Page 185 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual DTC P0734 A/T 4TH GEAR FUNCTION AT-179 [EURO-OBD] D E F G H I J K L MA B AT Component InspectionECS004RP SOLENOID VALVES lFor removal, refer toAT-454, "REMOVAL". Resistance Check lCheck resistance bet

Page 186 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual AT-180 [EURO-OBD] DTC P0734 A/T 4TH GEAR FUNCTION Operation Check lCheck solenoid valve by listening for its operating sound while applying battery voltage to the terminal and ground. SCIA0759E

Page 187 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual DTCP0740TORQUECONVERTERCLUTCHSOLENOIDVALVE AT-181 [EURO-OBD] D E F G H I J K L MA B AT DTC P0740 TORQUE CONVERTER CLUTCH SOLENOID VALVEPFP:31940 DescriptionECS004RQ The torque converter clutch solenoi

Page 188 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual AT-182 [EURO-OBD] DTC P0740 TORQUE CONVERTER CLUTCH SOLENOID VALVE NOTE: If “DIAGNOSTIC TROUBLE CODE CONFIRMATION PROCE- DURE” has been previously conducted, always turn ignition switch “OFF”

Page 189 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual DTCP0740TORQUECONVERTERCLUTCHSOLENOIDVALVE AT-183 [EURO-OBD] D E F G H I J K L MA B AT Wiring Diagram — AT — TCVECS004RR TCWA0043E

Page 190 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual AT-184 [EURO-OBD] DTC P0740 TORQUE CONVERTER CLUTCH SOLENOID VALVE Diagnostic Procedure ECS004RS 1.CHECK VALVE RESISTANCE 1. Turn ignition switch to “OFF” position. 2. Disconnect terminal cord ass

Page 191 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual DTCP0740TORQUECONVERTERCLUTCHSOLENOIDVALVE AT-185 [EURO-OBD] D E F G H I J K L MA B AT Component InspectionECS004RT TORQUE CONVERTER CLUTCH SOLENOID VALVE lFor removal, refer toAT-454, "REMOVAL". Resi

Page 192 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual AT-186 [EURO-OBD] DTC P0745 LINE PRESSURE SOLENOID VALVE DTC P0745 LINE PRESSURE SOLENOID VALVE PFP:31940 DescriptionECS004RU The line pressure solenoid valve regulates the oil pump discharge pressure
