AIR CLEANER AND AIR DUCTPFP:16500
Removal and InstallationEBS009QS
REMOVAL
1. Remove mass air flow sensor harness clamp.
2. Remove harness connector from mass air flow sensor.
3. Remove air duct, air cleaner case/ mass air flow sensor.
lAdd marks as necessary for easier installation.
4. Remove mass air flow sensor from air cleaner case.
CAUTION:
Handle mass air flow sensor with following cares.
lDo not shock it.
lDo not disassembly it.
lDo not touch its sensor.
5. Remove resonator in fender lifting left fender protector.
KBIA0231E
1 Air cleaner case upper 2 Clamp 3 Air duct
4 Bracket 5 Mass air flow sensor 6 O-ring
7 Grommet 8 Resonator 9 Mounting rubber
10 Air cleaner case lower 11 Air cleaner element
Page 1986 of 3066
EM-16
[QR20DE]
AIR CLEANER AND AIR DUCT
INSTALLATION
1. Attach each joint aligning marks put at removal. Screw clamps firmly.
2. Install in the reverse order of removal.
CHANGING AIR CLEANER ELEMENT
1. Remove clips and lift up air cleaner upper case.
2. Remove air cleaner element.
Page 1987 of 3066
INTAKE MANIFOLD
EM-17
[QR20DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
INTAKE MANIFOLDPFP:14003
Removal and InstallationEBS009QT
REMOVAL
WA RN ING:
To avoid the danger of being scalded, never drain the coolant when the engine is hot.
1. Remove mass air flow sensor harness connector from mass air flow sensor and clamp.
2. Release fuel pressure.
Refer toEC-34, "
FUEL PRESSURE RELEASE"(WITH EURO-OBD),EC-399, "FUEL PRESSURE
RELEASE"(WITHOUT EURO-OBD).
3. Remove air cleaner case and air duct assembly.
Refer toEM-15, "
Removal and Installation".
4. Drain coolant when engine is cooled. Refer toCO-9, "
DRAINING ENGINE COOLANT".
KBIA0232E
1 Bracket 2 PCV hose 3 Intake manifold collector
4 Gasket 5 Electric throttle control actuator 6 Intake manifold support
7EVAP canister purge volume control
solenoid valve8 Vacuum hose 9 Intake manifold
Page 1988 of 3066
![NISSAN X-TRAIL 2003 Electronic Repair Manual EM-18
[QR20DE]
INTAKE MANIFOLD
5. Disconnect fuel hose quick connector on engine side (The same
apply to the quick connector on vehicle side).
lUsing tool of quick connector release (here in after “ NISSAN X-TRAIL 2003 Electronic Repair Manual EM-18
[QR20DE]
INTAKE MANIFOLD
5. Disconnect fuel hose quick connector on engine side (The same
apply to the quick connector on vehicle side).
lUsing tool of quick connector release (here in after “](/manual-img/5/57402/w960_57402-1987.png)
EM-18
[QR20DE]
INTAKE MANIFOLD
5. Disconnect fuel hose quick connector on engine side (The same
apply to the quick connector on vehicle side).
lUsing tool of quick connector release (here in after “release”),
perform the following steps to disconnect quick connector.
a. Remove quick connector cap.
b. With the sleeve side of release facing quick connector, install
release onto fuel tube.
c. Insert release into quick connector until sleeve contacts and
goes no further. Hold the release on that position.
CAUTION:
Inserting the release hard will not disconnect quick connec-
tor. Hold release where it contacts and goes no further.
d. Draw and pull out quick connector straight from fuel tube.
CAUTION:
lPull quick connector holding A position in illustration.
lDo not pull with lateral force applied. O-ring inside quick connector may be damaged.
lPrepare container and cloth beforehand as fuel will leak out.
lAvoid fire and sparks.
lBe sure to cover openings of disconnected pipes with plug or plastic bag to avoid fuel leakage
and entry of foreign materials.
6. Loosen mounting bolts diagonally, and remove electric throttle control actuator.
CAUTION:
Handle carefully to avoid any shock.
7. Disconnect intake manifold collector harness, vacuum hose, and PCV hose.
CAUTION:
lCover engine openings to avoid entry of foreign materials.
KBIA0268E
PBIC0012E
KBIA0230E
Page 1989 of 3066
INTAKE MANIFOLD
EM-19
[QR20DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
8. Remove intake manifold collector mounting bolts on the support.
9. Loosen mounting bolts and nuts in order from 5 to 1, and
remove intake manifold collector.
lDisregard 6 when loosening.
10. Disconnect harness and power steering piping from intake man-
ifold and fuel tube assembly, and move them a side.
11. Loosen bolts in reverse order of illustration to remove intake
manifold assembly.
lDisregard No.6 when loosening.
INSPECTION AFTER REMOVAL
Surface Distortion
lUsing straightedge and feeler gauge, inspect surface distortion
of intake manifold collector and intake manifold surface.
INSTALLATION
lInstall in the reverse order of removal paying attention to the following.
Tightening Intake Manifold bolts and nuts
lTighten in numerical order as shown in the figure.
NOTE:
No.6 means double tightening of bolt 1.
KBIA0234E
KBIA0233E
Standard : 0.1 mm (0.004 in)
KBIA0235E
KBIA0233E
Page 1990 of 3066
![NISSAN X-TRAIL 2003 Electronic Repair Manual EM-20
[QR20DE]
INTAKE MANIFOLD
Tightening Intake Manifold collector bolts and nuts
lTighten in numerical order as shown in the figure.
NOTE:
No.6 means double tightening of bolts 1.
Installation of El NISSAN X-TRAIL 2003 Electronic Repair Manual EM-20
[QR20DE]
INTAKE MANIFOLD
Tightening Intake Manifold collector bolts and nuts
lTighten in numerical order as shown in the figure.
NOTE:
No.6 means double tightening of bolts 1.
Installation of El](/manual-img/5/57402/w960_57402-1989.png)
EM-20
[QR20DE]
INTAKE MANIFOLD
Tightening Intake Manifold collector bolts and nuts
lTighten in numerical order as shown in the figure.
NOTE:
No.6 means double tightening of bolts 1.
Installation of Electric Throttle Control Actuator
lTighten fixing bolts of electric throttle control actuator equally and diagonally in several steps.
lAfter installation perform procedure inEM-20, "INSPECTION AFTER INSTALLATION".
Connecting Quick Connector of Fuel Hose
lInstall quick connector as follows. (The steps are the same for quick connectors on engine side and vehi-
cle)
1. Make sure no foreign substances are deposited in and around tube and quick connector and no damage
on them.
2. Thinly apply new engine oil around the fuel tube tip end.
3. Align center to insert quick connector straightly into fuel tube.
lInsert fuel tube into quick connector until the first spool on fuel
tubes is inserted completely and the second one is positioned
slightly below the quick connectors bottom end.
CAUTION:
lHold A position in illustration when inserting fuel tube
into quick connector.
lCarefully align center to avoid inclined insertion to pre-
vent damage to O-ring inside quick connector.
lInsert until you hear a “click” sound and actually feel the
engagement.
lTo avoid misidentification of engagement with a similar sound, be sure to perform the next step.
4. Before clamping fuel hose with hose clamps, pull quick connector hard by hand holding A position. Make
sure it is completely engaged (connected) so that it does not come out from fuel tube.
NOTE:
Recommended pulling force is 50 N (5.1 kg, 11.2 lb).
5. Install quick connector cap on quick connector joint.
lDirect arrow mark on quick connector cap to upper side (The
figure shows quick connector cap for engine side).
6. Install fuel hose to hose clamp.
INSPECTION AFTER INSTALLATION
lCheck connections for fuel leakage.
1. Start the engine, and run it for a few minutes with engine at idle.
2. Stop the engine, and check for fuel leakage both visually and by odor of gasoline.
NOTE:
Use mirrors for checking on invisible points.
KBIA0234E
KBIA0272E
KBIA0298E
