NISSAN X-TRAIL 2003 Electronic Repair Manual SERVICE DATA AND SPECIFICATIONS (SDS)
AT-563
[ALL]
D
E
F
G
H
I
J
K
L
MA
B
AT
SERVICE DATA AND SPECIFICATIONS (SDS)PFP:00030
General SpecificationsECS004MI
Shift ScheduleECS004MJ
VEHICLE SPEED WHEN SHI

Page 570 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual AT-564
[ALL]
SERVICE DATA AND SPECIFICATIONS (SDS)
Control Valves
ECS004MM
CONTROL VALVE AND PLUG RETURN SPRINGS
Unit: mm (in)
*: Always check with the Parts Department for the latest parts informatio

AT-564
[ALL]
SERVICE DATA AND SPECIFICATIONS (SDS)
Control Valves
ECS004MM
CONTROL VALVE AND PLUG RETURN SPRINGS
Unit: mm (in)
*: Always check with the Parts Department for the latest parts information.
AccumulatorECS0 04 MN
O-RING
Unit: mm (in)
*: Always check with the Parts Department for the latest parts information.
RETURN SPRING
Unit: mm (in)
*: Always check with the Parts Department for the latest parts information.
Clutch and BrakesECS004MO
REVERSE CLUTCH
PartsItem
Part No.* Free length Outer diameter
Upper body23 Pilot valve spring 31742-3AX03 38.98 (1.535) 8.9 (0.350)
7 1-2 accumulator valve spring 31742-3AX00 20.5 (0.807) 6.95 (0.274)
28 1-2 accumulator piston spring 31742-85X02 55.60 (2.189) 19.6 (0.772)
33 1st reducing valve spring 31742-80X05 27.0 (1.063) 7.0 (0.276)
35 3-2 timing valve spring 31736-01X00 23.0 (0.906) 6.65 (0.262)
18 Overrun clutch reducing valve spring 31742-80X15 37.5 (1.476) 6.9 (0.272)
16 Torque converter relief valve spring 31742-80X07 31.0 (1.220) 9.0 (0.354)
11 Torque converter clutch control valve 31742-85X00 56.98 (2.243) 6.5 (0.256)
3 Cooler check valve spring 31742-85X01 29.4 (1.157) 6.0 (0.236)
Lower body15 Pressure regulator valve spring 31742-80X13 45.0 (1.772) 15.0 (0.591)
20 Overrun clutch control valve spring 31762-80X00 21.7 (0.854) 7.0 (0.276)
24 Accumulator control valve spring 31742-80X02 22.0 (0.866) 6.5 (0.256)
29 Shift valve A spring 31762-80X00 21.7 (0.854) 7.0 (0.276)
32 Shuttle valve spring 31762-41X04 51.0 (2.008) 5.65 (0.222)
12 Shift valve B spring 31762-80X00 21.7 (0.854) 7.0 (0.276)
7
Pressure modifier valve spring31742-41X15 30.5 (1.201) 9.8 (0.386)
3 31742-80X16 32.0 (1.260) 6.9 (0.272)
— Oil cooler relief valve spring 31872-31X00 17.02 (0.670) 8.0 (0.315)
Accumulator Part No.*Inner diameter
(Small)Part No.*Inner diameter
(Large)
Servo release accumulator 31526 41X03 26.9 (1.059) 31526 41X02 44.2 (1.740)
N-D accumulator 31526 31X08 34.6 (1.362) 31672 21X00 39.4 (1.551)
Accumulator Part number* Free length Outer diameter
Servo release accumulator 31605-80X00 52.5 (2.067) 20.1 (0.791)
N-D accumulator 31605-31X15 43.5 (1.713) 28.0 (1.102)
Model code number85X23
Number of drive plates2
Number of driven plates2
Drive plate thickness mm (in)Standard 1.6 (0.063)
Allowable limit 1.4 (0.055)
Driven plate thickness mm (in) Standard 1.8 (0.071)

Page 571 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual SERVICE DATA AND SPECIFICATIONS (SDS)
AT-565
[ALL]
D
E
F
G
H
I
J
K
L
MA
B
AT
*: Always check with the Parts Department for the latest parts information.
HIGH CLUTCH
*: Always check with the Parts Depa

Page 572 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual AT-566
[ALL]
SERVICE DATA AND SPECIFICATIONS (SDS)
*: Always check with the Parts Department for the latest parts information.
LOW & REVERSE BRAKE
*: Always check with the Parts Department for the lat

Page 573 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual SERVICE DATA AND SPECIFICATIONS (SDS)
AT-567
[ALL]
D
E
F
G
H
I
J
K
L
MA
B
AT
DIFFERENTIAL SIDE GEAR THRUST WASHERS
*: Always check with the Parts Department for the latest parts information.
DIFFERENT

Page 574 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual AT-568
[ALL]
SERVICE DATA AND SPECIFICATIONS (SDS)
Input Shaft
ECS0 04 MR
SEAL RING CLEARANCE
SEAL RING
*: Always check with the Parts Department for the latest parts information.
Reduction Pinion Gea

AT-568
[ALL]
SERVICE DATA AND SPECIFICATIONS (SDS)
Input Shaft
ECS0 04 MR
SEAL RING CLEARANCE
SEAL RING
*: Always check with the Parts Department for the latest parts information.
Reduction Pinion GearECS004MS
TURNING TORQUE
REDUCTION PINION GEAR BEARING ADJUSTING SHIMS
Input shaft seal ring clearance mm
(in)Standard 0.08 - 0.23 (0.0031 - 0.0091)
Allowable limit 0.23 (0.0091)
Outer diameter mm (in) 1n ner diameter mm (in) width mm (in) Part number*
26 (1.024) 22.4 (0.882) 1.97 (0.078) 31525 80X02
Turning torque of reduction pinion gear N-m (kg-cm, in-lb) 0.05 - 0.39 (0.5 - 4.0, 0.43 - 3.47)
NO. Thickness mm (in) Part number NO. Thickness mm (in) Part number*
1 5.00 (0.1969) 31439-81X00 33 5.64 (0.2220) 31439-81X63
2 5.02 (0.1976) 31439-81X01 34 5.66 (0.2228) 31439-81X64
3 5.04 (0.1984) 31439-81X02 35 5.68 (0.2236) 31439-81X65
4 5.06 (0.1992) 31439-81X03 36 5.70 (0.2244) 31439-81X66
5 5.08 (0.2000) 31439-81X04 37 5.72 (0.2252) 31439-81X67
6 5.10 (0.2008) 31439-81X05 38 5.74 (0.2260) 31439-81X68
7 5.12 (0.2016) 31439-81X06 39 5.76 (0.2268) 31439-81X69
8 5.14 (0.2024) 31439-81X07 40 5.78 (0.2276) 31439-81X70
9 5.16 (0.2031) 31439-81X08 41 5.80 (0.2283) 31439-81X71
10 5.18 (0.2039) 31439-81X09 42 5.82 (0.2291) 31439-81X72
11 5.20 (0.2047) 31439-81X10 43 5.84 (0.2299) 31439-81X73
12 5.22 (0.2055) 31439-81X11 44 5.86 (0.2307) 31439-81X74
13 5.24 (0.2063) 31439-81X12 45 4.60 (0.1811) 31439-85X01
14 5.26 (0.2071) 31439-81X13 46 4.62 (0.1819) 31439-85X02
15 5.28 (0.2079) 31439-81X14 47 4.64 (0.1827) 31439-85X03
16 5.30 (0.2087) 31439-81X15 48 4.66 (0.1835) 31439-85X04
17 5.32 (0.2094) 31439-81X16 49 4.68 (0.1843) 31439 85X05
18 5.34 (0.2102) 31439-81X17 50 4.70 (0.1850) 31439 85X06
19 5.36 (0.2110) 31439-81X18 51 4.72 (0.1858) 31439 83X11
20 5.38 (0.2118) 31439-81X19 52 4.74 (0.1866) 31439 83X12
21 5.40 (0.2126) 31439-81X20 53 4.76 (0.1874) 31439 83X13
22 5.42 (0.2134) 31439-81X21 54 4.78 (0.1882) 31439 83X14
23 5.44 (0.2142) 31439-81X22 55 4.80 (0.1890) 31439 83X15
24 5.46 (0.2150) 31439-81X23 56 4.82 (0.1898) 31439 83X16
25 5.48 (0.2157) 31439-81X24 57 4.84 (0.1906) 31439 83X17
26 5.50 (0.2165) 31439-81X46 58 4.86 (0.1913) 31439 83X18
27 5.52 (0.2173) 31439-81X47 59 4.88 (0.1921) 31439 83X19
28 5.54 (0.2181) 31439-81X48 60 4.90 (0.1929) 31439 83X20
29 5.56 (0.2189) 31439-81X49 61 4.92 (0.1937) 31439 83X21
30 5.58 (0.2197) 31439-81X60 62 4.94 (0.1945) 31439 83X22

Page 575 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual SERVICE DATA AND SPECIFICATIONS (SDS)
AT-569
[ALL]
D
E
F
G
H
I
J
K
L
MA
B
AT
*: Always check with the Parts Department for the latest parts information.
Band ServoECS004MT
RETURN SPRING
Unit: mm (in)

Page 576 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual AT-570
[ALL]
SERVICE DATA AND SPECIFICATIONS (SDS)
BEARING RACE FOR ADJUSTING TOTAL END PLAY
*: Always check with the Parts Department for the latest parts information.
Reverse Clutch End PlayECS004MX
