Page 305 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual TROUBLE DIAGNOSIS — BASIC INSPECTION AT-299 [EXC.F/EURO-OBD] D E F G H I J K L MA B AT 14. Touch “DISPLAY”. 15. Touch “PRINT”. 16. Check the monitor data printed out. 17. Continue cruise tes

Page 306 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual AT-300 [EXC.F/EURO-OBD] TROUBLE DIAGNOSIS — BASIC INSPECTION Cruise Test — Part 1 1.CHECKSTARTINGGEAR(D1) POSITION 1. Drive vehicle for approx. 10 minutes to warm engine oil and ATF up to operatin

Page 307 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual TROUBLE DIAGNOSIS — BASIC INSPECTION AT-301 [EXC.F/EURO-OBD] D E F G H I J K L MA B AT 2.CHECK SHIFT UP (D1TO D2) Does A/T shift from D 1to D2at the specified speed? Read gear position, throttle ope

Page 308 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual AT-302 [EXC.F/EURO-OBD] TROUBLE DIAGNOSIS — BASIC INSPECTION 5.CHECK LOCK-UP (D4TO D4L/U) Does A/T perform lock-up at the specified speed? Read vehicle speed, throttle position when lock-up duty bec

Page 309 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual TROUBLE DIAGNOSIS — BASIC INSPECTION AT-303 [EXC.F/EURO-OBD] D E F G H I J K L MA B AT Cruise Test — Part 2 1.CHECK STARTING GEAR (D1) POSITION 1. Confirm overdrive control switch is in “ON” p

Page 310 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual AT-304 [EXC.F/EURO-OBD] TROUBLE DIAGNOSIS — BASIC INSPECTION 4.CHECK SHIFT UP (D3TO D4) AND ENGINE BRAKE Release accelerator pedal after shifting from D 2to D3. Does A/T shift from D 3to D4and does

Page 311 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual TROUBLE DIAGNOSIS — BASIC INSPECTION AT-305 [EXC.F/EURO-OBD] D E F G H I J K L MA B AT Cruise Test — Part 3 1.CHECK SHIFT DOWN (D4TO D3) 1. Confirm overdrive control switch is in “ON” position

Page 312 of 3066

NISSAN X-TRAIL 2003 Electronic Repair Manual AT-306 [EXC.F/EURO-OBD] TROUBLE DIAGNOSIS — BASIC INSPECTION 2.CHECK ENGINE BRAKE Does vehicle decelerate by engine brake? Ye s o r N o Yes >>GOTO3 No >> Go To "15. Engine Speed Does Not Return To I
