Page 2753 of 3613
Sistema de Control Climático — Información General412-00-167
412-00-167
DIAGNOSTICO Y PRUEBA (Continuación)
Prueba Pinpoint Q: EL MOTOR SOPLADOR FUNCIONA CONTINUAMENTE A ALTA VELOCIDAD - EATC
CONDICIONES DE PRUEBADETALLES/RESULTADOS/ACCIONES
Q1VERIFIQUE EL FUNCIONAMIENTO DEL MOTOR SOPLADOR
3
2Pulse el botón MAX A/C del control electrónico automático
de temperatura (EATC).
3Ajuste la perilla del motor soplador EATC a HI y luego a LO.
• ¿La velocidad del motor soplador aumenta y luego baja?
® ®® ®
®Si
El sistema está funcionando normalmente.
® ®® ®
®No
Vaya a Q2.
2
1
procarmanuals.com
Page 2754 of 3613
Sistema de Control Climático — Información General412-00-168
412-00-168
DIAGNOSTICO Y PRUEBA (Continuación)
Prueba Pinpoint Q: EL MOTOR SOPLADOR FUNCIONA CONTINUAMENTE A ALTA VELOCIDAD - EATC (Continuación)
CONDICIONES DE PRUEBADETALLES/RESULTADOS/ACCIONES
Q2VERIFIQUE LOS CONTROLES REMOTOS
5
4Pulse el botón MAX A/C del control electrónico automático
de temperatura (EATC).
5Ajuste la perilla del motor soplador EATC a HI y luego a LO.
• ¿La velocidad del motor soplador aumenta y luego baja?
® ®® ®
®Si
VAYA a Prueba Pinpoint T.
® ®® ®
®No
Vaya a Q3.
312
C220 del Resorte del Reloj
4
procarmanuals.com
Page 2755 of 3613
Sistema de Control Climático — Información General412-00-169
412-00-169
DIAGNOSTICO Y PRUEBA (Continuación)
Prueba Pinpoint Q: EL MOTOR SOPLADOR FUNCIONA CONTINUAMENTE A ALTA VELOCIDAD - EATC (Continuación)
312
132
CONDICIONES DE PRUEBADETALLES/RESULTADOS/ACCIONES
Q3VERIFIQUE EL CIRCUITO 261 (O/BK)
Q4VERIFIQUE EL CONTROL DE VELOCIDAD DEL MOTOR SOPLADOR DEL A/C
• ¿Está funcionando el motor soplador?
® ®® ®
®Si
INSTALE un control nuevo de velocidad del motor
soplador. PRUEBE si el sistema funciona normalmente.
® ®® ®
®No
Vaya a Q5. • ¿Está funcionando el motor soplador?
® ®® ®
®Si
REPARE el Circuito 261 (O/BK), está en corto a tierra.
PRUEBE si el sistema funciona normalmente.
® ®® ®
®No
Vaya a Q4.
C179 del Control de Velocidad
del motor Soplador del A/C
C179 del Control de Velocidad
del Motor Soplador del A/CC297 del EATC
procarmanuals.com
Page 2756 of 3613

Sistema de Control Climático — Información General412-00-170
412-00-170
DIAGNOSTICO Y PRUEBA (Continuación)
Prueba Pinpoint Q: EL MOTOR SOPLADOR FUNCIONA CONTINUAMENTE A ALTA VELOCIDAD - EATC (Continuación)
CONDICIONES DE PRUEBADETALLES/RESULTADOS/ACCIONES
Q5VERIFIQUE EL CIRCUITO 181 (BR/O)
3
Q6VERIFIQUE EL CIRCUITO 184 (T/O)
1Mida la resistencia entre el C297-10, circuito 184 (T/O) del
control electrónico automático de temperatura (EATC) y el
C179-1, circuito 184 (T/O) del control de velocidad del motor
soplador del A/C. Mida la resistencia a tierra del C297-10,
circuito 184 (T/O) del EATC.
• ¿Es inferior a 5 Ohmios entre el EATC y el control de
velocidad del motor soplador y mayor a 10.000 Ohmios
entre el EATC y tierra?
® ®® ®
®Si
Vaya a Q7.
® ®® ®
®No
REPARE el Circuito 184 (T/O). PRUEBE si el sistema
funciona normalmente.
3Mida la resistencia entre el C297-23, circuito 181 (BR/O) del
control electrónico automático de temperatura (EATC) y el
C179-2, circuito 181 (BR/O) del control de velocidad del
motor soplador del A/C. Mida la resistencia a tierra del C297-
23, circuito 181 (BR/O) del EATC.
• ¿Es inferior a 5 Ohmios entre el EATC y el control de
velocidad del motor soplador y mayor a 10.000 Ohmios
entre el EATC y tierra?
® ®® ®
®Si
Vaya a Q6.
® ®® ®
®No
REPARE el Circuito 181 (BR/O). PRUEBE si el sistema
funciona normalmente.
1
12
C179 del Control de Velocidad
del motor Soplador del A/C
procarmanuals.com
Page 2757 of 3613

Sistema de Control Climático — Información General412-00-171
412-00-171
DIAGNOSTICO Y PRUEBA (Continuación)
Prueba Pinpoint Q: EL MOTOR SOPLADOR FUNCIONA CONTINUAMENTE A ALTA VELOCIDAD - EATC (Continuación)
CONDICIONES DE PRUEBADETALLES/RESULTADOS/ACCIONES
Q7VERIFIQUE SI EL CIRCUITO 775 (W/PK) ESTÁ EN CORTO A TIERRA
1
Q8VERIFIQUE SI EL CIRCUITO 775 (W/PK) ESTÁ ABIERTO
1Mida la resistencia del circuito 775 (W/PK) entre el C228-24
del conector del EATC y el C179-3 del conector del control
de velocidad del motor soplador del A/C.
• ¿Es inferior a 5 Ohmios?
® ®® ®
®Si
INSTALE un nuevo módulo EATC. PRUEBE si el
sistema funciona normalmente.
® ®® ®
®No
REPARE el Circuito 775 (W/PK), está abierto. PRUEBE
si el sistema funciona normalmente.
1Mida la resistencia a tierra del C298-24, circuito 775 (W/PK)
del conector del EATC.
• ¿Es mayor a 10.000 Ohmios?
® ®® ®
®Si
Vaya a Q8.
® ®® ®
®No
REPARE el Circuito 775 (W/PK), está en corto a tierra.
PRUEBE si el sistema funciona normalmente.
1
procarmanuals.com
Page 2758 of 3613
Sistema de Control Climático — Información General412-00-172
412-00-172
DIAGNOSTICO Y PRUEBA (Continuación)
CONDICIONES DE PRUEBADETALLES/RESULTADOS/ACCIONES
R1VERIFIQUE LA VELOCIDAD DEL MOTOR SOPLADOR
3
2Gire el interruptor de funciones del A/C a la posición FLOOR.
3Gire el interruptor del motor soplador a alta.
• ¿Funciona en alta velocidad el motor soplador?
® ®® ®
®Si
GIRE varias veces el interruptor del motor soplador
de high a low varias veces. Si el soplador funciona,
aconséjele al propietario como funciona el sistema. Si
el soplador no funciona en alta cada vez. INSTALE
un nuevo interruptor del motor soplador.
® ®® ®
®No
Vaya a R2.
2
1
Prueba Pinpoint R: NO HAY OPERACIÓN EN POSICIÓN HIGH DEL SOPLADOR - A/C MANUAL
procarmanuals.com
Page 2759 of 3613
Sistema de Control Climático — Información General412-00-173
412-00-173
DIAGNOSTICO Y PRUEBA (Continuación)
Prueba Pinpoint R: NO HAY OPERACIÓN EN POSICIÓN HIGH DEL SOPLADOR - A/C MANUAL (Continuación)
1
CONDICIONES DE PRUEBADETALLES/RESULTADOS/ACCIONES
R2REVISE EL INTERRUPTOR DEL MOTOR SOPLADOR
3Mida la resistencia del interruptor del motor soplador.
Refiérase a la tabla mostrada.
• ¿Es inferior a 5 Ohmios?
® ®® ®
®Si
Vaya a R3.
® ®® ®
®No
INSTALE un nuevo interruptor del motor soplador.
PRUEBE si el sistema funciona normalmente.
2
C230 del Interruptor del
Motor Soplador
3
Prueba de Resistencia del Interruptor del Soplador
Posición Resistencia
del Interruptor entre los Terminales
Low Ninguna
Medium/Low 2 y 3 solamente
Medium/High 2, 3 y 4 solamente
High 1, 2, y 4 solamente
procarmanuals.com
Page 2760 of 3613
Sistema de Control Climático — Información General412-00-174
412-00-174
DIAGNOSTICO Y PRUEBA (Continuación)
Prueba Pinpoint R: NO HAY OPERACIÓN EN POSICIÓN HIGH DEL SOPLADOR - A/C MANUAL (Continuación)
CONDICIONES DE PRUEBADETALLES/RESULTADOS/ACCIONES
R3VERIFIQUE SI EL CIRCUITO 261 (O/BK) ESTÁ ABIERTO
2
R4VERIFIQUE SI EL CIRCUITO 57 (BK) ESTÁ ABIERTO
1Mida la resistencia a tierra del pin 87, circuito 57 (BK) del
conector del relé de alta velocidad del motor soplador.
• ¿Es igual o menor a 5 Ohmios?
® ®® ®
®Si
Vaya a R4.
® ®® ®
®No
REPARE el Circuito 261. PRUEBE si el sistema
funciona normalmente.
2Mida la resistencia a tierra del pin 85, circuito 261 (O/BK) del
conector del relé de alta velocidad del motor soplador.
• ¿Es igual o menor a 5 Ohmios?
® ®® ®
®Si
Vaya a R4.
® ®® ®
®No
REPARE el Circuito 261 (O/BK). PRUEBE si el sistema
funciona normalmente.
1
1
Relé de Alta Velocidad del Motor Soplador
procarmanuals.com
