JAGUAR XFR 2010 1.G Workshop Manual

Page 1306 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Published: 11-May-2011 Intake Air Distribution and Filtering - V8 S/C 5.0L Petrol - Air Cleaner RH Removal and Installation Removal NOTE: Removal steps in this procedure may contain installa

Page 1307 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 4. Torque: 8 Nm 5. NOTES: Do not disassemble further if the component is removed for access only. Some variation in the illustrations may occur, but the e

Page 1308 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Installation 7. NOTES: Some variation in the illustrations may occur, but the essential information is always correct. LH illustration shown, RH is similar. 1. To install, reverse

Page 1309 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Published: 11-May-2011 Intake Air Distribution and Filtering - V8 S/C 5.0L Petrol - Air Cleaner Outlet Pipe LH Removal and Installation Removal NOTE: Removal steps in this procedure may cont

Page 1310 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Published: 11-May-2011 Intake Air Distribution and Filtering - V8 S/C 5.0L Petrol - Air Cleaner Outlet Pipe RH Removal and Installation Removal NOTE: Removal steps in this procedure may cont

Page 1311 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Published: 11-May-2011 Intake Air Distribution and Filtering - V8 S/C 5.0L Petrol - Air Cleaner Outlet Pipe T-Connector Removal and Installation Removal NOTE: Removal steps in this procedure

Page 1312 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Published: 08-Nov-2013 Intake Air Distribution and Filtering - V8 S/C 5.0L Petrol - Charge Air Cooler Removal and Installation Removal NOTE: Removal steps in this procedure may contain instal
