Page 1137 of 3039

JAGUAR XFR 2010 1.G Workshop Manual
2. CAUTION: Be prepared to collect escaping coolant.

3.

Page 1138 of 3039

JAGUAR XFR 2010 1.G Workshop Manual
4. CAUTION: Be prepared to collect escaping coolant.

Fill the cooling system, keeping coolant to the upper level
mark of the expansion tank until a steady stream of coolant
is seen running from

Page 1139 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 14. Visually check the engine and cooling system for signs of coolant
leakage.

15. WARNING: When releasing the cooling system pressure, cover the
coolant expansion tank cap with a thick cloth.

Page 1140 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Published: 19-Nov-2013
Engine Cooling - V8 5.0L Petrol/V8 S/C 5.0L Petrol - Auxiliary Radiator
Removal and Installation

Removal

NOTE: Removal steps in this procedure may contain installation

Page 1141 of 3039

JAGUAR XFR 2010 1.G Workshop Manual

8. NOTE: Some variation in the illustrations may occur,
but the essential information is always correct.

Page 1142 of 3039

JAGUAR XFR 2010 1.G Workshop Manual

Page 1143 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Published: 14-Apr-2014
Engine Cooling - V8 5.0L Petrol/V8 S/C 5.0L Petrol - Coolant Expansion Tank
Removal and Installation

Removal

NOTE: Removal steps in this procedure may contain installa

Page 1144 of 3039

JAGUAR XFR 2010 1.G Workshop Manual

Installation 5. CAUTION: Note the fitted position of the component
prior to removal.

NOTES:

Do not disassemble further if the component is
removed for access only.

Make sure that
