Page 473 of 3039
Installation
1. CAUTION: Make sure that the component is secured in the retainer.
NOTE: Make sure that the component is installed to the noted
removal position.
To install, reverse the removal procedure.
Page 474 of 3039
Published: 11-May-2011
Wheels and Tires - Tire Pressure Monitoring System (TPMS) Module
Removal and Installation
Removal
NOTE: Removal steps in this procedure may contain installation details.
1. Switch the igntion off.
2. Remove the right-hand front seat.
Refer to: Front Seat (501-10 Seating, Removal and Installation).
3. Refer to: B-Pillar Lower Trim Panel (501-05 Interior Trim and Ornamentation, Removal and Installation).
4. Detach and reposition the floor covering.
5. www.JagDocs.com
Page 475 of 3039
Page 476 of 3039
Published: 11-May-2011
Wheels and Tires - Tire Pressure Monitoring System (TPMS) Receiver
Removal and Installation
Removal
NOTES:
Removal steps in this procedure may contain installation details.
The tire pressure monitoring system receiver is installed in the same location on both LHD and RHD vehicles.
1. Switch the ignition off.
2. Remove the left-hand floor console side trim panel.
Refer to: Floor Console Side Trim Panel (501-12 Instrument Panel and Console, Removal and Installation).
3.
Page 477 of 3039
Page 478 of 3039
Wheels and Tires - Wheel and Tire
Removal and Installation
Removal
NOTE: Removal steps in this procedure may contain installation details. Published: 11-May-2011
1. WARNING: Make sure to support the vehicle with axle stands.
Raise and support the vehicle.
Installation
2. Torque: 125 Nm
1. CAUTION: Apply a small amount of grease to the hub and wheel mating
surfaces before installation. Make sure the grease does not come into
contact with the vehicles braking components and the wheel stud
threads. Failure to follow these instructions may result in personal
injury.
To install, reverse the removal procedure.
Page 479 of 3039
1 RH (right-hand) front-spring and damper assembly 2 RH rear suspension height sensor 3 RH rear-spring and damper assembly 4 Rear vertical accelerometer 5 LH (left-hand) rear-spring and damper assembly 6 LH rear suspension height sensor 7 Adaptive damping module 8 LH front-spring and damper assembly www.JagDocs.com
Page 480 of 3039
10 LH front vertical accelerometer 11 RH front suspension height sensor 12 RH front vertical accelerometer
