Page 361 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 22. 23. Torque: M6 9 Nm M10 40 Nm CAUTIONS: Support the engine on a jack. The angle may need to be adjusted during this procedure. Make sure to protect

Page 362 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 26. 27. 28. NOTE: LH illustration shown, RH is similar. Torque: 43 Nm During installation tighten t

Page 363 of 3039

JAGUAR XFR 2010 1.G Workshop Manual General Information, General Procedures).

Page 364 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Tires, Removal and Installation). 3. NOTE: Use an additional wrench to prevent the ball joint rotating. Remove the front stabilizer bar link. Remove and discard the 2 nuts.

Page 365 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Front Suspension - Stabilizer Bar Link Bushing Removal and Installation Special Tool(s) Bush installer 204-340 Bush remove 204-342 Support 204-341 Support 204-339 Remov

Page 366 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 3. Using the special tools, remove and discard the stabilizer bar link bushing. Installation 1. NOTE: Apply water to lubricate the bushing. Using the special tools, ins

Page 367 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Suspension, Removal and Installation). 3. Remove the secondary bulkhead panel LH. For additional information, refer to: Secondary Bulkhead Panel LH - 3.0L NA V6 - AJ27 (501-02 Front End Body Panel

Page 368 of 3039

JAGUAR XFR 2010 1.G Workshop Manual
