Page 1129 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 12. 13. Set the heater controls to maximum. 14. CAUTION: Observe the engine temperature gauge. If the engine starts to over-heat switch off immediately and allow t

Page 1130 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Published: 14-Feb-2013 Engine Cooling - V8 5.0L Petrol/V8 S/C 5.0L Petrol - Cooling System Partial Draining, Filling and Bleeding V8 S/C 5.0L Petrol General Procedures Draining 1. WARNING: Ma

Page 1131 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Filling 1. Refer to: Radiator Splash Shield (501-02 Front End Body Panels, Removal and Installation). 2. Lower the vehicle. 3. 4. CAUTION: Anti-freeze concentration must be maintain

Page 1132 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 5. Continue to fill the coolant until the maximum level is reached. 6. Set the heater controls to maximum. 7. Start engine and increase speed to 2000 rpm for

Page 1133 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 15. WARNING: When releasing the cooling system pressure, cover the coolant expansion tank cap with a thick cloth. CAUTIONS: Since injury such as scalding could be caused by escaping steam or

Page 1134 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Published: 14-Feb-2013 Engine Cooling - V8 5.0L Petrol/V8 S/C 5.0L Petrol - Cooling System Draining, Filling and Bleeding V8 S/C 5.0L Petrol General Procedures Draining 1. WARNING: Make sure

Page 1135 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 7. CAUTION: Be prepared to collect escaping fluids. 8. CAUTION: Be prepared to collect escaping coolant. 9. www.JagDocs.com

Page 1136 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Torque: 50 Nm 12. Carry out the procedure up to step 1 in the filling section three times, filling the cooling system w
