Page 553 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual ASSEMBLY AT-547 [ALL] D E F G H I J K L MA B AT 2. Set side cover on transmission case. lApply locking sealant to the mating surface of transmis- sion case. 3. Tighten side cover fixing bolts to speci

Page 554 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual AT-548 [ALL] ASSEMBLY 7. Install thrust needle bearing on bearing retainer. lApply petroleum jelly to thrust needle bearing. lPay attention to direction of thrust needle bearing. 8. Install overrun cl

Page 555 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual ASSEMBLY AT-549 [ALL] D E F G H I J K L MA B AT 11. Install rear planetary carrier assembly and rear sun gear accord- ing to the following procedures. a. Install needle bearings on rear planetary carr

Page 556 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual AT-550 [ALL] ASSEMBLY 13. Install low and reverse brake piston according to the following procedures. a. Set and align return springs to transmission case gutters as shown in illustration. b. Set and

Page 557 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual ASSEMBLY AT-551 [ALL] D E F G H I J K L MA B AT e. Push down piston and retainer assembly and install snap ring. 14. Install low one-way clutch to front planetary carrier by turning carrier in the dir

Page 558 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual AT-552 [ALL] ASSEMBLY 17. Install bearing race, needle bearing and high clutch hub on front sun gear. lApply petroleum jelly to needle bearing. lPay attention to direction of needle bearing. 18. Insta

Page 559 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual ASSEMBLY AT-553 [ALL] D E F G H I J K L MA B AT Adjustment (2)ECS0 04 MG When any parts listed below are replaced, adjust total end play and reverse clutch end play. TOTAL END PLAY lMeasure clearance

Page 560 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual AT-554 [ALL] ASSEMBLY b. Measure dimension "L". c. Calculate dimension "J". 2. Measure dimension "M". a. Place bearing race and needle bearing on oil pump assembly. b. Measure dimension "M". c. Measur
