NISSAN X-TRAIL 2003 Electronic Repair Manual TROUBLE DIAGNOSIS — GENERAL DESCRIPTION AT-123 [EURO-OBD] D E F G H I J K L MA B AT Lock-up point is extremely high or low. AT- 2 5 2 , " 12. A/T Does Not Perform Lock-up" ON vehicle1. Throttle posi

Page 130 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual AT-124 [EURO-OBD] TROUBLE DIAGNOSIS — GENERAL DESCRIPTION A/T does not shift to “D4”whendriv- ing with overdrive control switch “ON”.ON vehicle1. Throttle position sensor (Accelerator pedal

Page 131 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual TROUBLE DIAGNOSIS — GENERAL DESCRIPTION AT-125 [EURO-OBD] D E F G H I J K L MA B AT TCM Terminals and Reference ValueECS004QV PREPARATION lMeasure voltage between each terminal and terminal 25 or 48

Page 132 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual AT-126 [EURO-OBD] TROUBLE DIAGNOSIS — GENERAL DESCRIPTION TCM HARNESS CONNECTOR TERMINAL LAYOUT TCM INSPECTION TABLE (Data are reference values.) SCIA0712E Te r m i - nal No.Wire color Item Conditio

Page 133 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual TROUBLE DIAGNOSIS — GENERAL DESCRIPTION AT-127 [EURO-OBD] D E F G H I J K L MA B AT 20 L/BOverrun clutch solenoid valveWhen overrun clutch solenoid valve operates.Battery voltage When overrun clutch

Page 134 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual AT-128 [EURO-OBD] TROUBLE DIAGNOSIS — GENERAL DESCRIPTION *2: These terminals are connected to the ECM. *3: These terminals are connected to the data link connector.40 L/BVehicle speed sensorWhen mo

Page 135 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual CAN COMMUNICATION AT-129 [EURO-OBD] D E F G H I J K L MA B AT CAN COMMUNICATIONPFP:23710 System DescriptionECS004VP CAN (Controller Area Network) is a serial communication line for real time applicati

Page 136 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual AT-130 [EURO-OBD] DTC P0705 PARK/NEUTRAL POSITION (PNP) SWITCH DTC P0705 PARK/NEUTRAL POSITION (PNP) SWITCH PFP:32006 DescriptionECS004QW lThe PNP switch assembly includes a transmission range switch.
