICC brake hold relay
connectorTe r m i n a l
E80 3 Ground Battery voltage
PKIB9343E

TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
ACS-53
[ICC]
C
D
E
F
G
H
I
J
L
MA
B
ACS
Revision: 2006 January2006 M35/M45
15. CHECK HARNESS BETWEEN ICC BRAKE HOLD RELAY AND ECM
1. Turn ignition switch OFF.
2. Disconnect ECM connector.
3. Check continuity between ICC brake hold relay harness connec-
tor (A) and ECM harness connector (B).
4. Check continuity between ICC brake hold relay harness connec-
tor (A) and ground.
OK or NG
OK >> GO TO 16.
NG >> 1. Repair harness between ICC brake hold relay and ECM.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system
again.
16. CHECK ICC BRAKE HOLD RELAY
With CONSULT-II
1. Connect ECM connector and ICC brake hold relay.
2. Disconnect stop lamp switch connector.
3. Perform “ACTIVE TEST” (“STOP LAMP”) with CONSULT-II, and make sure that stop lamp is illuminated.
OK or NG
OK >> GO TO 17.
NG >> 1. Replace ICC brake hold relay.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system
again.
17. CHECK STOP LAMP SWITCH WITH ABS DATA MONITOR
With CONSULT-II
With “ABS” “DATA MONITOR”, check if “STOP LAMP SW” are operates normally.
OK or NG
OK >> GO TO 18.
NG >> GO TO 20.
18. PERFORM ECM SELF-DIAGNOSIS
With CONSULT-II
1. Perform “ENGINE”self-diagnosis. Refer to EC-133, "
CONSULT-II Function (ENGINE)" (for VQ35DE) or
EC-846, "
CONSULT-II Function (ENGINE)" (for VK45DE).
2. Check if malfunction is indicated.
Is malfunction indicated?
YES >> 1. Repair or replace applicable item.
2. Erase DTC and perform ICC system running test. Then perform self-diagnosis of ICC system
again.
NO >> GO TO 19.
AB
Continuity
Connector Terminal Connector Terminal
E80 5 M71 101 Yes
A
GroundContinuity
Connector Terminal
E80 5 No
PKIB9344E

ACS-68
[ICC]
ELECTRICAL COMPONENT INSPECTION
Revision: 2006 January2006 M35/M45
ELECTRICAL COMPONENT INSPECTIONPFP:00000
ICC Steering SwitchNKS004DS
1. Disconnect ICC steering switch.
2. Check resistance between terminals by pressing each switch.
ICC Brake Hold RelayNKS004DT
Check continuity between ICC brake hold relay terminals.
ICC Brake Switch and Stop Lamp SwitchNKS004DU
Check continuity between ICC brake switch terminals.
Check continuity between stop lamp switch terminals.
Check each switch after adjusting brake pedal, refer to BR-6,
"BRAKE PEDAL" .
Terminals Switch Condition Resistance [k]
18 21MAINPressed Approx. 0
Released Approx. 5.5
CANCELPressed Approx. 0.3
Released Approx. 5.5
DISTANCEPressed Approx. 0.7
Released Approx. 5.5
SET/COASTPressed Approx. 1.4
Released Approx. 5.5
RESUME/ACCELERATE Pressed Approx. 2.6
Released Approx. 5.5
PKIB9345E
terminals condition Continuity
35Applying battery voltage to between ter-
minals 1 and 2Ye s
No battery voltage No
PKIB9346E
terminals Condition Continuity
12When brake pedal is depressed No
When brake pedal is released Yes
PKIC0597E
terminals Condition Continuity
12When brake pedal is depressed Yes
When brake pedal is released No
34When brake pedal is depressed Yes
When brake pedal is released No
PKIC0695E
