JAGUAR XFR 2010 1.G Workshop Manual Front End Body Panels - Cowl Vent Screen Removal and Installation Removal CAUTION: Always protect paintwork and glass when removing exterior components. NOTE: Removal steps in this proce

Page 2194 of 3039

JAGUAR XFR 2010 1.G Workshop Manual

Page 2195 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Front End Body Panels - Engine Rear Undershield Removal and Installation Removal NOTE: Removal steps in this procedure may contain installation details. Published: 11-May-2011 1. WARNI

Page 2196 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Front End Body Panels - Fender Splash Shield Removal and Installation Removal NOTE: Removal steps in this procedure may contain installation details. Published: 11-May-2011 1. WARNING:

Page 2197 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Front End Body Panels - Hood Removal and Installation Published: 11-May-2011 Removal 1. NOTE: The hood is manufactured from aluminium. The hood is serviced as a separate bolt-on panel.

Page 2198 of 3039

JAGUAR XFR 2010 1.G Workshop Manual

Page 2199 of 3039

JAGUAR XFR 2010 1.G Workshop Manual

Page 2200 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Installation 1. NOTES: If the hood hinges are deformed as a result of the pedestrian protection system deployment, they will need to be replaced. This step requires the aid of another tech
