Page 1457 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Published: 11-May-2011 Automatic Transmission/Transaxle - TDV6 3.0L Diesel /V8 5.0L Petrol/V8 S/C 5.0L Petrol - Input Shaft Seal Removal and Installation Special Tool(s) 100-012 Slide Hamm

Page 1458 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 3. Refer to: Transmission - TDV6 3.0L Diesel (307-01B Automatic Transmission/Transaxle - TDV6 3.0L Diesel /V8 5.0L Petrol/V8 S/C 5.0L Petrol, Removal). Installation 4. Special Tool

Page 1459 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 3. CAUTION: Make sure the torque converter is fully located into the oil pump drive. 4. Refer to: Trans

Page 1460 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 100-012-01 Slide Hammer Adapter 204-264 Pinion Seal Replacer 205-053 Retainer, Drive Flange 303-D121 Puller, General Purpose 308-375 Remover, Input and Output Seal Remova

Page 1461 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Cables, General Procedures). 2. WARNING: Make sure to support the vehicle with axle stands. Raise and support the vehicle. 3. Refer to: Driveshaft - TDV6 3.0L Diesel (205-01 Driveshaft, Remov

Page 1462 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Installation 1. CAUTIONS: Make sure that the mating faces are clean and free of foreign material. Install a new seal. Special Tool(s): 204-264 2. WARNING: Make sure

Page 1463 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Published: 11-May-2011 Automatic Transmission/Transaxle - TDV6 3.0L Diesel /V8 5.0L Petrol/V8 S/C 5.0L Petrol - Transmission Control Module (TCM) and Main Control Valve Body Removal and Installat

Page 1464 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 6. CAUTION: Discard the component. 7. CAUTION: Be prepared to collect escaping fluids. NOTE: Note the position of the manual park brake release.
