Page 937 of 3039

JAGUAR XFR 2010 1.G Workshop Manual

Page 938 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 17. 18. CAUTIONS: If a new cylinder head has been installed then new tappets must be installed. If the cylinder head is being removed without a new component being installed, the ta

Page 939 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Installation 19. 1. CAUTION: An acceptable flatness of the cylinder head is 0.1mm. Check cylinder head face for distortion, across the center and from corner to corner.

Page 940 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 3. CAUTION: Make sure that new cylinder head bolts are installed. NOTE: Tighten the bolts in the indicated sequence. Torque: 20 Nm 4. N

Page 941 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 5. NOTE: Tighten the bolts in the indicated sequence. Tighten the bolts 1 to 10, a further 90 degrees. 6. NOTE: Tighten the bolts in

Page 942 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 7. 8. 9. 10. Torque: 25 Nm NOTE: Tighten the bolts in the indicated sequence. Torque: 12 Nm

Page 943 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 11. 12. 13. CAUTION: Install the new seals. Torque: 10 Nm

Page 944 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 14. 15. 16. CAUTION: Install a new seal. NOTE: Engine shown removed for clarity. Torque: 12 Nm
