NISSAN X-TRAIL 2003 Electronic Repair Manual SERVICE DATA AND SPECIFICATIONS (SDS)
EM-95
[QR20DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
PISTON, PISTON RING AND PISTON PIN
Available Piston
Unit: mm (in) Main journal inner
diameter grade
(Without bearing)Grad

Page 2066 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual EM-96
[QR20DE]
SERVICE DATA AND SPECIFICATIONS (SDS)
Piston Ring
Unit: mm (in)
Piston Pin
Unit: mm (in)
CONNECTING ROD
Unit: mm (in)
*: After installing in connecting rodStandard Limit
Side clearanceT

Page 2067 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual SERVICE DATA AND SPECIFICATIONS (SDS)
EM-97
[QR20DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
CRANKSHAFT
Unit: mm (in)
Pin journal grade. “DP”Grade No. A
Grade No. B
Grade No. C
Grade No. D
Grade No. E
Grade No.

SERVICE DATA AND SPECIFICATIONS (SDS)
EM-97
[QR20DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
CRANKSHAFT
Unit: mm (in)
Pin journal grade. “DP”Grade No. A
Grade No. B
Grade No. C
Grade No. D
Grade No. E
Grade No. F
Grade No. G
Grade No. H
Grade No. J
Grade No. K
Grade No. L
Grade No. M
Grade No. N
Grade No. P
Grade No. R
Grade No. S
Grade No. T
Grade No. U44.974 - 44.973 (1.7706 - 1.7706)
44.973 - 44.972 (1.7706 - 1.7705)
44.972 - 44.971 (1.7705 - 1.7705)
44.971 - 44.970 (1.7705 - 1.7705)
44.970 - 44.969 (1.7705 - 1.7704)
44.969 - 44.968 (1.7704 - 1.7704)
44.968 - 44.967 (1.7704 - 1.7704)
44.967 - 44.966 (1.7704 - 1.7703)
44.966 - 44.965 (1.7703 - 1.7703)
44.965 - 44.964 (1.7703 - 1.7702)
44.964 - 44.963 (1.7702 - 1.7702)
44.963 - 44.962 (1.7702 - 1.7702)
44.962 - 44.961 (1.7702 - 1.7701)
44.961 - 44.960 (1.7701 - 1.7701)
44.960 - 44.959 (1.7701 - 1.7700)
44.959 - 44.958 (1.7700 - 1.7700)
44.958 - 44.957 (1.7700 - 1.7700)
44.957- 44.956 (1.7700 - 1.7699)
Main journal grade. “Dm”Grade No. A
Grade No. B
Grade No. C
Grade No. D
Grade No. E
Grade No. F
Grade No. G
Grade No. H
Grade No. J
Grade No. K
Grade No. L
Grade No. M
Grade No. N
Grade No. P
Grade No. R
Grade No. S
Grade No. T
Grade No. U
Grade No. V
Grade No. W
Grade No. X
Grade No. Y
Grade No. 4
Grade No. 754.979 - 54.978 (2.1645 - 2.1645)
54.978 - 54.977 (2.1645 - 2.1644)
54.977 - 54.976 (2.1644 - 2.1644)
54.976 - 54.975 (2.1644 - 2.1644)
54.975 - 54.974 (2.1644 - 2.1643)
54.974 - 54.973 (2.1643 - 2.1643)
54.973 - 54.972 (2.1643 - 2.1642)
54.972 - 54.971 (2.1642 - 2.1642)
54.971 - 54.970 (2.1642 - 2.1642)
54.970 - 54.969 (2.1642 - 2.1641)
54.969 - 54.968 (2.1641 - 2.1641)
54.968 - 54.967 (2.1641 - 2.1641)
54.967 - 54.966 (2.1641 - 2.1640)
54.966 - 54.965 (2.1640 - 2.1640)
54.965 - 54.964 (2.1640 - 2.1639)
54.964 - 54.963 (2.1639 - 2.1639)
54.963 - 54.962 (2.1639 - 2.1639)
54.962 - 54.961 (2.1639 - 2.1638)
54.961 - 54.960 (2.1638 - 2.1638)
54.960 - 54.959 (2.1638 - 2.1637)
54.959 - 54.958 (2.1637 - 2.1637)
54.958 - 54.957 (2.1637 - 2.1637)
54.957 - 54.956 (2.1637 - 2.1636)
54.956 - 54.955 (2.1636 - 2.1636)
Center distance “r” 40.11 - 40.19 (1.5791 - 1.5823)
Out-of-round (X-Y) Standard Less than 0.005 (0.0002)
Taper (A-B) Standard Less than 0.005 (0.0002)
Runout [TIR*] Limit Less than 0.10 (0.004)

Page 2068 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual EM-98
[QR20DE]
SERVICE DATA AND SPECIFICATIONS (SDS)
*: Total indicator reading
MAIN BEARING
Unit: mm (in) Free end playStandard 0.10 - 0.26 (0.0039 - 0.0102)
Limit 0.30 (0.0118)
SEM645SEM715
Grade nu

Page 2069 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual SERVICE DATA AND SPECIFICATIONS (SDS)
EM-99
[QR20DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
Undersize
Unit: mm (in)
Bearing Clearance
Unit: mm (in)
CONNECTING ROD BEARING
Undersize
Unit: mm (in)
Bearing Clearance

Page 2070 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual EM-100
[QR20DE]
SERVICE DATA AND SPECIFICATIONS (SDS)
Tightening Torque
EBS009RC
*1: Parts to be tightened in particular orders.
1)-: Order of tightening when tightening two or more times separately.

EM-100
[QR20DE]
SERVICE DATA AND SPECIFICATIONS (SDS)
Tightening Torque
EBS009RC
*1: Parts to be tightened in particular orders.
1)-: Order of tightening when tightening two or more times separately.
Unit: N·m (kg-m, ft-lb)
Unit: N·m (kg-m, in-lb)*2
Auto-tensioner19.6 - 23.5 (2.0 - 2.4, 15 - 17)
Mass air flow sensor 4.3 - 5.8 (0.44 - 0.59, 38 - 51) *2
Resonetor3.8 - 4.5 (0.39 - 0.46, 34 - 39)*2
Air cleaner case lower 3.8 - 4.5 (0.39 - 0.46, 34 - 39)*2
Air cleaner case lower bracket 12.7 - 15.7 (1.3 - 1.6, 10 - 11)
*1 Intake manifold17.6 - 21.6 (1.8 - 2.2, 13 - 15)
Intake manifold collector 17.6 - 21.6 (1.8 - 2.2, 13 - 15)
Intake manifold support 17.6 - 21.6 (1.8 - 2.2, 13 - 15)
Electric throttle control actuator 7.2 - 9.6 (0.74 - 0.98, 64 - 84) *2
EVAP canister purge volume control solenoid valve 4.3 - 5.8 (0.44 - 0.59, 38 - 51) *2
*1 Exhaust manifold39.2 - 44.1 (4.0 - 4.5, 29 - 32)
Exhaust manifold cover 5.1 - 6.5 (0.52 - 0.66, 46 - 57) *2
Heated oxygen sensor 40 - 50 (4.1 - 5.1, 30 - 36)
*1 Oil pan upper M6 bolt 8.1 - 9.5 (0.83 - 0.97, 72 - 84) *2
M8 bolt 19.6 - 23.5 (2.0 - 2.4, 15 - 17)
Oil pan upper to transmission joint bolts 39.2 - 46.1 , (4.0 - 4.7 , 29 - 34 )
*1 Oil pan lower6.4-7.5,(0.65-0.76,57-66)*2
Oil pan drain plug29.4 - 39.2 ( 3.0 - 4.0, 22 - 28)
Rear plate cover6.4-7.5,(0.65-0.76,57-66)*2
Oil strainer M6 bolt 8.1 - 9.5 (0.83 - 0.97, 72 - 84) *2
M8 bolt 19.6 - 23.5 ,(2.0 - 2.4 , 15 - 17)
Oil level gauge guide 19.6 - 23.5 (2.0 - 2.4, 15 - 17)
Ignition coil5.4 - 7.3 (0.55 - 0.75 , 48 - 64) *2
Spark plug19.6 - 29.4 (2.0 - 3.0, 15 - 21)
*1 Fuel tube1)
2)9.3 - 10.8 (0.95 - 1.1, 0.7 - 0.8) *2
20.6 - 26.5 (2.1 - 2.7, 16 - 19)
*1 Rocker cover1)
2)0.98 - 2.9 (0.1 - 0.3 , 9 - 25) *2
7.4-9.3,(0.75-0.95,66-82)*2
PCV valve1.96 - 2.94 ( 0.20 - 0.30 , 18 - 26) *2
Intake valve timing control solenoid valve 5.4 - 7.3 (0.55 - 0.75, 48 - 64) *2
*1 Intake valve timing control cover 11.8 - 13.7 (1.2 - 1.4, 9 - 10 )
Camshaft position sensor (PHASE) 5.4 - 7.3 (0.55 - 0.75 48 - 64) *2
Camshaft sprocket127- 157 (13.0 - 16.0, 94 - 115)
Chain tensioner6.4 - 7.5 (0.65 - 0.76, 57 - 66) *2
*1 Camshaft bracket 1)
2)
3)
4)2.0 (0.2, 17) *2
2.0 (0.2, 17) *2
5.9 (0.6, 52) *2
9.0 - 11.8 (0.92 - 1.20, 80 - 104) *2
Crankshaft pulley 1)
2)37.3 - 47.1 (3.8 - 4.8, 28 - 34)
60°-66°(Angle tightening)
*1 Front cover11.8 - 13.7 (1.2 - 1.4, 9 - 10)
Timing chain slack guide 15.7 - 17.7 (1.6 - 1.8, 12 - 13)
Timing chain tension guide 15.7 - 17.7 (1.6 - 1.8, 12 - 13)

Page 2071 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual SERVICE DATA AND SPECIFICATIONS (SDS)
EM-101
[QR20DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
Balancer unit timing chain tensioner 6.4 - 7.5 (0.65 - 0.76, 57 - 66) *2
*1 Balancer unit 1) 45.2 - 51.0 (4.6 - 5.2, 34

Page 2072 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual EM-102
[YD22DDTi]
PRECAUTIONS
[YD22DDTi]PRECAUTIONSPFP:00001
Precautions for Drain CoolantEBS00BNO
lDrain coolant when engine is cooled.
Precautions for Disconnecting Fuel PipingEBS00BNP
lBefore start

EM-102
[YD22DDTi]
PRECAUTIONS
[YD22DDTi]PRECAUTIONSPFP:00001
Precautions for Drain CoolantEBS00BNO
lDrain coolant when engine is cooled.
Precautions for Disconnecting Fuel PipingEBS00BNP
lBefore starting work, make sure no fire or spark producing items are in the work area.
lRelease fuel pressure before disassembly.
lAfter disconnecting pipes, plug openings to stop fuel leakage.
Precautions for Removal and DisassemblyEBS00BNQ
lWhen instructed to use special service tools, use the specified tools. Always be careful to work safely,
avoid forceful or uninstructed operations.
lExercise maximum care to avoid damage to mating or sliding surfaces.
lCover openings of engine system with tape or the equivalent, if necessary, to seal out foreign materials.
lMark and arrange disassembly parts in an organized way for easy troubleshooting and re-assembly.
lWhen loosening nuts and bolts, as a basic rule, start with the one furthest outside, then the one diagonally
opposite, and so on. If the order of loosening is specified, do exactly as specified.
Precautions for Inspection, Repair and ReplacementEBS00BNR
lBefore repairing or replacing, thoroughly inspect parts. Inspect new replacement parts in the same way,
and replace if necessary.
Precautions for Assembly and InstallationEBS00BNS
lUse torque wrench to tighten bolts or nuts.
lWhen tightening nuts and bolts, as a basic rule, equally tighten in several different steps starting with the
ones in center, then ones on inside and outside diagonally in this order. If the order of tightening is speci-
fied, do exactly as specified.
lReplace with new gasket, packing, oil seal or O-ring.
lThoroughly wash, clean, and air-blow each part. Carefully check oil or coolant passages for any restriction
and blockage.
lAvoid damaging sliding or mating surfaces. Completely remove foreign materials such as cloth lint or dust.
Before assembly, oil sliding surfaces well.
lRelease air within route after draining coolant.
lAfter repairing, start engine and increase engine speed to check coolant, fuel, oil, and exhaust systems
for leakage.
Parts Requiring Angular TighteningEBS00BNT
lUse an angle wrench for the final tightening of the following engine parts:
–Cylinder head bolts
–Main bearing cap bolts
–Connecting rod cap nuts
–Crankshaft pulley bolt (No angle wrench is required as the bolt flange is provided with notches for angular
tightening)
lDo not use a torque value for final tightening.
lThe torque value for these parts are for a preliminary step.
lEnsure thread and seat surfaces are clean and coated with engine oil.
