NISSAN X-TRAIL 2003 Electronic Repair Manual DTC P1233 - P1234 SUCTION CONTROL VALVE
EC-775
[YD]
C
D
E
F
G
H
I
J
K
L
MA
EC
Diagnostic ProcedureEBS008XM
1.CHECK ECM OUTPUT SIGNAL CIRCUIT FOR OPEN AND SHORT
1. Turn ignition switch "OFF".
2. Discon

Page 1890 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual EC-776
[YD]
DTC P1233 - P1234 SUCTION CONTROL VALVE
Component Inspection
EBS008Z6
SUCTION CONTROL VALVE
1. Check continuity between fuel supply pump terminals 1 and 2, 3
and 4.
2. If NG, replace fuel

Page 1891 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual DTC P1301 - P1304 FUEL INJECTOR ADJUSTMENT RESISTOR
EC-777
[YD]
C
D
E
F
G
H
I
J
K
L
MA
EC
DTC P1301 - P1304 FUEL INJECTOR ADJUSTMENT RESISTORPFP:16600
DescriptionEBS008XN
The fuel injector adjustment

DTC P1301 - P1304 FUEL INJECTOR ADJUSTMENT RESISTOR
EC-777
[YD]
C
D
E
F
G
H
I
J
K
L
MA
EC
DTC P1301 - P1304 FUEL INJECTOR ADJUSTMENT RESISTORPFP:16600
DescriptionEBS008XN
The fuel injector adjustment resistor is built into the fuel injector. The resistance is constant and individual.
ECM uses the individual resistance to determine the fuel injection pulse.
ECM Terminals and Reference ValueEBS008XP
Specification data are reference values and are measured between each terminal and ground.
CAUTION:
Do not use ECM ground terminals when measuring input/output voltage. Doing so may result in dam-
age to the ECM's transistor. Use a ground other than ECM terminals, such as the ground.
On Board Diagnosis LogicEBS008XQ
DTC Confirmation ProcedureEBS008XR
WITH CONSULT-II
1. Turn ignition switch “ON” and wait at least 2 seconds.
2. Select “DATA MONITOR” mode with CONSULT-II.
3. Start engine and run it for at least 2 seconds at idle speed.
(If engine does not run, turn ignition switch to “START” for at
least 2 seconds.)
4. If DTC is detected, go toEC-779, "
Diagnostic Procedure".
TER-
MINAL
NO.WIRE
COLORITEM CONDITION DATA (DC Voltage)
A25 G/W Fuel injector's ground[Engine is running]
lWarm-up condition
lIdle speedApproximately 0V
B9 G/BFuel injector adjustment
resistor No.2
[Ignition switch "ON"]0.7 - 2.3V (0.2 - 4.8V)
(There is an individual differ-
ence in fuel injector adjust-
ment resistor.) B10 Y/BFuel injector adjustment
resistor No.4
B11 R/BFuel injector adjustment
resistor No.3
B12 W/BFuel injector adjustment
resistor No.1
DTC Malfunction is detected when .... Check Items (Possible cause)
P1301
lAn excessively high or low voltage from fuel injector
No.1 adjustment resistor is sent to ECMlHarness or connectors
(Injector adjustment resister circuit is open or
shorted.)
lFuel injector adjustment resistor P1302lAn excessively high or low voltage from fuel injector
No.2 adjustment resistor is sent to ECM
P1303
lAn excessively high or low voltage from fuel injector
No.3 adjustment resistor is sent to ECM
P1304
lAn excessively high or low voltage from fuel injector
No.4 adjustment resistor is sent to ECM
SEF817Y

Page 1892 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual EC-778
[YD]
DTC P1301 - P1304 FUEL INJECTOR ADJUSTMENT RESISTOR
Wiring Diagram
EBS008XS
TBWA0128E

Page 1893 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual DTC P1301 - P1304 FUEL INJECTOR ADJUSTMENT RESISTOR
EC-779
[YD]
C
D
E
F
G
H
I
J
K
L
MA
EC
Diagnostic ProcedureEBS008XT
1.CHECK FUEL INJECTOR ADJUSTMENT RESISTOR POWER SUPPLY CIRCUIT
1. Turn ignition s

Page 1894 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual EC-780
[YD]
DTC P1301 - P1304 FUEL INJECTOR ADJUSTMENT RESISTOR
5.CHECK INTERMITTENT INCIDENT
Refer toEC-699, "
TROUBLE DIAGNOSIS FOR INTERMITTENT INCIDENT".
>>INSPECTION END
Component InspectionEBS00

Page 1895 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual DTC P1305 FUEL LEAK
EC-781
[YD]
C
D
E
F
G
H
I
J
K
L
MA
EC
DTC P1305 FUEL LEAKPFP:17520
On Board Diagnosis LogicEBS004TX
DTC Confirmation ProcedureEBS004TY
WITH CONSULT-II
1. Turn ignition switch “ON

Page 1896 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual EC-782
[YD]
DTC P1305 FUEL LEAK
FUEL SUPPLY PUMP
Refer toEM-138, "FUEL SUPPLY PUMP".
