Page 1009 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 23. 24. 25. Loosen the Torx screws half a turn each. CAUTIONS: Install new high-pressure fuel supply lines.

Page 1010 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 26. 27. 28. CAUTION: Care must be taken when positioning the fuel rail high-pressure fuel pump cover to one side. NOTE: Fuel rail high-pressure fuel pump

Page 1011 of 3039

JAGUAR XFR 2010 1.G Workshop Manual M6 (2) 11 Nm M8 (3) 25 Nm M5 nut (4) 6 Nm Torque: Unions 21 Nm www.JagDocs.com

Page 1012 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 31. 32. 33. NOTES: Install the bolt and unions finger tight before final tightening. Remove and discard the blanking caps. Torque: Unions 21 Nm M6 11 Nm

Page 1013 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 36. Torque: Unions

Page 1014 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 37. 38. 39. 40. Torque: Unions 21 Nm NOTE: The high-pressure fuel pumps are removed from the illustration

Page 1015 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Torque: 25 Nm Torque: 25 Nm Torque: 55 Nm

Page 1016 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 45. 46. 47. 48. Torque: 12 Nm CAUTION: Install all the bolts finger tight before final tightening. Torque: 25 Nm
