NISSAN X-TRAIL 2003 Electronic Repair Manual BULB SPECIFICATIONS
LT-67
C
D
E
F
G
H
I
J
L
MA
B
LT
BULB SPECIFICATIONSPFP:26297
HeadlampEKS003GS
Exterior LampEKS003GT
Interior Lamp/IlluminationEKS003GU
Item Wattage (W)
Low/High55 /60(H4)
Item Watt

Page 2466 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual LT-68
BULB SPECIFICATIONS

Page 2467 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual LU-1
ENGINE LUBRICATION SYSTEM
B ENGINE
CONTENTS
C
D
E
F
G
H
I
J
K
L
M
SECTION
A
LU
ENGINE LUBRICATION SYSTEM
QR20DE
PRECAUTIONS .......................................................... 3
Precaution

LU-1
ENGINE LUBRICATION SYSTEM
B ENGINE
CONTENTS
C
D
E
F
G
H
I
J
K
L
M
SECTION
A
LU
ENGINE LUBRICATION SYSTEM
QR20DE
PRECAUTIONS .......................................................... 3
Precautions For Liquid Gasket ................................. 3
REMOVAL OF LIQUID GASKET SEALING .......... 3
LIQUID GASKET APPLICATION PROCEDURE..... 3
PREPARATION ........................................................... 4
Special Service Tools ............................................... 4
LUBRICATION SYSTEM ............................................ 5
Lubrication Circuit .................................................... 5
System Drawing ....................................................... 6
ENGINE OIL ............................................................... 7
Inspection ................................................................. 7
OIL LEVEL AND MUDDINESS ............................. 7
OIL LEAKAGE ....................................................... 7
OIL PRESSURE CHECK ...................................... 7
Changing Engine Oil ................................................ 8
OIL FILTER ................................................................. 9
Removal and Installation .......................................... 9
REMOVAL ............................................................. 9
INSTALLATION ..................................................... 9
OIL PUMP ................................................................. 10
Removal and Installation ........................................ 10
Disassembly and Assembly ................................... 10
DISASSEMBLY ................................................... 10
INSPECTION AFTER DISASSEMBLY ............... 10
ASSEMBLY ......................................................... 12
OIL COOLER ............................................................ 13
Removal and Installation ........................................ 13
REMOVAL ........................................................... 13
INSPECTION ...................................................... 13
INSTALLATION ................................................... 13
SERVICE DATA AND SPECIFICATIONS (SDS) ...... 14
Standard and Limit ................................................. 14
OIL PRESSURE .................................................. 14
OIL PUMP ........................................................... 14
REGULATOR VALVE .......................................... 14
OIL CAPACITY .................................................... 14
TIGHTENING TORQUE ...................................... 14
YD22DDTi
PRECAUTIONS ........................................................ 15
Precautions For Liquid Gasket ............................... 15
REMOVAL OF LIQUID GASKET SEALING ........ 15
LIQUID GASKET APPLICATION PROCEDURE... 15
PREPARATION ......................................................... 16
Special Service Tools ............................................. 16
LUBRICATION SYSTEM .......................................... 17
Lubrication Circuit ................................................... 17
ENGINE OIL .............................................................. 18
Inspection ............................................................... 18
OIL LEVEL AND MUDDINESS ........................... 18
OIL LEAKAGE ..................................................... 18
OIL PRESSURE CHECK .................................... 18
Changing Engine Oil ............................................... 19
OIL FILTER ............................................................... 20
Removal and Installation ........................................ 20
REMOVAL ........................................................... 20
INSTALLATION ................................................... 21
OIL FILTER BRACKET ............................................. 22
Removal and Installation ........................................ 22
REMOVAL ........................................................... 22
INSTALLATION ................................................... 22
OIL PUMP ................................................................. 23
Removal and Installation ........................................ 23
Disassembly and Assembly .................................... 23
DISASSEMBLY ................................................... 23
INSPECTION AFTER DISASSEMBLY ................ 23
ASSEMBLY ......................................................... 24
OIL COOLER ............................................................ 25
Removal and Installation ........................................ 25
REMOVAL ........................................................... 25
INSPECTION ...................................................... 25
INSTALLATION ................................................... 25
SERVICE DATA AND SPECIFICATIONS (SDS) ...... 26
Standard and Limit .................................................. 26
OIL PRESSURE .................................................. 26
OIL PUMP ........................................................... 26
REGULATOR VALVE .......................................... 26

Page 2468 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual LU-2
OIL CAPACITY .................................................... 26
Tightening Torque ................................................... 26

Page 2469 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual PRECAUTIONS
LU-3
[QR20DE]
C
D
E
F
G
H
I
J
K
L
MA
LU
[QR20DE]PRECAUTIONSPFP:00001
Precautions For Liquid GasketEBS009SQ
REMOVAL OF LIQUID GASKET SEALING
lAfter removing the mounting bolts and nuts, dis

Page 2470 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual LU-4
[QR20DE]
PREPARATION
PREPARATION
PFP:00002
Special Service ToolsEBS009SR
Tool number
Tool nameDescription
ST25051001
Oil pressure gaugeMeasuring oil pressure
Maximum measuring range:
2,452 kPa (2

Page 2471 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual LUBRICATION SYSTEM
LU-5
[QR20DE]
C
D
E
F
G
H
I
J
K
L
MA
LU
LUBRICATION SYSTEMPFP:15010
Lubrication CircuitEBS009SS
PBIC0522E

Page 2472 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual LU-6
[QR20DE]
LUBRICATION SYSTEM
System Drawing
EBS009ST
PBIC0523E
