DTC P1180 FUEL TEMPERATURE SENSOR
EC-751
[YD]
C
D
E
F
G
H
I
J
K
L
MA
EC
DTC P1180 FUEL TEMPERATURE SENSORPFP:16700
DescriptionEBS004T2
Fuel temperature sensor is built in the fuel supply pump. The sensor detects the fuel temperature in the fuel
supply pump and calibrates the fuel injection amount change by fuel temperature.
CONSULT-II Reference Value in Data Monitor ModeEBS004T3
Remarks: Specification data are reference values.
ECM Terminals and Reference ValueEBS004T4
Specification data are reference values and are measured between each terminal and ground.
CAUTION:
Do not use ECM ground terminals when measuring input/output voltage. Doing so may result in dam-
age to the ECM's transistor. Use a ground other than ECM terminals, such as the ground.
On Board Diagnosis LogicEBS004T5
DTC Confirmation ProcedureEBS004T6
WITH CONSULT-II
1. Turn ignition switch “ON” and wait at least 2 seconds.
2. Select “DATA MONITOR” mode with CONSULT-II.
3. Start engine and run it for at least 2 seconds at idle speed.
(If engine does not run, turn ignition switch to “START” for at
least 2 seconds.)
4. If DTC is detected, go toEC-753, "
Diagnostic Procedure".
MONITOR ITEM CONDITION SPECIFICATION
FUEL TEMP SEN
lEngine: After warming up More than 40°C(104°F)
TER-
MINAL
NO.WIRE
COLORITEM CONDITION DATA (DC Voltage)
A12 PU Fuel temperature sensor[Engine is running]
lWarm-up conditionApproximately 0 - 4.8V
Output voltage varies with fuel
temperature
A23 B Sensor's ground[Engine is running]
lWarm-up condition
lIdle speedApproximately 0V
DTC Malfunction is detected when .... Check Items (Possible cause)
P1180
lAn excessively high or low voltage from the sensor
is sent to ECM.lHarness or connectors
(The sensor circuit is open or shorted.)
lFuel temperature sensor
SEF817Y
Page 1866 of 3066
EC-752
[YD]
DTC P1180 FUEL TEMPERATURE SENSOR
Wiring Diagram
EBS004T7
TBWA0116E
Page 1867 of 3066
![NISSAN X-TRAIL 2003 Electronic Repair Manual DTC P1180 FUEL TEMPERATURE SENSOR
EC-753
[YD]
C
D
E
F
G
H
I
J
K
L
MA
EC
Diagnostic ProcedureEBS004T8
1.CHECK FUEL TEMPERATURE SENSOR POWER SUPPLY CIRCUIT
1. Turn ignition switch “OFF”.
2. Disconne NISSAN X-TRAIL 2003 Electronic Repair Manual DTC P1180 FUEL TEMPERATURE SENSOR
EC-753
[YD]
C
D
E
F
G
H
I
J
K
L
MA
EC
Diagnostic ProcedureEBS004T8
1.CHECK FUEL TEMPERATURE SENSOR POWER SUPPLY CIRCUIT
1. Turn ignition switch “OFF”.
2. Disconne](/manual-img/5/57402/w960_57402-1866.png)
DTC P1180 FUEL TEMPERATURE SENSOR
EC-753
[YD]
C
D
E
F
G
H
I
J
K
L
MA
EC
Diagnostic ProcedureEBS004T8
1.CHECK FUEL TEMPERATURE SENSOR POWER SUPPLY CIRCUIT
1. Turn ignition switch “OFF”.
2. Disconnect fuel temperature sensor harness connector.
3. Turn ignition switch “ON”.
4. Check voltage between fuel temperature sensor terminal 1 and
engine ground.
OK or NG
OK >> GO TO 2.
NG >> Repair open circuit or short to ground or short to power
in harness or connectors.
2.CHECK FUEL TEMPERATURE SENSOR GROUND CIRCUIT FOR OPEN AND SHORT
1. Turn ignition switch "ON".
2. Check harness continuity between fuel temperature sensor terminal 2 and ground. Refer to Wiring Dia-
gram.
3. Also check harness for short to ground and short to power.
OK or NG
OK >> GO TO 4.
NG >> GO TO 3.
3.DETECT MALFUNCTIONING PART
Check harness for open or short to between ECM and fuel temperature sensor.
>> Repair open circuit or short to ground or short to power in harness or connectors.
4.CHECK INTERMITTENT INCIDENT
Refer toEC-699, "
TROUBLE DIAGNOSIS FOR INTERMITTENT INCIDENT".
OK or NG
OK >> Replace fuel supply pump.
NG >> Repair or replace.
Removal and InstallationEBS008Z2
FUEL SUPPLY PUMP
Refer toEM-138, "FUEL SUPPLY PUMP".
PBIB0464E
Voltage: Approximately 5V
PBIB0420E
Continuity should exist.
Page 1868 of 3066
![NISSAN X-TRAIL 2003 Electronic Repair Manual EC-754
[YD]
DTC P1216 EDU
DTC P1216 EDU
PFP:22710
DescriptionEBS008X9
The ECM sends the fuel injection signal to EDU (Electronic Drive Unit). Then the EDU sends ON signals to
fuel injectors to operate NISSAN X-TRAIL 2003 Electronic Repair Manual EC-754
[YD]
DTC P1216 EDU
DTC P1216 EDU
PFP:22710
DescriptionEBS008X9
The ECM sends the fuel injection signal to EDU (Electronic Drive Unit). Then the EDU sends ON signals to
fuel injectors to operate](/manual-img/5/57402/w960_57402-1867.png)
EC-754
[YD]
DTC P1216 EDU
DTC P1216 EDU
PFP:22710
DescriptionEBS008X9
The ECM sends the fuel injection signal to EDU (Electronic Drive Unit). Then the EDU sends ON signals to
fuel injectors to operate them.
The EDU monitors injector ground circuit and sends the feed back signal to the ECM.
ECM Terminals and Reference ValueEBS008XB
Specification data are reference values and are measured between each terminal and ground.
CAUTION:
Do not use ECM ground terminals when measuring input/output voltage. Doing so may result in dam-
age to the ECM's transistor. Use a ground other than ECM terminals, such as the ground.
PBIB0482E
TERMI-
NAL
NO.WIRE
COLORITEM CONDITIONDATA
(DC Voltage and Pulse Signal)
A1
A2
A3
A4L/W
Y/PU
PU
YEDU drive No. 2
EDU drive No. 4
EDU drive No. 3
EDU drive No. 1[Engine is running]
lWarm-up condition
lIdle speed0-4V
[Engine is running]
lWarm-up condition
lEngine speed is 2,000 rpm0-4V
A8
A9R
RPower supply for ECM[Ignition switch "ON"]BATTERY VOLTAGE
(11 - 14V)
A29 W/PU EDU injector check signal[Engine is running]
lWarm-up condition
lIdle speed1-5V
PBIB0387E
PBIB0388E
PBIB0391E
Page 1869 of 3066
![NISSAN X-TRAIL 2003 Electronic Repair Manual DTC P1216 EDU
EC-755
[YD]
C
D
E
F
G
H
I
J
K
L
MA
EC
: Average voltage for pulse signal (Actual pulse signal can be confirmed by oscilloscope.)
On Board Diagnosis LogicEBS008XC
DTC Confirmation Procedu NISSAN X-TRAIL 2003 Electronic Repair Manual DTC P1216 EDU
EC-755
[YD]
C
D
E
F
G
H
I
J
K
L
MA
EC
: Average voltage for pulse signal (Actual pulse signal can be confirmed by oscilloscope.)
On Board Diagnosis LogicEBS008XC
DTC Confirmation Procedu](/manual-img/5/57402/w960_57402-1868.png)
DTC P1216 EDU
EC-755
[YD]
C
D
E
F
G
H
I
J
K
L
MA
EC
: Average voltage for pulse signal (Actual pulse signal can be confirmed by oscilloscope.)
On Board Diagnosis LogicEBS008XC
DTC Confirmation ProcedureEBS008XD
WITH CONSULT-II
1. Turn ignition switch “ON” and wait at least 2 seconds.
2. Select “DATA MONITOR” mode with CONSULT-II.
3. Start engine and run it for at least 2 seconds at idle speed.
(If engine does not run, turn ignition switch to “START” for at
least 2 seconds.)
4. If DTC is detected, go toEC-758, "
Diagnostic Procedure".
[Engine is running]
lWarm-up condition
lEngine speed is 2,000 rpm1-5V
D24
D26G
GECM relay (self-shutoff)[Ignition switch “ON”]
[Ignition switch “OFF”]
lFor a few seconds after turning ignition
switch "OFF"Approximately 0V
[Ignition switch “OFF”]
lA few seconds passed after turning ignition
switch "OFF"BATTERY VOLTAGE
(11 - 14V) TERMI-
NAL
NO.WIRE
COLORITEM CONDITIONDATA
(DC Voltage and Pulse Signal)
PBIB0392E
DTC Malfunction is detected when .... Check Items (Possible cause)
P1216
lEDU feed back signal is not normal pattern.lHarness or connectors
(Injector drive circuit is open or shorted.)
lElectronic drive unit
lFuel injectors
SEF817Y
Page 1870 of 3066
EC-756
[YD]
DTC P1216 EDU
Wiring Diagram
EBS008XE
TBWA0118E
Page 1871 of 3066
DTC P1216 EDU
EC-757
[YD]
C
D
E
F
G
H
I
J
K
L
MA
EC
TBWA0119E
Page 1872 of 3066
![NISSAN X-TRAIL 2003 Electronic Repair Manual EC-758
[YD]
DTC P1216 EDU
Diagnostic Procedure
EBS008XF
1.INSPECTION START
1. Turn ignition switch "START".
2. Is any cylinder ignited?
OK or NG
OK >> GO TO 5.
NG >> GO TO 2.
2.CHECK EDU POWER SUPPLY NISSAN X-TRAIL 2003 Electronic Repair Manual EC-758
[YD]
DTC P1216 EDU
Diagnostic Procedure
EBS008XF
1.INSPECTION START
1. Turn ignition switch "START".
2. Is any cylinder ignited?
OK or NG
OK >> GO TO 5.
NG >> GO TO 2.
2.CHECK EDU POWER SUPPLY](/manual-img/5/57402/w960_57402-1871.png)
EC-758
[YD]
DTC P1216 EDU
Diagnostic Procedure
EBS008XF
1.INSPECTION START
1. Turn ignition switch "START".
2. Is any cylinder ignited?
OK or NG
OK >> GO TO 5.
NG >> GO TO 2.
2.CHECK EDU POWER SUPPLY CIRCUIT
