EXHAUST MANIFOLD AND TURBOCHARGER
EM-119
[YD22DDTi]
C
D
E
F
G
H
I
J
K
L
MA
EM
EXHAUST MANIFOLD AND TURBOCHARGERPFP:14004
Removal and InstallationEBS00BOB
REMOVAL
1. Drain engine coolant. Refer toCO-30, "Changing Engine Coolant".
2. Remove charge air cooler. Refer toEM-114, "
Removal and Installation".
3. Remove air duct and air inlet pipe. Refer toEM-112, "
Removal and Installation".
4. Remove engine under cover.
5. Remove radiator upper hose.
6. Remove radiator fan. Refer toCO-34, "
Disassembly and Assembly Radiator Fan".
7. Remove radiator mount bracket and radiator. Refer toCO-33, "
Removal and Installation".
8. Remove water inlet pipe.
9. Disconnect exhaust front tube. Refer toEX-2, "
EXHAUST SYSTEM".
10. Remove catalyst. Refer toEM-118, "
Removal and Installation".
11. Remove exhaust manifold cover.
12. Remove insulator.
13. Each wiring and piping (disconnect/move)
SBIA0158E
1. Electronic EGR control valve 2. Gasket 3. EGR tube
4. Air inlet pipe 5.Exhaust manifold & turbocharger
assembly6. Oil return hose
7. Turbo insulator 8. Exhaust manifold insulator 9. Air inlet pipe
Page 2090 of 3066
EM-120
[YD22DDTi]
EXHAUST MANIFOLD AND TURBOCHARGER
14. Loosen exhaust manifold mounting nuts in the reverse order
specified in the figure.
15. Rotate the exhaust manifold and turbocharger assembly so that
the rear side (EGR tube mounting side) faces upward. And then
pull out the assembly from between the engine and the air con-
ditioning piping.
CAUTION:
Be careful not to deform each turbocharger piping when pulling
out the assembly.
INSTALLATION
lWhen a stud bolt is pulled out, tighten it to the following torque:
lTighten the exhaust manifold mounting nuts in the following procedure:
1. Tighten the nuts in the order specified in the figure.
2. Re-tighten the nuts 1 to 4.
3. Install the gasket so that the alignment protrusion faces the No.
4port.
4. Install in reverse order of removal.
INSPECTION AFTER INSTALLATION
Start engine and raise engine speed to check no exhaust emission leaks.
JEM266G
: 18 - 21 N·m (1.8 - 2.2 kg-m, 13 - 15 ft-lb)
JEM266G
Page 2091 of 3066
EXHAUST MANIFOLD AND TURBOCHARGER
EM-121
[YD22DDTi]
C
D
E
F
G
H
I
J
K
L
MA
EM
Disassembly and AssemblyEBS00BOC
REMOVAL
1. After applying penetrative lubricant to the mounting nuts, check for the penetration of the lubricant, and
then loosen the nuts to remove.
CAUTION:
Do not disassemble or adjust the turbocharger body.
2. When a stud bolt is pulled out, tighten it to the following torque:
INSPECTION AFTER REMOVAL
Surface Distortion
Check the distortion on the mounting surface in the six directions
using a straightedge and a feeler gauge.
SBIA0159E
1. Exhaust manifold 2. Gasket 3. Oil inlet tube
4. Water tube 5. Turbocharger 6. Oil outlet tube
:24-27N·m(2.4-2.8kg-m,18-20ft-lb)
Limit : 0.3 mm (0.012 in)
JEM267G
Page 2092 of 3066
EM-122
[YD22DDTi]
EXHAUST MANIFOLD AND TURBOCHARGER
Turbocharger
EBS00BPK
CAUTION:
When the compressor wheel turbine wheel or rotor shaft is damaged, remove all the fragments and
foreign matter left in the following passages in order to prevent a secondary failure:
ROTOR SHAFT CLEARANCE
lCheck that the rotor shaft rotates smoothly without any resis-
tance when it is rotated by your fingertips.
lCheck that the rotor shaft is not loose when it is moved vertically
or horizontally.
ROTOR SHAFT END PLAY
Place a dial gauge at the rotor shaft end in the axial direction to mea-
sure the end play.
SEM269G
Suction side : Between turbocharger and air cleaner
Exhaust side : Between turbocharger and catalyst
Standard : 0.068 - 0.096 mm (0.0027 - 0.0038 in)
SEM270G
Standard : 0.026 - 0.084 mm (0.0010 - 0.0033 in)
SEM271G
Page 2093 of 3066
![NISSAN X-TRAIL 2003 Electronic Repair Manual EXHAUST MANIFOLD AND TURBOCHARGER
EM-123
[YD22DDTi]
C
D
E
F
G
H
I
J
K
L
MA
EM
TURBINE WHEEL
lCheck that there is no oil adhesion.
lCheck that there is no carbon accumulation.
lCheck that blades of the NISSAN X-TRAIL 2003 Electronic Repair Manual EXHAUST MANIFOLD AND TURBOCHARGER
EM-123
[YD22DDTi]
C
D
E
F
G
H
I
J
K
L
MA
EM
TURBINE WHEEL
lCheck that there is no oil adhesion.
lCheck that there is no carbon accumulation.
lCheck that blades of the](/manual-img/5/57402/w960_57402-2092.png)
EXHAUST MANIFOLD AND TURBOCHARGER
EM-123
[YD22DDTi]
C
D
E
F
G
H
I
J
K
L
MA
EM
TURBINE WHEEL
lCheck that there is no oil adhesion.
lCheck that there is no carbon accumulation.
lCheck that blades of the turbine wheel are not bent or broken.
lCheck that the turbine wheel does not interfere with the turbine
housing.
COMPRESSOR WHEEL
lCheck that there is no oil adhesion inside the air inlet.
lCheck that the compressor wheel does not interfere with the
compressor housing.
lCheck that the wheel is not bent or broken.
WASTEGATE VALVE ACTUATOR
lConnect the handy pump to the actuator, and check that the rod
strokes smoothly in compliance with the following pressure.
lPressure to be applied at actuator part to move rod end as fol-
lows:
TROUBLE DIAGNOSIS OF TURBOCHARGER
Preliminary check:
lCheck that the engine oil level is between MIN and MAX of the dipstick. (When the engine oil amount is
more than MAX, the oil flows into the inlet duct through the blow-by gas passage, and the turbocharger is
misjudged failure.)
lAsk the customer if he/she always runs the vehicle in idle engine speed to cool the oil down after driving.
lReplace the turbocharger assembly when any malfunction is found after unit inspections specified in the
table below.
lIf no malfunction is found after the unit inspections, judge that the turbocharger body has no failure. Check
the other parts again.
SEM272G
SEM273G
Standard (Pressure/rod stroke amount):
: 150.80 - 156.20 kPa (1,508 - 1,562 mbar, 1,131 - 1,172
mmHg, 44.0 - 46.2 inHg)/0.38 mm (0.0150 in)
: 176.50 - 185.90 kPa (1,765 - 1,859 mbar, 1,324 - 1,394
mmHg, 52.2 - 54.9 inHg)/4.0 mm (0.157 in)
SEM274G
Inspection item Inspection resultSymptom
(when each inspection item meets each inspection result)
Oil leakage Smoke NoiseInsufficient power/
acceleration failure
Page 2094 of 3066
EM-124
[YD22DDTi]
EXHAUST MANIFOLD AND TURBOCHARGER
A: Large possibility
B: Medium possibility
C: Small possibilityTurbine wheelOil leaks C A C C
Carbon is accumulated C A B B
Friction with housing C B A B
Blades are bent or broken A A
Compressor wheelInside the air inlet is seriously con-
taminated by oil.BB
Friction with housing C B A B
Blades are bent or broken A A
After checking both turbine and
compressor, inspect rotor shaft
end play.There is resistance when the rotor
shaft is rotated by your fingertips.CC B
The rotor shaft sometimes does not
rotate by your fingertips.A
There is too much play in the bear-
ing.CCB C
Oil return portCarbon or sludge is accumulated in
the waste oil hole.CAC C
Page 2095 of 3066
OIL PAN AND OIL STRAINER
EM-125
[YD22DDTi]
C
D
E
F
G
H
I
J
K
L
MA
EM
OIL PAN AND OIL STRAINERP F P : 1111 0
Removal and InstallationEBS00BO1
REMOVAL
WA RN ING:
To avoid the danger of being scalded, never drain the engine oil when the engine is hot.
1. Remove engine under cover at both side.
2. Drain engine oil. Refer toLU-19, "
Changing Engine Oil".
3. Remove lower oil pan bolts, Loosen bolts in the reverse order of
that shown in the figure.
SBIA0160E
1. Rear plate cover 2. Oil pan upper 3. Oil strainer
4. Drain plug 5. Oil pan lower
SBIA0161E
Page 2096 of 3066
EM-126
[YD22DDTi]
OIL PAN AND OIL STRAINER
4. Remove lower oil pan.
a. Insert Tool between upper oil pan and lower oil pan.
lBe careful not to damage aluminum mating surface.
lDo not insert screwdriver, or oil pan flange will be
deformed.
b. Slide Tool by tapping on the side of the Tool with a hammer.
c. Remove lower oil pan.
5. Remove drive belts.
6. Remove A/C compressor and bracket.
7. Remove front exhaust tube and its support.
8. Set a suitable transmission jack under transaxle and hoist
engine with engine slinger. Refer toEM-184, "
Removal and
Installation".
9. Remove center member.
10. Remove rear plate cover and four engine-to transaxle bolts.
11. Remove catalyst and rear diffuser. Refer toEM-118, "
Removal
and Installation".
12. Loosen bolts in reverse order of illustration to remove upper oil
pan.
SEM544G
SEM545G
JEM553G
SBIA0162E
