Page 1041 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 5. Install the special tool 303-1445 to the rear of the camshafts making sure the key ways are correctly located into each slot on each of the camshafts. 6. CAUTIONS:

Page 1042 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 7. CAUTIONS: Do not allow the camshaft to rotate. If the VVT is knocked or dropped then the VVT must be replaced. NOTE: Do not tighten at this stage. Install the timing chain with t

Page 1043 of 3039

JAGUAR XFR 2010 1.G Workshop Manual

Page 1044 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 10. 11. Make sure the tensioner piston is fully extended. Then fully depress and lock the tensioner piston with the grenade

Page 1045 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 12. CAUTIONS: Do not allow the camshafts to rotate. If the VVT is knocked or dropped then the VVT must be replaced. NOTE: Do not tighten at this stage. Install the timing chain with

Page 1046 of 3039

JAGUAR XFR 2010 1.G Workshop Manual www.JagDocs.com

Page 1047 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 15. 16. Make sure the tensioner piston is fully extended. Then fully depress and lock the tensioner piston with the grenade

Page 1048 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 18. 17. CAUTION: Do not use mechanical force. Make sure that the tensioners are fully deployed. 19. Release and reposition the oil
