Page 2553 of 3039
Wipers and Washers - Windshield Wiper Motor
Removal and Installation
Removal
NOTE: Removal steps in this procedure may contain installation details. Published: 11-May-2011
1. Refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures).
2. Refer to: Cowl Vent Screen (501-02 Front End Body Panels, Removal and Installation).
3. CAUTION: Tighten the bolts in the sequence shown.
NOTE: LHD illustration shown, RHD is similar.
Torque: 12 Nm
4. NOTE: LHD illustration shown, RHD is similar.
5. NOTE: LHD illustration shown, RHD is similar.
Page 2554 of 3039
Installation 6. CAUTION: Make sure that the component is correctly
located on the locating dowels.
NOTE: LHD illustration shown, RHD is similar.
1. To install, reverse the removal procedure. www.JagDocs.com
Page 2555 of 3039
Wipers and Washers - Windshield Wiper Pivot Arm
Removal and Installation
Removal
CAUTION: Always protect paintwork and glass when removing exterior components.
1. Published: 11-May-2011
Installation
2. NOTE: Do not disassemble further if the component is
removed for access only.
1. Install the wiper blade.
2. CAUTION: Align the wiper blades onto the centre of the
windshield circle mark.
NOTE: After the wiper pivot arm nuts have been
tightened to the correct torque value, lift the wiper pivot
arm from the windshield and return to the windshield. Make
sure that wiper blades are not positioned below any point
of the windshield circle mark.
Page 2556 of 3039
Page 2557 of 3039
Wipers and Washers - Windshield Washer Pump
Removal and Installation
Removal Published: 11-May-2011
1. Refer to: Fender Splash Shield (501-02 Front End Body Panels, Removal and Installation).
Installation
2.
3. CAUTION: Be prepared to collect escaping fluids.
4. CAUTION: Take extra care not to damage the seal.
1. CAUTION: The seal is to be reused unless damaged.
To install, reverse the removal procedure.
Page 2558 of 3039
Roof opening panel frame retaining bolts 9 — 80 Roof opening panel motor retaining bolts 4 — 35 Roof opening panel glass retaining screws 4 — 35
Page 2559 of 3039
Published: 11-May-2011
Roof Opening Panel - Roof Opening Panel - Component Location
Description and Operation
Component Location
Item Description 1 CJB (central junction box) 2 Roof opening panel, rocker switch 3 Rear window sunblind, switch 4 Roof opening panel, motor 5 Roof opening panel, control module 6 Roof opening panel 7 Rear window sunblind 8 Rear window sunblind, motor assembly 9 Drain tubes (4 off) 10 ABS (anti-lock brake system) module www.JagDocs.com
