Page 2825 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual PREPARATION RFD-3 C E F G H I J K L MA B RFD PREPARATIONPFP:00002 Special Service ToolsEDS00057 To o l n a m e Tool numberDescription Drift ST27861000 a: 62 mm (2.44 in) dia. b: 52 mm (2.05 in) dia.In

Page 2826 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual RFD-4 PREPARATION Drift ST33230000 a: 51 mm (2.01 in) dia. b: 41 mm (1.61 in) dia. c: 28.5 mm (1.122 in) dia.Installing pinion front bearing outer race Drift ST23860000 a: 38 mm (1.50 in) dia. b: 33 m

Page 2827 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual PREPARATION RFD-5 C E F G H I J K L MA B RFD Commercial Service ToolsEDS000HY drive pinion gear socket KV38108500lMeasuring preload torque lRemoving and installing pinion nut Pinion nut wrench KV38108

Page 2828 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual RFD-6 OIL OIL PFP:00024 InspectionEDS00059 FLUID LEAKAGE AND OIL LEVEL 1. Check for fluid leakage and for proper oil level. 2. Install the filler plug to the final drive, and tighten to the specified

Page 2829 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual REAR FINAL DRIVE SYSTEM RFD-7 C E F G H I J K L MA B RFD REAR FINAL DRIVE SYSTEMPFP:38300 Sectional ViewEDS0005A SDIA0141E

Page 2830 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual RFD-8 FRONT OIL SEAL FRONT OIL SEAL PFP:38189 Removal and InstallationEDS0005B REMOVAL 1. Remove propeller shaft. Refer toPR-3, "REMOVAL". 2. Paint mating marks on the final drive companion flange and

Page 2831 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual SIDE OIL SEAL RFD-9 C E F G H I J K L MA B RFD SIDE OIL SEALPFP:38343 Removal and InstallationEDS000DF REMOVAL 1. Remove drive shaft. Refer toRAX-9, "Removal". 2. Using a slotted screwdriver as shown

Page 2832 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual RFD-10 REAR COVER GASKET REAR COVER GASKET PFP:38320 ReplacementEDS0005D lApply a continuous bead of Three bond 1217 or equivalent around the gear carrier mating surface on the coupling cover as shown
