Page 2233 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 10. 11. WARNING: Failure to follow this instruction may cause damage to the vehicle. CAUTION: Make sure the locating dowe

Page 2234 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Interior Trim and Ornamentation - C-Pillar Lower Trim Panel Removal and Installation Removal NOTE: Removal steps in this procedure may contain installation details. Published: 11-May-2011

Page 2235 of 3039

JAGUAR XFR 2010 1.G Workshop Manual www.JagDocs.com

Page 2236 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 5. 6. Torque: 40 Nm 7. CAUTIONS: Note the fitted position of the component prior to removal. Make sure that these components are installed to the noted removal position.

Page 2237 of 3039

JAGUAR XFR 2010 1.G Workshop Manual

Page 2238 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Interior Trim and Ornamentation - C-Pillar Trim Panel Removal and Installation Removal NOTE: Removal steps in this procedure may contain installation details. Published: 12-May-2014 1. R

Page 2239 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 5.

Page 2240 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 6. CAUTIONS: Make sure the locating dowels are installed correctly. Make sure that the clips are correctly located. Torque: 6 Nm 7. CAUTIONS: Note the fitte
