Page 1201 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Petrol (501-02 Front End Body Panels, Removal and Installation). 23. Refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures).

Page 1202 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 310-197 Remover, Fuel Injector 310-198 Installer, Teflon Seal 310-199 Re-shape Tool, Teflon Seal 310-200-01 Fuel Rail Installation Guide Pins - Threaded 310-200-02 Fuel Rail Instal

Page 1203 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Removal steps in this procedure may contain installation details. Some variation in the illustrations may occur, but the essential information is always correct. 1. Refer to: Petrol and Petrol

Page 1204 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 5.0L Petrol, Removal and Installation). 11. 10. CAUTIONS: Be prepared to collect escaping fluids. Make sure that all openings are sealed. Use new blanking caps.

Page 1205 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 14. 15. 16. NOTE: Engine shown removed for clarity. NOTE: Engine shown removed for clarity.

Page 1206 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 18. 19. 20. 21. NOTE: LH shown RH similar. NOTE: LH shown RH similar. Spec

Page 1207 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 22. 23. 24. CAUTION: Make a note of the fuel injector alignment to the fuel rail prior to removal. NOTE: LH shown RH similar. CA

Page 1208 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Installation 25. 26. 1. CAUTIONS: Do not use a knife to remove the Teflon se
