Page 1225 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 12. 13. 14. NOTES: Install the bolt and unions finger tight before final tightening. Remove and discard the blanking caps. Torque: Unions 21 Nm M6 11 Nm

Page 1226 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 15. 16. NOTE: Engine shown removed for clarity. Torque: 25 Nm 17. Refer to: Generator - V8 5.

Page 1227 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 21. NOTES: Lubricate the union threads with clean engine oil. Do not tighten at this stage. Remove and discard the blanking caps. 22. Torque: Unions 21 Nm Bolts 8 Nm

Page 1228 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Ornamentation, Removal and Installation). 28. Refer to: Secondary Bulkhead Panel RH - TDV6 3.0L Diesel /V8 5.0L Petrol/V8 S/C 5.0L Petrol (501-02 Front End Body Panels, Removal and Installation).

Page 1229 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Published: 11-May-2011 Fuel Charging and Controls - V8 S/C 5.0L Petrol - Right-Hand Fuel Rail High-Pressure Fuel Pump Removal and Installation Removal CAUTION: Make sure that tools and equipm

Page 1230 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 8. 9. CAUTION: Be prepared to collect escaping fluids. 10. Refer to: Air Cleaner Outlet Pipe RH (303-12D Intake Air Distribution and Filtering - V8 S/C 5.0L Petrol,

Page 1231 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 12. 13. CAUTIONS: Be prepared to collect escaping fluids. Make sure that all openings are sealed. Use new blanking caps.

Page 1232 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 18. All vehicles 19. 20. NOTE: Engine shown removed for clarity. www.JagDocs.com
