Page 2537 of 3066

MT-1
MANUAL TRANSAXLE
C TRANSMISSION/TRANSAXLE
CONTENTS
D
E
F
G
H
I
J
K
L
M
SECTION
A
B
MT
MANUAL TRANSAXLE
PRECAUTIONS .......................................................... 3
Caution ..................................................................... 3
PREPARATION ........................................................... 4
Special Service Tools ............................................... 4
Commercial Service Tools ........................................ 6
NOISE, VIBRATION, AND HARSHNESS (NVH)
TROUBLESHOOTING ................................................ 8
NVH Troubleshooting Chart ..................................... 8
MANUAL TRANSAXLE ......................................... 8
DESCRIPTION ............................................................ 9
Cross-sectional View ................................................ 9
DOUBLE-CONE SYNCHRONIZER .................... 10
REVERSE GEAR NOISE PREVENTION FUNC-
TION (SYNCHRONIZING METHOD) ................. 10
M/T OIL ......................................................................11
Changing M/T Oil ....................................................11
DRAINING ............................................................11
FILLING ................................................................11
Checking M/T Oil .....................................................11
OIL LEAKAGE AND OIL LEVEL ..........................11
SIDE OIL SEAL ........................................................ 12
Removal and Installation ........................................ 12
REMOVAL ........................................................... 12
INSTALLATION ................................................... 12
POSITION SWITCH .................................................. 13
Checking ................................................................ 13
BACK-UP LAMP SWITCH .................................. 13
PARK/NEUTRAL POSITION SWITCH ............... 13
CONTROL LINKAGE ............................................... 14
Removal and Installation of Control Device and
Cable ...................................................................... 14
AIR BREATHER HOSE ............................................ 15
Removal and Installation ........................................ 15
TRANSAXLE ASSEMBLY ........................................ 16
Removal and Installation ........................................ 16
REMOVAL ........................................................... 16
INSTALLATION ................................................... 17
Component Parts (RS5F51A) ................................ 18CASE AND HOUSING COMPONENTS .............. 18
GEAR COMPONENTS ....................................... 19
SHIFT CONTROL COMPONENTS ..................... 21
FINAL DRIVE COMPONENTS ........................... 22
Component Parts (RS6F51A) ................................. 23
CASE AND HOUSING COMPONENTS .............. 23
GEAR COMPONENTS ....................................... 24
SHIFT CONTROL COMPONENTS ..................... 26
FINAL DRIVE COMPONENTS ........................... 27
Disassembly and Assembly (RS5F51A) ................. 27
DISASSEMBLY ................................................... 27
ASSEMBLY ......................................................... 30
Disassembly and Assembly (RS6F51A) ................. 35
DISASSEMBLY ................................................... 35
ASSEMBLY ......................................................... 39
Adjustment (RS5F51A) ........................................... 44
INPUTSHAFT END PLAY ................................... 44
DIFFERENTIAL SIDE BEARING PRELOAD ...... 45
MAINSHAFT END PLAY ..................................... 46
REVERSE IDLER GEAR END PLAY .................. 47
Adjustment (RS6F51A) ........................................... 48
INPUTSHAFT END PLAY ................................... 48
DIFFERENTIAL SIDE BEARING PRELOAD ...... 49
MAINSHAFT END PLAY ..................................... 51
REVERSE IDLER GEAR END PLAY .................. 52
INPUT SHAFT AND GEARS .................................... 53
Assembly and Disassembly (RS5F51A) ................. 53
DISASSEMBLY ................................................... 53
INSPECTION AFTER DISASSEMBLY ................ 54
ASSEMBLY ......................................................... 55
Assembly and Disassembly (RS6F51A) ................. 60
DISASSEMBLY ................................................... 60
INSPECTION AFTER DISASSEMBLY ................ 61
ASSEMBLY ......................................................... 62
MAINSHAFT AND GEARS ....................................... 67
Assembly and Disassembly (RS5F51A) ................. 67
DISASSEMBLY ................................................... 67
INSPECTION AFTER DISASSEMBLY ................ 68
Page 2538 of 3066

MT-2
ASSEMBLY ......................................................... 70
Assembly and Disassembly (RS6F51A) ................. 74
DISASSEMBLY ................................................... 74
INSPECTION AFTER DISASSEMBLY ................ 76
ASSEMBLY ......................................................... 77
REVERSE IDLER SHAFT AND GEARS .................. 83
Assembly and Disassembly (RS5F51A) ................. 83
DISASSEMBLY ................................................... 83
INSPECTION AFTER DISASSEMBLY ................ 83
ASSEMBLY ......................................................... 84
Assembly and Disassembly (RS6F51A) ................. 84
DISASSEMBLY ................................................... 84
INSPECTION AFTER DISASSEMBLY ................ 84
ASSEMBLY ......................................................... 85
FINAL DRIVE ............................................................ 86
Assembly and Disassembly (RS5F51A) ................. 86
PRE-INSPECTION .............................................. 86
DISASSEMBLY ................................................... 86
INSPECTION AFTER DISASSEMBLY ................ 87
ASSEMBLY ......................................................... 87
Assembly and Disassembly (RS6F51A) ................. 89
PRE-INSPECTION .............................................. 89
DISASSEMBLY ................................................... 90
INSPECTION AFTER DISASSEMBLY ................ 91
ASSEMBLY ......................................................... 91
SHIFT CONTROL ...................................................... 94
Inspection (RS5F51A) ............................................ 94
SHIFT FORK ....................................................... 94
Inspection (RS6F51A) ............................................ 95
SHIFT FORK ....................................................... 95SERVICE DATA AND SPECIFICATIONS (SDS) ......96
General Specifications ............................................96
TRANSAXLE ........................................................96
FINAL GEAR ........................................................97
Gear End Play .........................................................97
Clearance Between Baulk Ring and Gear ..............97
3RD,4TH,5TH,6TH & REVERSE BAULK RING... 97
1ST AND 2ND DOUBLE BAULK RING ...............97
Available Snap Rings ..............................................98
INPUT SHAFT SPACER ......................................98
5TH MAIN GEAR .................................................98
Available C-rings .....................................................98
MAINSHAFT C-RING ..........................................98
Available Thrust Washer .........................................98
INPUT SHAFT THRUST WASHER .....................98
DIFFERENTIALSIDE GEAR THRUST WASHER
...99
Available Adjusting Shims .......................................99
MAINSHAFT ADJUSTING SHIM .........................99
INPUT SAFT REAR BEARING ADJUSTING
SHIM ....................................................................99
MAINSAFT REAR BEARING ADJUSTING SHIM.100
REVERASE IDLER GEAR ADJUSTING SHIM . 100
6TH MAIN GEAR ADJUSTING SHIM ................ 100
Available Shims .................................................... 100
BEARING PRELOAD ......................................... 100
DIFFERENTIAL SIDE BEARING ADJUSTING
SHIM(S) ............................................................. 100
Page 2539 of 3066
PRECAUTIONS
MT-3
D
E
F
G
H
I
J
K
L
MA
B
MT
PRECAUTIONSPFP:00001
CautionECS001WO
lDo not reuse transaxle oil, once it has been drained.
lCheck oil level or replace oil with vehicle on level ground.
lDuring removal or installation, keep inside of transaxle clear of dust or dirt.
lCheck for the correct installation status prior to removal or disassembly. If mating marks are required, be
certain they do not interfere with the function of the parts they are applied to.
lIn principle, tighten bolts or nuts gradually in several steps working diagonally from inside to outside. If
tightening sequence is specified, observe it.
lBe careful not to damage sliding surfaces and mating surfaces.
Page 2540 of 3066

MT-4
PREPARATION
PREPARATION
PFP:00002
Special Service ToolsECS001WP
Tool name
Tool numberDescription
Drift
ST33400001
a: 60 mm (2.36 in) dia.
b: 47 mm (1.85 in) dia.
Installing transaxle side oil seal.
Drift
KV40100621
a: 76 mm (2.99 in) dia.
b: 69 mm (2.72 in) dia.
Puller
KV381054S0Side bearing outer race removal
Drift
ST35321000
a: 49 mm (1.93 in) dia.
b: 41 mm (1.61 in) dia.
lInput shaft oil seal installation
lReverse main gear installation
l1st bushing installation
l1st-2nd synchronizer hub installation
l2nd bushing installation
l3rd main gear installation
lDifferential side bearing removal
Drift
ST30720000
a: 77 mm (3.03 in) dia.
b: 55.5 mm (2.185 in) dia.
lDifferential oil seal installation
lDifferential side bearing outer race
installation
lMainshaft rear bearing installation
lDifferential side bearing installation
Drift
ST33200000
a: 60 mm (2.36 in) dia.
b: 44.5 mm (1.752 in) dia.
lMainshaft front bearing installation
l6th bushing installation (RS6F51A)
l4th main gear installation
l5th main gear installation
l6th main gear installation (RS6F51A)
Drift
KV40105320
a: 88 mm (3.46 in) dia.
lDifferential side bearing outer race
installation
ZZA0814D
ZZA0814D
ZZA0601D
ZZA1000D
ZZA0811D
ZZA1002D
ZZA0898D
Page 2541 of 3066

PREPARATION
MT-5
D
E
F
G
H
I
J
K
L
MA
B
MT
Drift
ST33061000
a: 38 mm (1.50 in) dia.
b: 28.5 mm (1.122 in) dia.lBore plug installation
lDifferential side bearing removal
Drift
ST33052000
a: 22 mm (0.87 in) dia.
b: 28 mm (1.10 in) dia.
lInput shaft rear bearing removal and
installation
lInput shaft bearing spacer and 5th stopper
removal
l5th bushing, thrust washer, 4th input gear,
4th gear bushing, 3rd-4th synchronizer
hub and 3rd input gear removal
lInput shaft front bearing installation
l6th input gear and 6th bushing removal
(RS6F51A)
lMainshaft rear bearing removal
l4th main gear and 5th main gear removal
Drift
KV40105020
a: 39.7 mm (1.563 in) dia.
b: 35 mm (1.38 in) dia.
c: 15 mm (0.59 in).
l5th input gear and synchronizer hub
removal
l3rd main gear, 2nd main gear, 2nd
bushing, 1st-2nd synchronizer hub, 1st
main gear, reverse main gear and 1st
bushing removal
Press stand
KV40105710
a: 46 mm (1.81 in) dia.
b: 41 mm (1.61 in).
l3rd-4th synchronizer hub installation
l4th bushing installation
l5th bushing installation (RS5F51A)
l5th synchronizer hub installation
(RS5F51A)
l5th-6th synchronizer hub installation
(RS6F51A)
l2nd bushing installation
l3rd main gear installation
Press stand
ST38220000
a: 63 mm (2.48 in) dia.
b: 65 mm (2.56 in).
lReverse main gear installation
l1st bushing installation
Drift
ST30032000
a: 80 mm (3.15 in) dia.
b: 38 mm (1.50 in) dia.
c: 31 mm (1.22 in) dia.
l5th stopper and input shaft bearing spacer
installation
lInput shaft front bearing installation
l1st-2nd synchronizer hub installation To o l n a m e
Tool numberDescription
ZZA1000D
ZZA1023D
ZZA1133D
ZZA1058D
ZZA1058D
ZZA0978D
Page 2542 of 3066
MT-6
PREPARATION
Commercial Service Tools
ECS004NA
Drift
ST30901000
a: 79 mm (3.11 in) dia.
b: 45 mm (1.77 in) dia.
c: 35.2 mm (1.386 in) dia.lInput shaft rear bearing installation
l4th main gear installation
l5th main gear installation
lMainshaft rear bearing installation
Puller
ST30031000
lMeasuring wear of 1st and 2nd baulk ring
Drift
KV40101630
a: 68 mm (2.68 in) dia.
b: 60 mm (2.36 in) dia.
lReverse main gear installation
Drift
KV38102510
a: 71 mm (2.80 in) dia.
b: 65 mm (2.56 in) dia.
l1st bushing installation
l1st-2nd synchronizer hub installation
lDifferential side bearing installation
Drift
KV40104830
a: 70 mm (2.76 in) dia.
b: 63.5 mm (2.500 in) dia.
lDifferential side bearing installation Tool name
Tool numberDescription
ZZA0978D
ZZA0537D
ZZA1003D
ZZA0838D
ZZA0936D
Tool nameDescription
PullerEach bearing gear and bushing removal
ZZA0537D
Page 2543 of 3066
PREPARATION
MT-7
D
E
F
G
H
I
J
K
L
MA
B
MT
PullerEach bearing gear and bushing removal
Pin punch
Tip diameter: 4.5 mm (0.177 in) dia.Each retaining pin removal and installation To o l n a m eDescription
NT077
ZZA0815D
Page 2544 of 3066

MT-8
NOISE, VIBRATION, AND HARSHNESS (NVH) TROUBLESHOOTING
NOISE, VIBRATION, AND HARSHNESS (NVH) TROUBLESHOOTING
PFP:00003
NVH Troubleshooting ChartECS0044N
Use the chart below to help you find the cause of the symptom. The numbers indicate the order of the inspec-
tion. If necessary, repair or replace these parts.
MANUAL TRANSAXLE
Reference pageMA-35
MT-18
(RS5F51A),MT-23
(RS6F51A)
MT-18
(RS5F51A),MT-23
(RS6F51A)
MT-18
(RS5F51A),MT-23
(RS6F51A)
MT-14
MT-21
(RS5F51A),MT-26
(RS6F51A)
MT-21
(RS5F51A),MT-26
(RS6F51A)
MT-19
(RS5F51A),MT-24
(RS6F51A)
MT-19
(RS5F51A),MT-24
(RS6F51A)
MT-19
(RS5F51A),MT-24
(RS6F51A)
MT-19
(RS5F51A),MT-24
(RS6F51A)
SUSPECTED PARTS
(Possible cause)
OIL (Oil level is low.)
OIL(Wrongoil.)
OIL (Oil level is high.)
GASKET (Damaged)
OIL SEAL (Worn or damaged)
O-RING (Worn or damaged)
SHIFT CONTROL LINKAGE (Worn)
CHECK PLUG RETURN SPRING AND CHECK BALL (Worn or damaged)
SHIFT FORK (Worn)
GEAR (Worn or damaged)
BEARING (Worn or damaged)
BAULK RING (Worn or damaged)
INSERT SPRING (Damaged)
SymptomsNoise 1 2 3 3
Oilleakage 31222
Hard to shift or will not shift 1 1 2 3 3
Jumps out of gear 1 2 3 3
