Page 1049 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual RADIATOR (ALLUMINUM TYPE)
CO-39
[YD22DDTi]
C
D
E
F
G
H
I
J
K
L
MA
CO
5. Make sure that the rim is completely crimped down.
6. Confirm that there is no leakage.
Refer to Inspection.
INSPECTION
1. Apply

Page 1050 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual CO-40
[YD22DDTi]
WATER PUMP
WAT ER PU M P
PFP:21020
Removal and InstallationEBS00BB4
WAR NIN G:
Never remove the radiator cap when the engine is hot. Serious burns could occur from high pressure
coola

Page 1051 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual WATER PUMP
CO-41
[YD22DDTi]
C
D
E
F
G
H
I
J
K
L
MA
CO
lInstall the water pump pulley with the front mark (painted white, used to prevent errors during assembly)
facing the front of the engine. Refer t

Page 1052 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual CO-42
[YD22DDTi]
THERMOSTAT AND WATER PIPING
THERMOSTAT AND WATER PIPING
PFP:21200
Removal and InstallationEBS00BK9
WAR NIN G:
Never remove the radiator cap when the engine is hot. Serious burns could

Page 1053 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual THERMOSTAT AND WATER PIPING
CO-43
[YD22DDTi]
C
D
E
F
G
H
I
J
K
L
MA
CO
INSPECTION AFTER REMOVAL
Thermostat
lPlace a string so that it is caught in the valves of the thermostat.
Immerse fully in a cont

Page 1054 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual CO-44
[YD22DDTi]
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
PFP:00030
Standard and LimitEBS00CU0
CAPACITY
THERMOSTAT
RADIATOR
Unit:kPa(bar,kg/cm2,psi)
Tightening Torqu

Page 1055 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual DI-1
DRIVER INFORMATION SYSTEM
K ELECTRICAL
CONTENTS
C
D
E
F
G
H
I
J
L
M
SECTION
A
B
DI
DRIVER INFORMATION SYSTEM
PRECAUTIONS .......................................................... 3
Precautions f

DI-1
DRIVER INFORMATION SYSTEM
K ELECTRICAL
CONTENTS
C
D
E
F
G
H
I
J
L
M
SECTION
A
B
DI
DRIVER INFORMATION SYSTEM
PRECAUTIONS .......................................................... 3
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” .................................................................. 3
Wiring Diagrams and Trouble Diagnosis .................. 3
COMBINATION METERS (LHD MODELS) ................ 4
System Description .................................................. 4
UNIFIED CONTROL METER ................................ 4
HOW TO CHANGE THE DISPLAY FOR ODO/
TRIP METER ........................................................ 4
POWER SUPPLY AND GROUND CIRCUIT ........ 4
WATER TEMPERATURE GAUGE ........................ 4
TACHOMETER ..................................................... 5
FUEL GAUGE ....................................................... 5
SPEEDOMETER ................................................... 5
Component Parts and Harness Connector Location..... 5
Combination Meter ................................................... 6
CHECK .................................................................. 6
Schematic ................................................................ 7
Wiring Diagram — METER — .................................. 8
Meter/Gauge Operation and Odo/Trip Meter Seg-
ment Check in Diagnosis Mode ............................. 10
DIAGNOSIS FUNCTION ..................................... 10
HOW TO ALTERNATE DIAGNOSIS MODE ....... 10
Trouble Diagnoses ................................................. 10
PRELIMINARY CHECK ...................................... 10
SYMPTOM CHART ..............................................11
Power Supply and Ground Circuit Check ............... 12
Inspection/Engine Speed Signal ............................ 12
Inspection/Water Temperature Gauge /Gasoline
Engine Models ....................................................... 13
Inspection/Water Temperature Gauge (Diesel
Engine Models) ...................................................... 13
Inspection/Vehicle speed signal ............................. 14
Inspection/Fuel Level Sensor Unit ......................... 15
FUEL LEVEL SENSOR UNIT ............................. 15
LOW-FUEL WARNING LAMP ............................. 15
The Fuel Gauge Pointer Fluctuates·Indicator
Wrong Value·or Varies. ........................................... 17
The Fuel Gauge Does Not Move to F-position. ...... 18The Fuel Gauge Does Not Work. ........................... 18
Low Fuel Warning Lamp Illuminate or Not Illuminate... 19
Electrical Components Inspection .......................... 19
FUEL LEVEL SENSOR UNIT CHECK / GASO-
LINE ENGINE MODELS ..................................... 19
FUEL LEVEL SENSOR UNIT CHECK / DIESEL
ENGINE MODELS EXCEPT FOR NORTHERN
EUROPE ............................................................. 19
FUEL LEVEL SENSOR UNIT CHECK / DIESEL
ENGINE MODELS FOR NORTHERN EUROPE... 20
THERMAL TRANSMITTER CHECK ................... 20
Removal and Installation for Combination Meter .... 21
Disassembly and Assembly for Combination Meter... 21
COMBINATION METERS (RHD MODELS) .............. 22
System Description ................................................. 22
UNIFIED CONTROL METER .............................. 22
HOW TO CHANGE THE DISPLAY FOR ODO/
TRIP METER ....................................................... 22
POWER SUPPLY AND GROUND CIRCUIT ....... 22
WATER TEMPERATURE GAUGE ...................... 22
TACHOMETER .................................................... 23
FUEL GAUGE ..................................................... 23
SPEEDOMETER ................................................. 23
Component Parts and Harness Connector Location... 23
Combination Meter ................................................. 24
CHECK ................................................................ 24
Schematic ............................................................... 25
Wiring Diagram — METER — ................................ 26
Meter/Gauge Operation and Odo/Trip Meter Seg-
ment Check in Diagnosis Mode .............................. 28
DIAGNOSIS FUNCTION ..................................... 28
HOW TO ALTERNATE DIAGNOSIS MODE ....... 28
Trouble Diagnoses ................................................. 28
PRELIMINARY CHECK ....................................... 28
SYMPTOM CHART ............................................. 29
Power Supply and Ground Circuit Check ............... 30
Inspection/Engine Speed Signal ............................. 30
Inspection/Water Temperature Gauge /Gasoline
Engine Models ........................................................ 31
Inspection/Water Temperature Gauge (Diesel

Page 1056 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual DI-2
Engine Models) ....................................................... 31
Inspection/Vehicle speed signal ............................. 32
Inspection/Fuel Level Sensor Unit ......................

DI-2
Engine Models) ....................................................... 31
Inspection/Vehicle speed signal ............................. 32
Inspection/Fuel Level Sensor Unit .......................... 33
FUEL LEVEL SENSOR UNIT .............................. 33
LOW-FUEL WARNING LAMP ............................. 33
The Fuel Gauge Pointer Fluctuates·Indicator
Wrong Value·or Varies. ........................................... 35
The Fuel Gauge Does Not Move to F-position. ...... 36
The Fuel Gauge Does Not Work. ........................... 36
Low Fuel Warning Lamp Illuminate or Not Illuminate... 37
Electrical Components Inspection .......................... 37
FUEL LEVEL SENSOR UNIT CHECK / GASO-
LINE ENGINE MODELS ...................................... 37
FUEL LEVEL SENSOR UNIT CHECK / DIESEL
ENGINE MODELS ............................................... 37
THERMAL TRANSMITTER CHECK ................... 38
Removal and Installation for Combination Meter .... 38
Disassembly and Assembly for Combination Meter... 38
WARNING LAMPS .................................................... 39
Schematic ............................................................... 39
Wiring Diagram — WARN —/ LHD Models ............ 40Wiring Diagram — WARN — / RHD Models ...........45
Electrical Components Inspection ...........................50
FUEL WARNING LAMP OPERATION CHECK ... 50
OIL PRESSURE SWITCH CHECK ......................50
DIODE CHECK ....................................................50
A/T INDICATOR .........................................................51
Wiring Diagram — AT/IND — .................................51
WARNING CHIME .....................................................52
System Description .................................................52
POWER SUPPLY AND GROUND CIRCUIT .......52
IGNITION KEY WARNING CHIME ......................52
LIGHT WARNING CHIME ...................................52
Component Parts and Harness Connector Location... 53
Wiring Diagram — CHIME — .................................54
Symptom Chart .......................................................56
Power Supply and Ground Circuit Check ...............56
Lighting Switch Input Signal Check .........................57
Key Switch Insert Signal Check ..............................57
Door Unlock Sensor Check .....................................58
Front Door Switch (driver side) Check ....................59
CLOCK ......................................................................60
Wiring Diagram — CLOCK — .................................60
