JAGUAR XFR 2010 1.G Workshop Manual Installation). Installation 2. 3. NOTE: Do not disassemble further if the component is removed for access only. 1. To install, reverse the r

Page 2586 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Bumpers - Rear Bumper Cover Removal and Installation Removal NOTE: Removal steps may contain installation details. Published: 11-May-2011 1. Remove the rear lamp assemblies. Refer to

Page 2587 of 3039

JAGUAR XFR 2010 1.G Workshop Manual

Page 2588 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Bumpers - Rear Bumper Removal and Installation Removal NOTE: Removal steps in this procedure may contain installation details. Published: 11-May-2011 1. Refer to: Rear Bumper Cover (501

Page 2589 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 1. To install, reverse the removal procedure. www.JagDocs.com

Page 2590 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Front safety belt retractor to seat track retaining bolt 40 30 - Front safety belt retractor retaining bolt 40 30 - Front safety belt D loop retaining bolt 40 30 - Front safety belt buckle retaining b

Page 2591 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Safety Belt System - Safety Belt System - Component Location Description and Operation NOTE: Authoring Template Published: 11-May-2011 Item Description 1 Belt tension sensor - if fitted

Page 2592 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 10 RH rear and center safety belt buckles 11 LH front safety belt 12 LH front safety belt retractor 13 LH front safety belt buckle and pre-tensioner 14 RH front safety belt buckle and pre-tensioner
