42.
43.
Remove the special tool.
Special Tool(s): 303-1447
Torque: 10 Nm
44.
Refer to: Timing Cover (303-01C Engine - V8 5.0L Petrol, Removal and Installation).
45. Connect the battery ground cable.
Refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures).
Page 1058 of 3039
Engine - V8 S/C 5.0L Petrol - Valve Cover LH
Removal and Installation Published: 11-May-2011
Removal
NOTE: Removal steps in this procedure may contain installation details.
1. Refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures).
2. Refer to: Supercharger (303-12D Intake Air Distribution and Filtering - V8 S/C 5.0L Petrol, Removal and Installation).
3. Refer to: Secondary Bulkhead Panel LH - TDV6 3.0L Diesel /V8 5.0L Petrol/V8 S/C 5.0L Petrol (501-02 Front End Body Panels, Removal and Installation).
4. Refer to: Air Cleaner Outlet Pipe LH (303-12D Intake Air Distribution and Filtering - V8 S/C 5.0L Petrol, Removal and Installation).
5. Refer to: Fuel Rail LH (303-04E Fuel Charging and Controls - V8 S/C 5.0L Petrol, Removal and Installation).
6. Torque: 10 Nm 303-1446
Valve Cover Alignment Tool Special Tool(s)
Page 1059 of 3039
7.
Installation
1. CAUTIONS:
Use only a plastic scraper when removing the sealing
material.
Use lint free cloth.
Make sure that the mating faces are clean and free of
corrosion and foreign material.
Installation of the valve cover and tightening must be
carried out within 7 minutes of applying the sealant.
NOTES:
Some variation in the illustrations may occur, but the
essential information is always correct.
Apply two beads of silcone gasket sealant (Loctite
5901) as shown on the illustration. The application of the
sealant must be 1.5mm diameter 12mm long. Install the
valve cover immediately after applying the sealant. The
cover should be fitted directly to the head without smearing
the sealant or the seals.
To install, reverse the removal procedure.
Page 1060 of 3039
3. NOTE: Tighten the bolts in the indicated sequence.
Torque: 13 Nm
Page 1061 of 3039
Engine - V8 S/C 5.0L Petrol - Valve Cover RH
Removal and Installation Published: 11-May-2011
Removal
NOTE: Removal steps in this procedure may contain installation details.
1. Refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures).
2. Refer to: Supercharger (303-12D Intake Air Distribution and Filtering - V8 S/C 5.0L Petrol, Removal and Installation).
3. Refer to: Secondary Bulkhead Panel RH - TDV6 3.0L Diesel /V8 5.0L Petrol/V8 S/C 5.0L Petrol (501-02 Front End Body Panels, Removal and Installation).
4. Refer to: Air Cleaner Outlet Pipe RH (303-12D Intake Air Distribution and Filtering - V8 S/C 5.0L Petrol, Removal and Installation).
5. Refer to: Fuel Rail RH (303-04E Fuel Charging and Controls - V8 S/C 5.0L Petrol, Removal and Installation).
6. NOTE: Some variation in the illustrations may occur, but
the essential information is always correct. 303-1446
Valve Cover Alignment Tool Special Tool(s) www.JagDocs.com
Page 1062 of 3039
Installation 7. NOTE: Some variation in the illustrations may occur,
but the essential information is always correct.
1. CAUTIONS:
Use only a plastic scraper when removing the sealing
material.
Use lint free cloth.
Make sure that the mating faces are clean and free of
corrosion and foreign material.
Installation of the valve cover and tightening must be
carried out within 7 minutes of applying the sealant.
NOTE: Apply two beads of silcone gasket sealant
(Loctite 5901) as shown on the illustration. The application
of the sealant must be 1.5mm diameter 12mm long. Install
the valve cover immediately after applying the sealant. The
cover should be fitted directly to the head without smearing
the sealant or the seals.
To install, reverse the removal procedure.
2. NOTE: Some variation in the illustrations may occur, but
the essential information is always correct.
Special Tool(s): 303-1446
Page 1063 of 3039
3. NOTE: Tighten the bolts in the indicated sequence.
Torque: 13 Nm
Page 1064 of 3039
Engine - V8 S/C 5.0L Petrol - Cylinder Block Oil Gallery Plug
Removal and Installation
Removal
NOTES:
Removal steps in this procedure may contain installation details.
Some variation in the illustrations may occur, but the essential information is always correct. Published: 23-Jul-2011
1. Refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures).
2. WARNING: Make sure to support the vehicle with axle stands.
Raise and support the vehicle.
3. Refer to: Exhaust Manifold RH (303-01C Engine - V8 5.0L Petrol, Removal and Installation).
4.
