Page 905 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Engine - V8 S/C 5.0L Petrol - Camshaft RH Removal and Installation Removal Published: 11-May-2011 CAUTION: Make sure that the orientation and code on the top of the camshaft bearing caps is n

Page 906 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Installation 1. CAUTIONS: Prior to installing the camshafts, position the crankshaft 45 degrees ATDC cylinder 1A to prevent valve/piston collision. Evenly and progressively install and t

Page 907 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Cables, General Procedures).

Page 908 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Engine - V8 S/C 5.0L Petrol - Crankshaft Front Seal Removal and Installation Published: 11-May-2011 Removal NOTE: Removal steps in this procedure may contain installation details. 1. R

Page 909 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Installation 1. CAUTIONS: Do not over tighten the crankshaft front seal. Failure to follow this instruction may result in damage to the vehicle. Take extra care not to damage the seal.

Page 910 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 303-1438 Crankshaft Damper Bolt Remover/Installer 303-1439 Crankshaft Damper Removal Plate 303-1440 Crankshaft Damper Removal/Installation Stud 303-1441 Crankshaft Damper Remov

Page 911 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Removal NOTE: Removal steps in this procedure may contain installation details. 1. Refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures). 2. W

Page 912 of 3039

JAGUAR XFR 2010 1.G Workshop Manual
