JAGUAR XFR 2010 1.G Workshop Manual Published: 11-May-2011 Accessory Drive - V8 S/C 5.0L Petrol - Accessory Drive - Overview Description and Operation OVERVIEW The accessory drive is a belt system powered by a pulley attached to

Page 1250 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Accessory Drive - V8 S/C 5.0L Petrol - Accessory Drive Belt Removal and Installation Removal NOTE: Removal steps in this procedure may contain installation details. Published: 11-May-2011

Page 1251 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 7. CAUTIONS: Make sure that the accessory drive belt is correctly aligned to the pulleys. Failure to follow this instruction may result in damage to the vehicle. Clean and inspect the acce

Page 1252 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Published: 11-May-2011 Accessory Drive - V8 S/C 5.0L Petrol - Accessory Drive Belt Idler Pulley Removal and Installation Removal NOTE: Removal steps in this procedure may contain installatio

Page 1253 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Installation 6. Torque: 40 Nm 1. CAUTIONS: Make sure the accessory belt is correctly aligned to the pulleys. Failure to follow this instruction may result in damage to the vehicle.

Page 1254 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Published: 11-May-2011 Accessory Drive - V8 S/C 5.0L Petrol - Accessory Drive Belt Tensioner Removal and Installation Removal NOTE: Removal steps in this procedure may contain installation d

Page 1255 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Published: 11-May-2011 Accessory Drive - V8 S/C 5.0L Petrol - Supercharger Belt Idler Pulley Removal and Installation Removal NOTE: Removal steps in this procedure may contain installation d

Page 1256 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Published: 11-May-2011 Accessory Drive - V8 S/C 5.0L Petrol - Supercharger Belt Tensioner Removal and Installation Removal NOTE: Removal steps in this procedure may contain installation deta
