Page 2953 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual SPIRAL CABLE SRS-31 C D E F G I J K L MA B SRS SPIRAL CABLEPFP:25554 Removal and InstallationEHS0 00 D8 REMOVAL CAUTION: lBefore servicing SRS, turn the ignition switch off, disconnect the battery gro

Page 2954 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual SRS-32 SPIRAL CABLE 7. Remove the spiral cable fixing screws, and while pushing the upper plastic tab, remove the spiral cable. CAUTION: lDo not attempt to disassemble spiral cable. lDo not apply lubr

Page 2955 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual FRONT PASSENGER AIR BAG MODULE SRS-33 C D E F G I J K L MA B SRS FRONT PASSENGER AIR BAG MODULEPFP:K8515 Removal and InstallationEHS0 00 D9 REMOVAL CAUTION: lBefore servicing SRS, turn the ignition sw

Page 2956 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual SRS-34 FRONT PASSENGER AIR BAG MODULE lAfter the work is completed, perform self-diagnosis to check that no malfunction is detected. Refer toSRS-15, " SRS Operation Check".

Page 2957 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual FRONT SIDE AIR BAG MODULE SRS-35 C D E F G I J K L MA B SRS FRONT SIDE AIR BAG MODULEPFP:K8EH0 Removal and InstallationEHS000DA REMOVAL CAUTION: lBefore servicing SRS, turn the ignition switch off, di

Page 2958 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual SRS-36 FRONT SIDE AIR BAG MODULE INSTALLATION To install, reverse the removal procedure. CAUTION: lAlways work from the rear of the front side air bag module. lAfter the work is completed, perform sel

Page 2959 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual SIDE AIR BAG (SATELLITE) SENSOR SRS-37 C D E F G I J K L MA B SRS SIDE AIR BAG (SATELLITE) SENSORPFP:98830 Removal and InstallationEHS000DB REMOVAL CAUTION: lBefore servicing SRS, turn the ignition sw

Page 2960 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual SRS-38 FRONT SEAT BELT PRE-TENSIONER FRONTSEATBELTPRE-TENSIONER PFP:86884 Removal and InstallationEHS000DC To removal and installation procedures, refer toSB-3, "Removal and Installation of Front Seat
