Page 2857 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Panel Sheet Metal Repairs, Removal and Installation). 7. Remove the side air curtain module. For additional information, refer to: Side Air Curtain Module (501-20B Supplemental Restraint System, R

Page 2858 of 3039

JAGUAR XFR 2010 1.G Workshop Manual

Page 2859 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 18. 19. 20. NOTE: A drill bit suitable for drilling boron should be used on the boron spot welds. Drill out the boron spot welds as indicated.

Page 2860 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 21. 22. Cut a window in the old panel, above the front door lower hinge reinforcement, to enable access to the spot welds as indicated. NOTE:

Page 2861 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 23. 24. Drill out the spot welds as indicated. NOTE: Care should be taken not to cause damage to remaining panels when separating joints co

Page 2862 of 3039

JAGUAR XFR 2010 1.G Workshop Manual

Page 2863 of 3039

JAGUAR XFR 2010 1.G Workshop Manual

Page 2864 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 10. 11. NOTE: Make sure the adhesive does not encroach into the areas of the MAG plug welds as it will contaminate the weld. Apply adhesive to the
