Page 2297 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual GI-44
IDENTIFICATION INFORMATION
IDENTIFICATION NUMBER
VEHICLE IDENTIFICATION NUMBER ARRANGEMENT
PAIA0004E
PAIA0005E

Page 2298 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual IDENTIFICATION INFORMATION
GI-45
IDENTIFICATION PLATE
ENGINE SERIAL NUMBER
AUTOMATIC TRANSAXLE NUMBER
PAIA0006E
PAIA0036E
PAIA0008E
PAIA0009E

Page 2299 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual GI-46
IDENTIFICATION INFORMATION
MANUAL TRANSAXLE NUMBER
DimensionsEAS000GF
Unit: mm(in)
Wheels & TiresEAS000GG
PAIA0010E
Overall length 4,510
Overall width 1,765
Overall height 1,675 (Standard), 1,75

Page 2300 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual TERMINOLOGY
GI-47
TERMINOLOGYPFP:00011
SAE J1930 Terminology ListEAS000GH
All emission related terms used in this publication in accordance with SAE J1930 are listed. Accordingly, new
terms, new acron

TERMINOLOGY
GI-47
TERMINOLOGYPFP:00011
SAE J1930 Terminology ListEAS000GH
All emission related terms used in this publication in accordance with SAE J1930 are listed. Accordingly, new
terms, new acronyms/abbreviations and old terms are listed in the following chart.
NEW TERMNEW ACRONYM /
ABBREVIATIONOLD TERM
Air cleaner ACL Air cleaner
Barometric pressure BARO ***
Barometric pressure sensor-BCDD BAROS-BCDD BCDD
Camshaft position CMP ***
Camshaft position sensor CMPS Crank angle sensor
Canister *** Canister
Carburetor CARB Carburetor
Charge air cooler CAC Intercooler
Closed loop CL Closed loop
Closed throttle position switch CTP switch Idle switch
Clutch pedal position switch CPP switch Clutch switch
Continuous fuel injection system CFI system ***
Continuous trap oxidizer system CTOX system ***
Crankshaft position CKP ***
Crankshaft position sensor CKPS ***
Data link connector DLC ***
Data link connector for CONSULT-II DLC for CONSULT-II Diagnostic connector for CONSULT-II
Diagnostic test mode DTM Diagnostic mode
Diagnostic test mode selector DTM selector Diagnostic mode selector
Diagnostic test mode I DTM I Mode I
Diagnostic test mode II DTM II Mode II
Diagnostic trouble code DTC Malfunction code
Direct fuel injection system DFI system ***
Distributor ignition system DI system Ignition timing control
Early fuel evaporation-mixture heater EFE-mixture heater Mixture heater
Early fuel evaporation system EFE system Mixture heater control
Electrically erasable programmable read
only memoryEEPROM ***
Electronic ignition system EI system Ignition timing control
Engine control EC ***
Engine control module ECM ECCS control unit
Engine coolant temperature ECT Engine temperature
Engine coolant temperature sensor ECTS Engine temperature sensor
Engine modification EM ***
Engine speed RPM Engine speed
Erasable programmable read only memory EPROM ***
Evaporative emission canister EVAP canister Canister
Evaporative emission system EVAP system Canister control solenoid valve
Exhaust gas recirculation valve EGR valve EGR valve

Page 2301 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual GI-48
TERMINOLOGY
Exhaust gas recirculation control-BPT
valveEGRC-BPT valve BPT valve
Exhaust gas recirculation control-solenoid
valveEGRC-solenoid valve EGR control solenoid valve
Exhaust gas recircu

GI-48
TERMINOLOGY
Exhaust gas recirculation control-BPT
valveEGRC-BPT valve BPT valve
Exhaust gas recirculation control-solenoid
valveEGRC-solenoid valve EGR control solenoid valve
Exhaust gas recirculation temperature sen-
sor
EGRT sensor Exhaust gas temperature sensor
EGR temperature sensor
Flash electrically erasable programmable
read only memoryFEEPROM ***
Flash erasable programmable read only
memoryFEPROM ***
Flexible fuel sensor FFS ***
Flexible fuel system FF system ***
Fuel pressure regulator *** Pressure regulator
Fuel pressure regulator control solenoid
valve*** PRVR control solenoid valve
Fuel trim FT ***
Heated Oxygen sensor HO2S Exhaust gas sensor
Idle air control system IAC system Idle speed control
Idle air control valve-air regulator IACV-air regulator Air regulator
Idle air control valve-auxiliary air control
valveIACV-AAC valve Auxiliary air control (AAC) valve
Idle air control valve-FICD solenoid valve IACV-FICD solenoid valve FICD solenoid valve
Idle air control valve-idle up control sole-
noid valveIACV-idle up control solenoid valve Idle up control solenoid valve
Idle speed control-FI pot ISC-FI pot FI pot
Idle speed control system ISC system ***
Ignition control IC ***
Ignition control module ICM ***
Indirect fuel injection system IFI system ***
Intake air IA Air
Intake air temperature sensor IAT sensor Air temperature sensor
Knock *** Detonation
Knock sensor KS Detonation sensor
Malfunction indicator lamp MIL Check engine light
Manifold absolute pressure MAP ***
Manifold absolute pressure sensor MAPS ***
Manifold differential pressure MDP ***
Manifold differential pressure sensor MDPS ***
Manifold surface temperature MST ***
Manifold surface temperature sensor MSTS ***
Manifold vacuum zone MVZ ***
Manifold vacuum zone sensor MVZS ***
Mass air flow sensor MAFS Air flow meter
Mixture control solenoid valve MC solenoid valve Air-fuel ratio control solenoid valve
Multiport fuel injection System MFI system Fuel injection controlNEW TERMNEW ACRONYM /
ABBREVIATIONOLD TERM

Page 2302 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual TERMINOLOGY
GI-49
Nonvolatile random access memory NVRAM ***
On board diagnostic system OBD system Self-diagnosis
Open loop OL Open loop
Oxidation catalyst OC Catalyst
Oxidation catalytic converter sy

Page 2303 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual GI-50
TERMINOLOGY
Torque converter clutch solenoid valve TCC solenoid valveLock-up cancel solenoid
Lock-up solenoid
Transmission control module TCM A/T control unit
Turbocharger TC Turbocharger
Vehicl

Page 2304 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual GW-1
GLASSES, WINDOW SYSTEM & MIRRORS
IBODY
CONTENTS
C
D
E
F
G
H
J
K
L
M
SECTION
A
B
GW
GLASSES, WINDOW SYSTEM & MIRRORS
PRECAUTIONS .......................................................... 2
Precau

GW-1
GLASSES, WINDOW SYSTEM & MIRRORS
IBODY
CONTENTS
C
D
E
F
G
H
J
K
L
M
SECTION
A
B
GW
GLASSES, WINDOW SYSTEM & MIRRORS
PRECAUTIONS .......................................................... 2
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” .................................................................. 2
Precautions .............................................................. 2
WINDSHIELD GLASS AND MOLDING ..................... 3
Removal and Installation .......................................... 3
REMOVAL ............................................................. 3
INSTALLATION ..................................................... 3
SIDE WINDOW GLASS .............................................. 5
Removal and Installation .......................................... 5
REMOVAL ............................................................. 5
INSTALLATION ..................................................... 5
BACK DOOR WINDOW GLASS ................................ 7
Removal and Installation .......................................... 7
REMOVAL ............................................................. 7
INSTALLATION ..................................................... 8
REAR WINDOW DEFOGGER .................................... 9
Component Parts and Harness Connector Location..... 9
System description ................................................... 9
Wiring Diagram –DEF– LHD models ..................... 10
Terminals and Reference value for Time Control
Unit (LHD models) .................................................. 12
Wiring Diagram –DEF– RHD models ..................... 13
Terminals and Reference value for Time Control
Unit (RHD models) ................................................. 15
Trouble Diagnoses ................................................. 15
DIAGNOSTIC PROCEDURE SUBTITLE
(SYMPTOM: REAR WINDOW DEFOGGER
DOES NOT ACTIVATE, OR DOES NOT GO OFF
AFTER ACTIVATING.) ........................................ 15
Electrical Components Inspection .......................... 17
REAR WINDOW DEFOGGER RELAY ............... 17
REAR WINDOW DEFOGGER SWITCH ............. 17
FILAMENT CHECK ............................................. 17
FILAMENT REPAIR ............................................ 18
POWER WINDOW SYSTEM .................................... 20
Component Parts and Harness Connector Location... 20
System Description ................................................ 20MANUAL OPERATION ........................................ 20
AUTO OPERATION ............................................. 21
POWER WINDOW LOCK ................................... 21
TIME FUNCTION ................................................ 21
DRIVER WINDOW ANTI–PINCH FUNCTION .... 21
Schematic (LHD models) ........................................ 23
Wiring Diagram – WINDOW – (LHD models) ......... 24
Terminal and Reference Value for Power Window
Main Switch (LHD models) ..................................... 28
Terminal and Reference Value for Each Door's
Power Window Switch (LHD models) ..................... 29
Schematic (RHD models) ....................................... 31
Wiring Diagram – WINDOW – RHD models ........... 32
Terminal and Reference Value for Power Window
Main Switch (RHD models) .................................... 36
Terminal and Reference Value for Each Door's
Power Window Switch (RHD models) .................... 37
Trouble Diagnoses ................................................. 38
Encoder and Limit Switch Check ............................ 39
FRONT DOOR GLASS AND REGULATOR ............. 41
Removal and Installation ........................................ 41
INSPECTION AFTER REMOVAL ....................... 42
INSPECTION AFTER INSTALLATION ................ 42
FITTING INSPECTION ....................................... 42
REAR DOOR GLASS AND REGULATOR ............... 43
Removal and Installation ........................................ 43
INSPECTION AFTER REMOVAL ....................... 45
FITTING INSPECTION ....................................... 45
DOOR MIRROR ........................................................ 46
Precautions to Handle Retractable Power Door Mir-
rors ......................................................................... 46
Wiring Diagram –MIRROR– LHD models .............. 47
Wiring Diagram –MIRROR– RHD models .............. 49
Removal and Installation ........................................ 51
REMOVAL ........................................................... 51
INSTALLATION ................................................... 51
Disassembly and Assembly .................................... 52
DISASSEMBLY ................................................... 52
ASSEMBLY ......................................................... 52
