Page 1017 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 49. CAUTIONS: Install all the bolts finger tight before final tightening. The bolts can only be used 3 times, mark the bolts with a center punch. If 2 punch marks are visible, discard the b

Page 1018 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Engine - V8 S/C 5.0L Petrol - Oil Pump Removal and Installation Removal Published: 07-Oct-2011 1. Refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Proced

Page 1019 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 6. 7. CAUTION: Remove and discard the O-ring seal. 8. CAUTION: Remove and discard the O-ring seals.

Page 1020 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Installation 9. CAUTION: Remove and discard the O-ring seal. 1. NOTE: Lubricate and install the new O-ring seals.

Page 1021 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 2. NOTE: Lubricate and install the new O-ring seals. Torque: M8 25 Nm M6 12 Nm 3. NOTE: Lubricate and install the new O-ring seals. 4. Torque:

Page 1022 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 6. NOTE: Tsubaki timing drive only. Install the lower timing chain making sure the coloured chain links align correctly with the fuel rail high-pressure fuel pumps camshaft and crankshaft sprocket

Page 1023 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 7. CAUTION: Make sure that the tensioner spring is correctly located. NOTE: Tsubaki timing drive only. Torque: 21 Nm 8. NOTE: INA timing drive only. Install the lower t

Page 1024 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 9. CAUTION: Make sure that the tensioner spring is correctly located. NOTE: INA timing drive only. Torque: 21 Nm 10. Refer to: Oil Pan Extension (303-01C Engine -
