Page 2185 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual SERVICE DATA AND SPECIFICATIONS (SDS) EM-215 [YD22DDTi] C D E F G H I J K L MA EM CAMSHAFT AND CAMSHAFT BEARING Unit: mm (in) CYLINDER BLOCK Unit: mm (in) Depth (H)Intake 8.83 - 9.13 (0.3476 - 0.3594)

Page 2186 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual EM-216 [YD22DDTi] SERVICE DATA AND SPECIFICATIONS (SDS) PISTON, PISTON RING AND PISTON PIN Available Piston Unit: mm (in) Piston Ring Unit: mm (in) Piston Pin Unit: mm (in) *: Values measured at ambie

Page 2187 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual SERVICE DATA AND SPECIFICATIONS (SDS) EM-217 [YD22DDTi] C D E F G H I J K L MA EMCONNCTING ROD Unit: mm (in) *: After installing in connecting rod CRANKSHAFT Unit: mm (in) *: Total indicator readingCe

Page 2188 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual EM-218 [YD22DDTi] SERVICE DATA AND SPECIFICATIONS (SDS) AVAILABLE MAIN BEARING Unit: mm (in) Under size Unit: mm (in) AVAILABLE CONNECTING ROD BEARING Connecting Rod Bearing Unit: mm (in) Under size U

Page 2189 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual SERVICE DATA AND SPECIFICATIONS (SDS) EM-219 [YD22DDTi] C D E F G H I J K L MA EM MISCELLANEOUS COMPONENTS Flywheel Unit: mm (in) *: Total indicator reading Bearing Clearance Unit: mm (in) Tightening

Page 2190 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual EM-220 [YD22DDTi] SERVICE DATA AND SPECIFICATIONS (SDS) M8 bolt 16.0- 19.0 (1.6 - 1.9, 12 - 14) Injection tube Nozzle side 21.6 - 24.5 (2.2 - 2.5, 16 - 18) Pump side 26.5 - 29.4 (2.7 - 3.0, 20 - 21) N

Page 2191 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual EX-1 EXHAUST SYSTEM B ENGINE CONTENTS C D E F G H I J K L M SECTION A EX EXHAUST SYSTEM EXHAUST SYSTEM ................................................... 2 Checking Exhaust System ...................

Page 2192 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual EX-2 EXHAUST SYSTEM EXHAUST SYSTEM PFP:20100 Checking Exhaust SystemEBS00AZ6 Check exhaust pipes, muffler and mounting for improper attachment, leaks, cracks, damage or deterioration. Removal and Inst
