NISSAN X-TRAIL 2003 Electronic Repair Manual PRECAUTIONS
EM-103
[YD22DDTi]
C
D
E
F
G
H
I
J
K
L
MA
EM
Precautions for Liquid GasketEBS00BNU
REMOVAL OF LIQUID GASKET SEALING
lAfter removing the mounting bolts and nuts, disconnect and
remove the li

Page 2074 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual EM-104
[YD22DDTi]
PREPARATION
PREPARATION
PFP:00002
Special Service ToolsEBS00BNV
Tool number
Tool nameDescription
ST0501S000
Engine stand assembly
1 ST05011000
Engine stand
2 ST05012000
BaseDisassemb

Page 2075 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual PREPARATION
EM-105
[YD22DDTi]
C
D
E
F
G
H
I
J
K
L
MA
EM
KV101056S0
Ring gear stopper
1 KV10105630
Adapter
2 KV10105610
PlatePreventing crankshaft from rotating
a: 3 (0.12)
b: 6.4 (0.252)
c: 2.8 (0.110

Page 2076 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual EM-106
[YD22DDTi]
PREPARATION
Commercial Service Tools
EBS00BNW
KV11106010
Hexagon wrencha: 5 mm (0.20 in) (Face to face)
b: 20 mm (0.79 in)
KV11106020
Hexagon wrencha: 6 mm (0.24 in) (Face to face)
b

Page 2077 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual PREPARATION
EM-107
[YD22DDTi]
C
D
E
F
G
H
I
J
K
L
MA
EM
Tool nameDescription
Valve seat cutter set Finishing valve seat dimensions
Piston ring compressor Installing piston assembly into cylinder bore

Page 2078 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual EM-108
[YD22DDTi]
NOISE, VIBRATION, AND HARSHNESS (NVH) TROUBLESHOOTING
NOISE, VIBRATION, AND HARSHNESS (NVH) TROUBLESHOOTING
PFP:00003
NVH Troubleshooting —Engine NoiseEBS00BO5
SBIA0148E

Page 2079 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual NOISE, VIBRATION, AND HARSHNESS (NVH) TROUBLESHOOTING
EM-109
[YD22DDTi]
C
D
E
F
G
H
I
J
K
L
MA
EM
Use the Chart Below to Help You Find the Cause of the Symptom.EBS00BO6
1. Locate the area where noise

Page 2080 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual EM-110
[YD22DDTi]
DRIVE BELTS
DRIVE BELTS
PFP:02117
Checking Drive BeltsEBS00BNX
lBefore inspecting the engine, make sure the engine has cooled
down; wait approximately 30 minutes after the engine has

EM-110
[YD22DDTi]
DRIVE BELTS
DRIVE BELTS
PFP:02117
Checking Drive BeltsEBS00BNX
lBefore inspecting the engine, make sure the engine has cooled
down; wait approximately 30 minutes after the engine has been
stopped.
lVisually inspect all belts for wear, damage or cracks on contact-
ing surfaces and edge areas.
lWhen measuring deflection, apply 98 N (10 kg, 22 lb) at the
marked point ( ).
CAUTION:
lWhen checking belt deflection immediately after installa-
tion, first adjust it to the specified value. Then, after turn-
ing the crankshaft two turns or more, re-adjust to the
specified value to avoid variation in deflection between
pulleys.
lTighten idler pulley lock nut by hand and measure deflection without looseness.
Belt Deflection:
*: When engine is cold.
Tension AdjustmentEBS00BNY
lAdjust belts with the parts shown below.
CAUTION:
lWhen a new belt is installed as a replacement, adjust it to the value specified under “New” value
because of insufficient adaptability with pulley grooves.
lIf the belt deflection of the current belt is out of the “Limit for re-adjusting”, adjust to the
“Adjusted” value.
lWhen checking belt deflection immediately after installation, first adjust it to the specified value.
Then, after turning crankshaft two turns or more, re-adjust it to the specified value to avoid vari-
ation in deflection between pulleys.
lMake sure the belts are fully fitted into the pulley grooves during installation.
lHandle with care to avoid smearing the belts with oil or cooling water etc.
lDo not twist or bend the belts with strong force.
JEM249G
Applied beltBelt deflection with 98 N (10 kg, 22 lb) force applied* mm (in)
New Adjusted Limit for re-adjusting
Air conditioner compressor belt 4 - 5 (0.16 - 0.20) 6 - 7 (0.24 - 0.28) 8.5 (0.335)
Alternator and water pump belt 9.0 - 10.5 (0.354 - 0.413) 11.0 - 12.5 (0.433 - 0.492) 16.5 (0.650)
Applied belt Belt adjustment method
Air conditioner compressor belt Adjusting bolt on idler pulley
Alternator water pump belt Adjusting bolt on alternator
