Page 3025 of 3039
10. Remove the special tool.
Special Tool(s): 502-005
11.
Torque:
Stage 1: 100 Nm Stage 2: 270°
12. CAUTION:
Make sure each bolt aligns with the removal markings.
Torque: 175 Nm
Page 3026 of 3039
13. CAUTION:
Make sure each bolt aligns with the removal markings.
Torque: 175 Nm
14.
15.
NOTE: Repeat the step for the other side.
Torque: 175 Nm
Torque: 43 Nm
Page 3027 of 3039
17.
Torque: 100 Nm
18. Torque: 45 Nm www.JagDocs.com
Page 3028 of 3039
Page 3029 of 3039
Page 3030 of 3039
24.
25.
CAUTION:
Make sure to protect the paintwork.
Special Tool(s): 303-1436 Special Tool(s): 303-021
Page 3031 of 3039
27. Release the radiator assembly.
28.
Refer to: Engine Cover - V8 5.0L Petrol/V8 S/C 5.0L Petrol (501-05 Interior Trim and Ornamentation, Removal and Installation).
29. Refer to: Air Deflector (501-02 Front End Body Panels, Removal and Installation). 30. Refer to: Radiator Splash Shield (501-02 Front End Body Panels, Removal and Installation). 31. Refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures).
32.
Refer to: Camber and Caster Adjustment (204-00 Suspension System - General Information, General Procedures).
Page 3032 of 3039

Published: 11-May-2011
Uni-Body, Subframe and Mounting System - Rear Subframe V8 5.0L Petrol/V8 S/C 5.0L Petrol
Removal and Installation
General Equipment
Removal
NOTE: Removal steps in this procedure may contain installation details.
1. Refer to: Petrol and Petrol-Ethanol Fuel Systems Health and Safety Precautions (100-00 General Information, Description and Operation).
2. WARNING: Do not work on or under a vehicle supported only by a jack.
Always support the vehicle on safety stands.
Raise and support the vehicle.
3. Refer to: Fuel Tank Draining (310-00 Fuel System - General Information, General Procedures).
4. Refer to: Wheel and Tire (204-04 Wheels and Tires, Removal and Installation).
5. Refer to: Driveshaft - V8 5.0L Petrol/V8 S/C 5.0L Petrol (205-01 Driveshaft, Removal and Installation).
6. CAUTION: Be prepared to collect escaping fluids.
NOTES:
The fuel tank has a non-return valve in the filler stub
pipe, only the fuel present in the filler hose will be spilt.
Some variation in the illustrations may occur, but the
essential information is always correct.
7. Using the special tool, press and hold the brake pedal. Powertrain Jack www.JagDocs.com
