Page 1233 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 21. 22. NOTE: Engine shown removed for clarity. CAUTIONS: Remove and discard the high-pressure fu

Page 1234 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 23. 24. 25. 26. CAUTIONS: Be prepared to collect escaping fluids. Make sure that all openings are sealed. Use new blanking caps.

Page 1235 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Installation All vehicles 1. NOTE: Lubricate the fuel rail high-pressure fuel pump bucket with clean engine oil. 2. CAUTION: Tighten on both sides simultaneo

Page 1236 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 5. CAUTION: Install new high-pressure fuel supply lines. NOTES: Engine shown removed for clarity. Remove and discard the blanking caps. Install the bolt and unions fully finger tight b

Page 1237 of 3039

JAGUAR XFR 2010 1.G Workshop Manual Raise and support the vehicle. 10. 11. CAUTION: Lubricate only the union threads with clean engine oil. NOTE: Engine

Page 1238 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 12. 13. 14. NOTES: Install the bolt and unions finger tight before final tightening. Remove and discard the blanking caps. Torque: Unions 21 Nm M6 11 Nm

Page 1239 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 15. 16. NOTE: Engine shown removed for clarity. Torque: 25 Nm Left-hand drive vehicles 17.

Page 1240 of 3039

JAGUAR XFR 2010 1.G Workshop Manual 18. Torque: 35 Nm All vehicles 19. Refer to: Generator - V8 5.0L Petrol (414-02C Generator and Regulator - V8 5.0L Petrol/V8 S/C 5.0L Petrol, Removal and Installation). 20
