3. Drive and pull out parking rod plate retaining pin.
4. Remove parking rod plate from manual shaft.
5. Draw out parking rod from transmission case.
6. Pull out manual shaft retaining pin.
7. Remove manual shaft and manual plate from transmission case.
8. Remove manual shaft oil seal.
INSPECTION
lCheck component parts for wear or damage. Replace if necessary.
INSTALLATION
1. Install manual shaft oil seal.
lApply ATF to outer surface of oil seal.
SAT043FC
SAT049F
SAT080D
SAT081D
Page 490 of 3066
AT-484
[ALL]
REPAIR FOR COMPONENT PARTS
2. Install manual shaft and manual plate.
3. Align groove of manual shaft and hole of transmission case.
4. Install manual shaft retaining pin up to bottom of hole.
5. Install parking rod to parking rod plate.
6. Set parking rod assembly onto manual shaft and drive retaining
pin.
lBoth ends of pin should protrude.
7. Drive manual plate retaining pin.
lBoth ends of pin should protrude.
8. Install detent spring. Tighten detent spring bolts to the specified
torque. Refer toAT-482, "
REPAIR FOR COMPONENT PARTS"
.
SAT044F
SAT045FC
SAT034JA
SAT047FC
SAT042F
Page 491 of 3066
REPAIR FOR COMPONENT PARTS
AT-485
[ALL]
D
E
F
G
H
I
J
K
L
MA
B
AT
Oil PumpECS004M1
COMPONENTS
DISASSEMBLY
1. Remove seal rings.
2. Loosen bolts in a crisscross pattern and remove oil pump cover.
3. Remove inner and outer gear from oil pump housing.
SCIA0802E
SAT699H
SAT051F
SAT092D
Page 492 of 3066
AT-486
[ALL]
REPAIR FOR COMPONENT PARTS
4. Remove O-ring from oil pump housing.
5. Remove oil pump housing oil seal.
INSPECTION
Oil Pump Housing, Oil Pump Cover, Inner Gear and Outer Gear
lCheck for wear or damage.
Side Clearances
lMeasure side clearance of inner and outer gears in at least four
places around each outside edge. Maximum measured values
should be within specified positions.
lIf clearance is less than standard, select inner and outer gear as
a set so that clearance is within specifications.
lIf clearance is more than standard, replace whole oil pump
assembly except oil pump cover.
SAT093D
SAT094D
Standard clearance: 0.030 - 0.050 mm (0.0012 - 0.0020 in)
Inner and outer gear:
Refer toAT- 5 6 3 , "
SERVICE DATA AND SPECIFICA-
TIONS (SDS)"
SAT095D
Page 493 of 3066
REPAIR FOR COMPONENT PARTS
AT-487
[ALL]
D
E
F
G
H
I
J
K
L
MA
B
AT
lMeasure clearance between outer gear and oil pump housing.
lIf not within allowable limit, replace whole oil pump assembly
except oil pump cover.
Seal Ring Clearance
lMeasure clearance between seal ring and ring groove.
lIf not within allowable limit, replace oil pump cover assembly.
ASSEMBLY
1. Install oil seal on oil pump housing.
2. Install O-ring on oil pump housing.
lApply ATF to O-ring. Standard clearance: 0.111 - 0.181 mm (0.0044 - 0.0071 in)
Allowable limit: 0.181 mm (0.0071 in)
SAT096D
Standard clearance: 0.1 - 0.25 mm (0.0039 - 0.0098 in)
Allowable limit: 0.25 mm (0.0098 in)
SAT097D
SAT900DA
SAT093D
Page 494 of 3066
AT-488
[ALL]
REPAIR FOR COMPONENT PARTS
3. Install inner and outer gears on oil pump housing.
lBe careful of direction of inner gear.
4. Install oil pump cover on oil pump housing.
a. Wrap masking tape around splines of oil pump cover assembly
to protect seal. Position oil pump cover assembly on oil pump
housing assembly, then remove masking tape.
b. Tighten bolts in a crisscross pattern. Tighten oil pump cover
bolts to the specified torque. Refer toAT-489, "
Control Valve
Assembly".
5. Install new seal rings carefully after packing ring groove with
petroleum jelly.
lDo not spread gap of seal ring excessively while install-
ing. The ring may be deformed.
SAT092D
SAT051F
SAT699H
Page 495 of 3066
REPAIR FOR COMPONENT PARTS
AT-489
[ALL]
D
E
F
G
H
I
J
K
L
MA
B
AT
Control Valve AssemblyECS004M2
COMPONENTS
1. Oil strainer 2. O-ring 3. Snap ring
4. Terminal body 5. O-rings 6. Control valve lower body
7. Oil cooler relief valve spring 8. Check ball 9. Separating plate
10. Support plate 11. Steel ball 12. Control valve inter body
13. Pilot filter 14. Separating plate 15. Steel ball
16. Control valve upper body 17 Solenoid valve assembly
SCIA0803E
Page 496 of 3066
AT-490
[ALL]
REPAIR FOR COMPONENT PARTS
DISASSEMBLY
Disassemble upper, inter and lower bodies.
Bolt length, number and location:
f: Reamer bolt and nut.
1. Remove boltsa,dand nutfand remove oil strainer from con-
trol valve assembly.
2. Remove solenoid valve assembly and line pressure solenoid
valve from control valve assembly.
Bolt symbolabcde f g
Bolt length “ ” mm (in)
13.5
(0.531)58.0
(2.283)40.0
(1.575)66.0
(2.598)33.0
(1.299)78.0
(3.071)18.0
(0.709)
Numberofbolts 63611221
SAT704J
AAT780
SAT062F
