Page 1153 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Installation 20. 21. 22. CAUTION:

Page 1154 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Published: 07-Aug-2012 Engine Cooling - V8 5.0L Petrol/V8 S/C 5.0L Petrol - Coolant Pump Vehicles With: Supercharger Removal and Installation Removal NOTE: Removal steps in this procedure m

Page 1155 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 11. 12. 13. 14. Torque: 40 Nm WARNING: Fluid loss is unavoidable

Page 1156 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Installation 15. CAUTION: Note the fitted position of the component prior to removal. 1. To install, reverse the removal procedure.

Page 1157 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Published: 19-Nov-2013 Engine Cooling - V8 5.0L Petrol/V8 S/C 5.0L Petrol - Radiator Vehicles With: Supercharger Removal and Installation Removal NOTE: Removal steps in this procedure may c

Page 1158 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 4. 5. 6. WARNINGS: Since injury such as scalding could be caused by escaping steam or coolant, do not remove the filler cap from the coolant exp

Page 1159 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 9. Refer to: Air Cleaner Outlet Pipe RH (303-12C Intake Air Distribution and Filtering - V8 5.0L Petrol, Removal and Installation). 10. Refer to: Air Cleaner Outlet Pipe T-Connector (303-12D Intake

Page 1160 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 15. 16. 17. Torque: 7 Nm CAUTION: Be prepared to collect escaping coolant.
